MSV - N2230W Day/Night Pan/Tilt IP Camera Hardware User Manual -Contents- CHAPTER 1. SAFETY INSTRUCTION ..................2 CHAPTER 2. INTRODUCTION .....................4 CHAPTER 3. PACKAGE CONTENTS ..................5 CHAPTER 4. PHYSICAL DESCRIPTION..................6 CHAPTER 5. BASIC CONNECTION ....................8 5.1 W ..........................8 ITHOUT ONNECTION 5.2 W... -
Page 3: Chapter 1. Safety Instruction
Hardware User Manual Chapter 1. Safety Instruction Before you use this product This product has been designed with safety in mind. However, the electrical products can cause fires which may lead to serious body injury if not used properly. To avoid such accidents, be sure to heed the following. - Page 4 In case of a breakdown In case of system breakdown, discontinue use and contact your authorized dealer. In case of abnormal operation • If the unit emits smoke or an unusual smell, • If water or other foreign objects enter the cabinet, or •...
-
Page 5: Chapter 2. Introduction
Chapter 2. Introduction The N2230W Day/Night Pan/Tilt IP Camera provides full overview and true day/night capabilities to be the perfect solution for indoor applications that need to cover everything at anytime, but still be cost-effective. Key Features: • Simultaneous MPEG-4 and Motion JPEG video stream •... -
Page 6: Chapter 3. Package Contents
Quick Installation Guide Software CD Component Pack Camera Camera – N2230W Day / Night Pan / Tilt IP Camera Quick Installation Guide - To provide brief product information and quick installation and wireless setting Software CD - To provide IP Surveillance Software, Intelligence IP Installer, User Manuals, and... -
Page 7: Chapter 4. Physical Description
Chapter 4. Physical Description Overview Focus Adjustment Ring - Adjust focus manually to achieve the best image quality Infrared LEDs - Infrared LEDs for night use up to 10 working distance Wireless Antenna – For connection of IEEE 802.11g/b wireless network Built-In Microphone - Built-In Microphone for Two-way Audio Power LED indicator - Power LED will light up after completing the boot process Network LED indicator - Network LED will light up after connecting with network. - Page 8 DI / DO Terminal connector diagram Please refer the following illustration below for connection method. D+ D- COM NO Ground Switch Alarm out device Ground Max. 30W...
-
Page 9: Chapter 5. Basic Connection
Chapter 5. Basic Connection N2230W is for both wire and wireless connection. You can follow the procedure below to connect the IP Camera with power and Ethernet for both wire and wireless connection. 5.1 Wired Connection 1. Connect the power adaptor to IP Camera 2. -
Page 10: Chapter 6. Application
Chapter 6. Application...
