Summary of Contents for iStarUSA ClayPower
- Page 1 ClayPower Rack/Tower On Line UPS USER MANUAL...
-
Page 2: Table Of Contents
Table of Contents 1. Important Safety Warning ..................... 1 1.1. Transportation ....................... 1 1.2. Preparation ......................1 1.3. Installation ......................1 1.4. Operation ......................1 1.5. Maintenance, service and faults .................. 2 2. Installation and setup ....................3 2.1. Rear panel view ..................... 3 2.2. -
Page 3: Important Safety Warning
Prevent no fluids or other foreign objects from inside of the UPS system. The EPO, RS-232 and USB circuits are an IEC 60950 safety extra low voltage (SELV) circuit. This circuit must be separated from any hazardous voltage circuits by reinforced insulation. ClayPower Online UPS... -
Page 4: Maintenance, Service And Faults
Remove watches, rings, or other metal objects b) Use tools with insulated handles. c) Wear rubber gloves and boots. d) Do not lay tools or metal parts on top of batteries. e) Disconnect charging source prior to connecting or disconnecting battery terminals. ClayPower Online UPS... -
Page 5: Installation And Setup
Model No. Type CP-900W-2U CP-900W-L-2U Standard Long Run-time CP-1350W-2U P-1350W-L-2U Model Model CP-1800W-2U CP-1800W-L-2U CP-2700W-2U CP-2700W-L-2U 2.1. Rear panel view CP-900W-2U CP-1350W-2U CP-1800W-2U CP-2700W-2U 1. Programmable outlets: connect to non-critical loads. 2. Output receptacles: connect to mission-critical loads. ClayPower Online UPS... -
Page 6: Operating Principle
Before install the UPS, please follow below steps to re-connect battery wires first. Step 1 Step 2 Step 3 Remove front panel. Connect the AC input and Put the front panel back to re-connect battery wires. the unit. ClayPower Online UPS... - Page 7 Rackmount installation Install the UPS and external battery Vertical postion installation Install the UPS and external battery NOTE: When installing the UPS or battery pack with feet, please keep 70mm distance from the edge of the unit. ClayPower Online UPS...
-
Page 8: Setup The Ups
Note: USB port and RS-232 port can’t work at the same time. Step 4: Network connection Network/Fax/Phone surge port Connect a single modem/phone/fax line into surge-protected “IN” outlet on the back panel of the UPS unit. Connect from “OUT” outlet to the equipment with another modem/fax/phone line cable. ClayPower Online UPS... - Page 9 2. Click ViewPower software icon and then choose your required OS to download the software. 3. Follow the on-screen instructions to install the software. 4. When your computer restarts, the monitoring software will appear as an orange plug icon located in the system tray, near the clock. ClayPower Online UPS...
-
Page 10: Battery Replacement
After replacing the Re-connect the battery wires. battery box and replace the batteries, put the battery inside batteries. box back to original location and screw it tightly. Step 7 Put the front panel back to the unit. ClayPower Online UPS... -
Page 11: Battery Kit Assembly (Optional)
Step 3: Put assembled battery packs on Step 4: Cover the other side of plastic shell as one side of plastic shells and insert one below chart. Then, battery kit is assembly well. more defect battery on the space. Defect battery ClayPower Online UPS... - Page 12 Step 2: Connect all battery terminals by following below chart. Tapes Tapes Step 3: Put assembled battery packs on Step 4: Cover the other side of plastic shell as one side of plastic shells. below chart. Then, battery kit is assembly well. ClayPower Online UPS...
-
Page 13: Operations
Battery info Load info Input/output and Battery info Battery info Warning & Fault info/ Input/output Setting operation Warning and Battery & Fault info/ Setting info operation UPS status Backup UPS status time info Load info Backup time info ClayPower Online UPS... - Page 14 Indicates the UPS powers the output directly from the mains Indicates that the UPS alarm is disabled. Indicates the battery charger is working. Battery information Indicates the Battery level by 0-25%, 26-50%, 51-75%, and 76-100%. Indicates low battery. Indicates there is something wrong with battery. ClayPower Online UPS...
-
Page 15: Audible Alarm
Display content Meaning Enable Disable Escape Rack display Tower display Low Battery Overload Battery is not connected Overcharge Site Fault Over Temperature Charger Failure Battery Fault Frequency Unstable in Bypass Mode Input Voltage is Out of Bypass Range ClayPower Online UPS... -
Page 16: Ups Setting
BAT 60: presents output frequency is 60Hz If converter mode enable, you may choose the following output frequency: CF 50: presents output frequency is 50Hz CF 60: presents output frequency is 60Hz 04: ECO enable/disable Interface Setting ClayPower Online UPS... - Page 17 ENA: Advanced ECO mode enable DIS: Advanced ECO mode disable 06: Bypass mode enable/disable Interface Setting ENA: Bypass mode enable DIS: Bypass mode disable 07: Programmable outlets enable/disable Interface Setting ENA: Programmable outlets enable DIS: Programmable outlets disable ClayPower Online UPS...
- Page 18 55/150 alternating flashing: acceptable input voltage range is from 55V to 150V. 80/130 alternating flashing: acceptable input voltage range is 80V to 130V. 85/135 alternating flashing: acceptable input voltage range is 85V to 135V. 00: Exit setting ClayPower Online UPS...
-
Page 19: Operating Mode Description
UPS will enter bypass mode or bypass mode can be set by front panel. Alarm is sounding every 10 second. Standby UPS is powered o without output mode power, but the battery still can be charge d. ClayPower Online UPS... -
Page 20: Faults Reference Code
Site wiring fault Sounding every second EPO enable Sounding every second Over temperature Sounding every second Charger failure Sounding every second Battery Fault Sounding every second Bypass Out Range Sounding every second Bypass Frequency Unstable Sounding every second ClayPower Online UPS... -
Page 21: Troubleshooting
Bypass. After repetitive overloads, Remove excess loads from the UPS is locked in the UPS output first. Then shut Bypass mode. Connected down the UPS and restart devices are fed directly by the mains. ClayPower Online UPS... - Page 22 Battery backup time is shorter Batteries are not fully Charge the batteries for at than nominal value charged least 5 hours and then check capacity. problem still persists, consult your dealer. Batteries defect Contact your dealer to replace the battery. ClayPower Online UPS...
-
Page 23: Storage And Maintenance
Before storing, charge the UPS 5 hours. Store the UPS covered and upright in a cool, dry location. During storage, recharge the battery in accordance with the following table: Storage Temperature Recharge Frequency Charging Duration -25°C - 40°C Every 3 months 1-2 hours 40°C - 45°C Every 2 months 1-2 hours ClayPower Online UPS... -
Page 24: Specifications
*Derate capacity to 95% when the output voltage is adjusted to 115VAC, derate capacity to 90% when the output voltage is adjusted to 110VAC and derate capacity to 80% when the output voltage is adjusted to 100VAC. ClayPower Online UPS... - Page 25 Blank Page...
