Summary of Contents for Dirtblaster NE445
- Page 1 DIRT BLASTER IN GROUND AUTOMATIC POOL CLEANER ASSEMBLY INSTRUCTIONS Congratulations on purchasing a Dirt Blaster Automatic Pool Cleaner! MODEL NE445...
- Page 2 DIRT BLASTER IN GROUND AUTOMATIC CLEANER...
- Page 3 S T T T E E E P P P 1 1 ATTACH THE SEAL To install the seal locate the word “UP”. Face it up towards the body of the cleaner. Gently stretch the seal over the foot pad of the cleaner until it sets itself into the groove as illustrated in figure 2.
- Page 4 S T T T E E E P P P 4 4 ASSEMBLE THE HOSE Your cleaner hose comes in 3’ sections which must be connected together. The hoses are connected by inserting the male cuff of one section of hose into the female cuff of another. Twist the sections of hose together until you establish a snug fit (See figure 5).
- Page 5 Once fully assembled, your Automatic Pool Cleaner should look like this..I N N N S S S T T T A A A L L L L L L A A A T T T I I I O O O N N Your automatic pool cleaner is designed to work in a wide variety of swimming pools.
- Page 6 H O O O S S S E E E B B B A A A L L L A A A N N N C C C E E You will also need to attach hose weights to neutralize the hose’s buoyancy in the water. For inground pools all three weights are typically needed.
- Page 7 If debris is still lodged inside the cleaner, you must remove the flapper. To do this you must take out the four red plugs in the foot pad. These are found on the bottom of the cleaner. They can be removed using a flat head screwdriver. Underneath there will be four screws.
- Page 8 T R R R O O O U U U B B B L L L E E E S S S H H H O O O O O O T T T I I I N N N G G POSSIBLE CAUSE SOLUTION PROBLEM...
