Aqua Comfort AC750 Owner's Manual

Hide thumbs

Advertisement

Table of Contents

OWNER'S MANUAL
Vintage Signature Series models: AC750, AC1050, AC1100, AC1250, AC1500, AC1750

TABLE OF CONTENTS

WARRANTY
WARRANTY REGISTRATION
Proudly Made in the USA
support@aquacomfort.com
888-475-7443
Manufacturing High Quality, High Efficiency
Heat Pump Pool Heaters
2
2
2
2
2-3
4
5
6
7
8
9-10
10
11
12
13
14
ALL IN-GROUND
INSTALLATION,
MAINTENANCE
1
MODELS
OPERATION,
& SERVICE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AC750 and is the answer not in the manual?

Questions and answers

Related Manuals for Aqua Comfort AC750

Summary of Contents for Aqua Comfort AC750

  • Page 1: Table Of Contents

    OWNER’S MANUAL Vintage Signature Series models: AC750, AC1050, AC1100, AC1250, AC1500, AC1750 Proudly Made in the USA support@aquacomfort.com 888-475-7443 Manufacturing High Quality, High Efficiency Heat Pump Pool Heaters TABLE OF CONTENTS SAFETY CONSIDERATIONS INSPECTION ALL IN-GROUND GENERAL INFORMATION INSTALLATION MODELS WATER FLOW &...

  • Page 2: Safety Considerations

    SAFETY CONSIDERATIONS • Qualified personnel should perform installation, maintenance and service. • Make sure all field wiring conforms to the heater specifications and all national and local codes. • Disconnect all power sources before performing any maintenance or service to the heater. INSPECTION Immediately upon receipt, inspect cartons and their contents for damage due to transit.
  • Page 3 height of the chlorinator. • When all the plumbing connections are complete, and ample drying time is allowed, run the filter pump and check the entire system for water leaks. • Make sure filter is clean and there are no obstructions in the filtering system. •...

  • Page 4: Electrical Connections

    ELECTRICAL CONNECTIONS Field connections must comply with national and local codes. The work must be done by a qualified electrician. Heater must be permanently grounded and bonded. Bonding will drastically reduce the chances of electrolysis, “Electrical Corrosion.” Use copper conductors only. Disconnect all power sources before performing any work on unit.

  • Page 5: Modes Of Operation

    MODES OF OPERATION To Change Between Pool and Spa Setpoints Manually: This is the default factory setting (jumper on pins 1-2) and allows the user to change between the pool and spa setpoints by using the mode button located on the front control panel. The use of an external water pressure switch IS NOT required for this mode of operation.

  • Page 6: Wiring Diagrams

    WIRING DIAGRAMS Pool Heater Series - Wiring Schematic 230/60/1 97P675-01 7/25/03 Compressor Blue Fan Motor PTCR Note 2 Brown Green Black Yellow PIN 1 Orange TEST Black Orange Fan1 Blue Black Green Not Used Brown Blk/Wht Unit Microprocessor Control Violet Power Supply Brown 208-230/60/1...

  • Page 7: Electronic Control Panel

    ELECTRONIC CONTROL PANEL FAULT CODES HP - High Pressure PO - Water Sensor Open LP - Low Pressure HC - Water Sensor Closed dO - Defrost Sensor Open F1 - Flow Switch 1 F2 - Flow Switch 2 dC - Defrost Sensor Closed bO - Brown Out Protection FS - Remote Flow Switch HEAT...

  • Page 8: Chemical Use

    CHEMICAL USE Water quality must be checked regularly and maintained within recommended limits at all times. Failure to maintain the proper water quality will greatly reduce the life of your heater. • Never add chemicals directly into skimmer. • Automatic chlorinators must be piped downstream from the heater. A check valve must be installed between the chlorinator and heater to prevent raw chlorine from draining back into the heater.

  • Page 9: Start-Up

    START-UP Before proceeding with this section make certain all plumbing connections are airtight and leak free. Flow rates should not exceed 70 GPM maximum. Use of an external bypass is necessary at 70 GPM and above. Minimum flow rate is 20 GPM. •...

  • Page 10: Maintenance

    Because evaporation accounts for about 70 percent of pool heat loss, the beneficial effect of using a pool cover / solar blanket can be dramatic. Wind Speed Reduction Reducing wind velocity at the water surface reduces convective and evaporative losses. Fences, trees, hills, or tall hedges close to the pool perimeter are effective windbreaks.

  • Page 11: Troubleshooting Checklist

    TROUBLESHOOTING CHECKLIST 1. Check to be sure that the electrical power is on. Reset the breakers or replace fuses if necessary. 2. Check to be sure the electronic control panel is set properly. The unit must be in either the Pool or Spa mode and the desired temperature must be set above the actual pool or spa temperature for the heater to run.

  • Page 12: Calling For Service

    SERVICE PERFORMED WITHIN THE WARRANTY PERIOD MUST BE APPROVED BY AQUA COMFORT TECHNOLOGIES, LLC PRIOR TO SERVICE BEING PERFORMED AND ONLY BY AN AQUA COMFORT TECHNOLOGIES, LLC AUTHORIZED TECHNICIAN. SEE WARRANTY FOR DETAILS. Please have the following ready before calling:...
