- Page 1 SVAT ELECTRONICS now you can see Covert Alarm Clock DVR with Built-In Color Camera USER’S MANUAL MODEL #: PI300-SD...
-
Page 2: Need Help
Toll free fax: 1.888.771.1701 PRODUCT TO THE STORE For more product information visit www.svat.com Please contact a SVAT customer support representative first regarding additional information on product features, specifications or assistance with setup. Note: This is manual version 1.0 for this product, you may find updated versions by visiting our website. -
Page 3: Warranty Information
PRODUCT WARRANTY INFORMATION Warranty Terms SVAT products are guaranteed for a period of one year from the date of We take quality very seriously. That is why all of our products come with purchase against defects in workmanship and materials. This warranty is limited to the repair, replacement or refund of the purchase price at SVAT’s... -
Page 4: Features
2. Product may not be exactly as shown on the package. Some images are used for illustration purposes only. 3. SVAT does not endorse any SVAT products for illegal activities. SVAT is not responsible or liable in any way for any damage, vandalism, theft or any other action that may occur while a SVAT product is in use by the purchaser. -
Page 5: Table Of Contents
TABLE OF CONTENTS SVAT ELECTRONICS now you can see Need Help Page WHAT’S INCLUDED Warranty Information Features Table of Contents What’s Included Buttons and Connections Installation Introduction Setting the LCD Alarm Clock Main Menu DVR Settings Search and Play Covert DVR Alarm Clock... -
Page 6: Buttons And Connections
BUTTONS & CONNECTIONS SVAT ELECTRONICS now you can see 1. AC Jack: Connect AC Adapter to this location 10. Time Switch: Select to adjust time, alarm or set to be locked 2. SD Card Slot: Insert SD Card in this slot Alarm Set 3. -
Page 7: Installation
INSTALLATION SVAT ELECTRONICS now you can see PI300-SD was designed to be quick and easy to set up and to use. Please follow these simple instructions to get your covert DVR up and running in just a matter of minutes. -
Page 8: Introduction
PI300. Please, take the time to read through this manual in its entirety to get the most out of your covert recording experience with the PI300-SD. PI300-SD ICONS Recording... -
Page 9: Setting The Lcd Alarm Clock
SETTING THE LCD ALARM CLOCK SVAT ELECTRONICS now you can see To turn off the alarm / use the snooze button: PI300 is a covert DVR hidden inside of a fully functional Magnasonic LCD alarm When the alarm is set and enabled, an audible buzzer will sound at the set clock. -
Page 10: Main Menu
MAIN MENU SVAT ELECTRONICS now you can see To access the main menu, press the joystick button. Navigation throughout the main menu is made easy with the directional joystick: move it up or down to navigate the menu, left or right to adjust settings and use the “STOP” button to go back a screen. -
Page 11: Dvr Settings
DVR SETTINGS SVAT ELECTRONICS now you can see Search and Play Search and Play Menu The Search and Play menu lets you view all of your previously recorded footage. Navigate this menu by moving the joystick up and down to scroll through the dates that footage was recorded on. -
Page 12: Set Motion Detection
DVR SETTINGS SVAT ELECTRONICS now you can see Set Motion Detection Adjusting the motion detection area is a convenient feature for you to customize your cover recording Set Motion Detection Area experience. This option allows you to eliminate unwanted items that would trigger motion recording, for example, a fan or television screen, allowing you to record only what is important to you. -
Page 13: Manual Record
DVR SETTINGS SVAT ELECTRONICS now you can see Manual Record Manual Record Menu Video Size: Select the resolution you wish to record while using Manual Record Mode. Choose between either 320x240 or 640x480 Frame Rate: Select how many frames per second (FPS) you wish to record. When using the resolution 320x240 you can select 1/2/10/15/20/30 FPS. -
Page 14: Motion Record
DVR SETTINGS SVAT ELECTRONICS now you can see Motion Record Schedule Record Menu From this menu, configure the settings for motion detection recording that occurs in your 24 hour recording schedule. Video Size: Select the resolution you wish to record while using Motion Record Mode. -
Page 15: Sd Card Status
DVR SETTINGS SVAT ELECTRONICS now you can see SD Card Options SD Card Options Menu This menu displays the size of your SD card and how much space is available. As well, you can set the size of files to be recorded, set automatic overwriting and format your SD card from this menu. -
Page 16: System Status
DVR SETTINGS SVAT ELECTRONICS now you can see System Status System Status Menu The System Status Menu displays all of your PI300’s current settings but features no adjustable values. Use this screen to quickly review all of your covert DVR’s current settings. -
Page 17: Factory Default
DVR SETTINGS SVAT ELECTRONICS now you can see Factory Default System Status Menu This option allows you to set your PI300 back to its factory default settings, precisely the way the unit came out of the box. To set factory default: Select the factory default option from the main menu. -
Page 18: Dvr Specifications
DVR SPECIFICATIONS SVAT ELECTRONICS now you can see Functionality Simplex OSD and System Menu Display English Video Compression MPEG-4 OSD Language Display Selectable Resolution 640 x 480, 320 x 240 Time and Date Stamp Display Recording Frame Rate 320x240: 1~30FPS, 640 x 480: 1~15FPS... - Page 19 Disclaimer SVAT does not endorse any of SVAT products for any illegal activities. SVAT is not responsible or liable in any way shape or form for any damage, vandalism, theft or any other action that may occur while a SVAT product is in use by the purchaser.
