Summary of Contents for Blue Max GE65B 6.5HP

  • Page 27: Cylinder Head

    Cylinder head PART DESCRIPTION JD(JF168) HEAD COMP CYLINDER JF200.1 GUIDE IN.VALVE(OVERSIZE) JF168.1.2-4 GUIDE VALVE(OVERSIZE) JF168.1.2-5 CLIP VALVE GUIDE JF168.1.2-6 GASKET CYLINDER HEAD JF200.2-3 COVER COMP HEAD JF168.1.1.1 PACKING HEAD COVER JF168.1.1-3 TUBE BREATHER JF168.1.1-2 BOLT FLANGE 6X13 GB5780-86 BOLT STUD 6X109 JF168.1-2 BOLT STUD 8X32 GB5780-86...
  • Page 28 BOLT FLANGE 8X60 JF168.2-4 JF168.10-1 PLUG SPARK BPR4ES NGK Cylinder barrel BARREL ASSY CYLINDER JF200.2 OIL ALERT SWITCH ASSY OIL LEVEL JF168.4 GOVERNOR ASSY JF168.11.1-1 SLIDER GOVERNOR JF168.11.1-7 SHAFT GOVERNOR ARM JF168.11.2-1 PIN LOCK 8MM JF168.11.2-2 BOLT FLANGE 6X12 GB5780-86 BOLT DRAIN PLUG JF168.2-6 JF168.11.1-5...
  • Page 29 WASHER DRAIN PLUG 10.2MM GB95-85 CLIP GOVERNOR HOLDER JF168.11.1-8 BEARING RADIAL BALL 6205TMB GB276-89 GB13817-92 OIL SEAL 25X41X6 Cylinder barrel O-RING 14MM NOK JF168.14.2-10 NUT FLANGE 10MM GB6177-86 WASHER PLAIN 6MM JF168.11.1-6...

  • Page 30: Crankcase Cover

    Crankcase cover 1 COVER ASSY CRANKCASE JF168.15 BEARING RADIAL BALL 6205 GB276-89 PACKING CASE COVER JF168.15-2 CAP ASSY OIL FILLER JF168.15-3 CAP ASSY OIL FILLER JF168.15-5 COVER ASSY CRANKCASE JF168.15-1B BEARING RADIAL BALL 6205 GB276-89 PACKING OIL FILLER CAP JF168.15-6 OIL SEAL 25X41X6 GB13817-92 JF168.15-4...
  • Page 31 BOLT FLANGE 8X32 GB5780-86 Crankshaft 1 CRANKSHAFT COMP JF200.4-1A CRANKSHAFT COMP JF200.4-1B CRANKSHAFT COMP JF200.4-1C CRANKSHAFT COMP JF200.4-1D CRANKSHAFT COMP JF200.4-1E CRANKSHAFT COMP JF200.4-1F CRANKSHAFT COMP JF200.4-1G CRANKSHAFT COMP JF200.4-1H CRANKSHAFT COMP JF200.4-1I...
  • Page 32 CRANKSHAFT COMP JF200.4-1J CRANKSHAFT COMP JF200.4-1K CRANKSHAFT COMP JF200.4-1L GB5780-86 BOLT HEX 5/16” Crankshaft 1 WASHER 8MM GB95-85 KEY 5X5X33 GB1096-79 CRANKSHAFT COMP JF200.4-1M...
  • Page 33 Crankshaft 2 CRANKSHAFT COMP JF200.4-1N BOLT HEX 8X25 GB5780-86 WASHER 8MM GB95-85 KEY 5X5X33 GB1096-79...
  • Page 34 Piston RING SET PISTON STD. JF168.3-1 PISTON STD. JF200.1-5 PIN PISTON JF168.3-4 ROD ASSY. CONNECTING STD. JF168.3-6 BOLT CONNECTION ROD JF168.3-8 CLIP PISTON PIN 18MM JF168.3-9...
  • Page 35 Camshaft CAMSHAFT ASSY JF200.5-1A ROD PUSH JF168.1.2-14 VALVE ROCKER JF168.1.2-9 LIFTER VALVE JF200.1.2-15 PIVOT ROCKER ARM JF168.1.2-8 SPRING WEIGHT RETURN JF168.5-5 VALVE IN JF168.1.2-3 JF168.1.2-4 VALVE EX...
  • Page 36 SPRING VALVE JF168.1.2-10 RETAINER IN.VALVE SPRING JF168.1.2-1 RETAINER EX.VALVE SPRING JF168.1.2-2 RATATOR VALVE JF168.1.2-13 JF168.1.2-16 PLATE PUSH ROD GUIDE Camshaft BOLT PIVOT 8MM JF168.1.2-7 NUT PIVOT ADJUSTING JF168.1.2-17 CAMSHAFT ASSY JF200.5-1B...

  • Page 37: Recoil Starter

    Recoil starter STARTER ASSY RECOIL JF168.13 *R8* BRIGHT RED CASE COMP RECOIL STARTER JF168.13.1-1 *R8* BRIGHT RED REEL RECOIL STARTER BLACK JF168.13-3 JF168.13-4 RATCHET STARTER...
  • Page 38 GUIDE RATCHET JF168.13-6 SPRING FRICTION JF168.13-8 SPRING RECOIL STARTER JF168.13-10 SPRING RETURN JF168.13-4 GRIP STARTER JF168.13-1 ROPE RECOIL STARTER JF168.13-2 SCREW SETTING JF168.13-7 BOLT FLANGE 6X8 GB5780-86 Fan cover COVER COMP FAN*R8* JF168.13-11 BRIGHT RED PLATE SIDE STD JF168.12.2-1 JF168.12.2-3 CLAMPER CORD...
  • Page 39 SHROUD COMP JF168.12.3 SUB HARNESS JF168.18-2 SWITCH ASSY ENGINE STOP JF168.10.1 CORD STOP SWITCH(395MM) JF168.10.2-2 BOLT FLANGE 6X12 CT200 GB5780-86 BOLT FLANGE 6X20 CT200 GB5780-86 Carburetor(1) CHOKE KIT REMOTE CONTROL JF168.9-1 GASKET SET JF168.9-2 JF168.9-3 VALVE SET FLOAT...
  • Page 40 FLOAT SET JF168.9-4 CHAMBER SET FLOAT JF168.9-5 SCREW SET PILOT JF168.9-6 SCREW SET DRAIN JF168.9-7 SCREW SET JF168.9-8 CARBURETOR ASSY. BE11C A JF168.9-9 SCREW THROTTLE STOP JF200.9-10 NOZZLE MAIN JF168.9-11 PACKING FUEL STRAINER CUP JF200.9-12 JF168.9-13 INSULATOR CARBURETOR arburetor (1) PACKING INSULATOR JF168.9-14 JF168.9-15...

  • Page 41: Air Cleaner

    PACKING CARBURETOR JF168.1.1-4 HOLDER CONTROL CABLE JF168.6-9 STAY CHOKE CONTROL JF168.9-2 SPRING RETURN JF168.9-16 SPRING COCK LEVER JF168.9-17 PACKING FUEL COCK JF168.9-18 CUP FUEL STRAINER JF168.9-19 CIRCLIP 5MM JF168.9-20 SCREW PAN 3X8 JF168.9-21 SCREW PAN 4X8 JF168.9-22 GB819-85 PIN SPRING 2X12 Air cleaner PACKING ELBOW JF168.6-6...
  • Page 42 FILTER OUTER JF168.6-4 COVER AIR CLEANER DUAL JF168.6-3 GROMMET AIR CLEANER JF168.6.1-7 NOSE SILENCER JF168.6-5 COLLAR AIR CLEANER JF168.6-12 COLLAR B AIR CLEANER JF168.6-11 ELBOW COMP AIR CLEANER JF168.6-8 NUT AIR CLEANER COVER JF168.6-1 DACRO COAYING NUT TOOL BOX SETTING JF168.6-1 BOLT-WASHER 6X20 GB5780-86...
  • Page 43 BOLT-WASHER 6X20 GB5780-86 NUT FLANGE 6MM GB6177-86 Air cleaner...
  • Page 44 ELEMENT AIR CLEANER JF168.6.2-1 SEPARATOR AIR CLEANER JF168.6.2-2 CASE COMP AIR CLEANER JF168.6.2-3 COVER AIR CLEANER JF168.6.2-4 STAY AIR CLEANER JF168.6.2-5 SEAL AIR CLEANER JF168.6.2-6 BOLT WINKER SETTING GB5780-86 NUT FLANGE 6MM GB6177-86 BOLT FLANGE 6X10 GB5780-86 Muffler...

  • Page 45: Fuel Tank

    NUFFLER COMP SILENT JF168.7.6 STAY MUFFLER JF168.7.2-3 ARRESTER SPARK SILENT JF168.7.2 GASKET MUFFLER JF168.7-9 SCREW TAPPING 5X8 Q235A(GB700-88) PROTECT ,MUFFLER OUUTER JF168.7.1 Fuel tank...
  • Page 46 TANK ASSY FUEL GAUGE JF168.8. NH31 MCKNLIE WHILE TANK COMP FUEL*NH31* JF168.8.2 MIKINLIE WHITE RUBBER TANK CUSHION JF168.8.2-4 WASHER AIR DUCT JF168.8.2-5 PIN LOCK 8MM JF168.11.2-2 CLIP TUBE B8 JF168.8.3-4 TUBE FUEL 4X140 JF168.8.3-2 95001-45001-60M RUBBER SUPPORTER 107MM JF168.8.3-3 CLIP TUBE B8 JF168.8.3-4 BOLT FLANGE 6X25 GB5780-86...
  • Page 47 Fuel tank CAP COMP FUEL FILLER JF168.8.1 PACKING FUEL FILLER CAP JF168.8.1-4 O-RING 14MM NOK JF168.8.3.1-3...
  • Page 48 Flywheel KEY SPECIAL WOODRUFF 25X18 JF168.4-2 FAN COOLING JF168.12.1 PULLEY STARTER JF168.13-9 FLYWHEEL COMP JF168.4.1A FLYWHEEL COMP LAMP JF168.4.1B FLYWHEEL COMP JF168.4.1C SELF STARTER-7A NUT SPECIAL 14MM JF168.4.1-4...
  • Page 49 Control CONTROL ASSY (STD) JF168.11.4 CONTROL ASSY(REMOTE INTL) JF168.11 CONTROL ASSY (REMOTE) JF168.11.2 ARM GOVERNOR JF168.11.2-4 ROD GOVERNOR JF168.11.2-7 SPRING GOVERNOR JF168.11.2-5 SPRING THROTTLE RETURN JF168.11.2-6 CONTROL ASSY JF168.11.3 LEVER CONTROL JF168.11.4-2 SPRING LEVER JF168.11.4-5 WASHER CONTROL LEVER JF168.11.4-6 HOLDER CABLE JF168.11.4-8 JF168.11.4-4 SPACER CONTROL LEVER...
  • Page 50 JF168.11.4-1 BASE COMP CONTROL Control SPRING CONTROL ADJUSTING JF168.11.3-3 SPRING CABLE RETURN JF168.11.4-7 HOLDER WIRE JF168.11.4-9 COLLAR STOPPER JF168.11.4-10 BOLT FLANGE 6X12 CT200 GB5780-86 BOLT GOVERNOR ARM JF168.11.2-3 SCREW RECESSED 5X25 GB818-85 NUT SELF-LOCK 6MM GB6177-86 SCREW LOCK PAN GB818-85 CIRCLIP 5MM GB818-85 SCREW...
