DL300 FINGERPRINT LOCK
USER MANUAL
Please read this manual carefully before operation.
Please keep this manual for later reference.
Intelligent Biometric Controls, LLC.
Tel: (513) 336-9292 Fax: (513) 336-0626
Http://www.fingerprintdoorlocks.com
E-mail: support@ibcbiometrics.com
All rights reserved. Reproduction without permission is prohibited.
Advertisement
Table of Contents
Related Manuals for Intelligent Biometric Controls DL300
Summary of Contents for Intelligent Biometric Controls DL300
- Page 1 DL300 FINGERPRINT LOCK USER MANUAL Please read this manual carefully before operation. Please keep this manual for later reference. Intelligent Biometric Controls, LLC. Tel: (513) 336-9292 Fax: (513) 336-0626 Http://www.fingerprintdoorlocks.com E-mail: support@ibcbiometrics.com All rights reserved. Reproduction without permission is prohibited.
-
Page 2: Table Of Contents
Table of Contents 1. Introduction …………………………………………………………………………………………………01 1.1 Features ………………………………………………………………………………………………………01 1.2 Structure & accessories ………………………………………………………………………………01 1.3 Checklist …………………………………………………………………………………………………………03 1.4 Parameters …………………………………………………………………………………………………03 2. Getting Started ………………………………………………………………………………………………04 2.1 Lock Installation ……………………………………………………………………………………………04 2.2 Fingertip Position for Fingerprint Template Enrollment ………………………04 2.3 Glossary …………………………………………………………………………………………………………05 3. Operation ……………………………………………………………………………………………………05 3.1 Operation Flowchart for a mechanical key ………………………………………………………05... -
Page 4: Introduction
- 180 users maximum - Normal open status can be set and deleted. - Two colors options (where “XX” is either “LH” or “RH”): A. DL300-XXB : Polished brass with PVD coated; B. DL300-XXC : Satin chrome - Standalone version, easy to install. - Page 5 Accessories Mechanical keys 3mm Hexagonal Screwdriver 2mm Hexagonal Screwdriver Mechanical Key Tapping screw Fixing screw Strike Plate Strike...
-
Page 6: Checklist
1.3 Checklist Item Description Front body Back body Mortise Handle 2pcs Cylinder Mechanical key 2pcs Cylinder cover Hexagonal screwdriver 2pcs Strike Strike plate Side plate Small Fittings 1set Battery 4pcs User guide 1set Quality Certificate... -
Page 7: Parameters
1.4 Parameters Operating Environment Operating Temperature Between -8ºC and +85ºC Storing Temperature Between -25ºC and +85ºC Humidity Between 20%RH and 90%RH Technical Parameters Parameter Description Value Optical sensor Fingerprint sensor 500 dpi Resolution of sensor Antistrike ability of sensor Remain good condition after being jabbed with a 4H pencil at surface a 20cm’s distance Authentication speed... -
Page 8: Lock Installation
2. Get started 2.1 Lock Installation Refer to Appendix A for detailed lock installation steps. - Power supply on and Initialization Step 1 Put 4 AA alkaline batteries into the battery box; Step 2 The red and green indicators flash once at the same time; Step 3 The motor makes a “zi”... -
Page 9: Glossary
Glossary Normal open status: The lock keeps open no matter the door is closed or not. The lock can be opened by rotating outside handle any time without neither mechanical key nor fingerprints. Locking Status: The door will be locked up when it is closed and a key is needed to open the door. -
Page 10: Fingerprint Template Enrollment
3.5 Fingerprint Template Enrollment 3.5.1 Ordinary fingerprint key : means fingerprints which can only unlock while the deadbolt doesn’t extend (The door is locked with latches only, but the deadbolt doesn’t extend). Step 1. Use the 2mm hexagonal screwdriver to take off the cylinder cover. (After the operation with a mechanical key, cover the cylinder back in the correct direction and press it with strength). -
Page 11: Unlocking With An Enrolled Fingerprint
3.6 Unlocking with an enrolled fingerprint Make sure the door is in locking status before you unlock it. Step 1. Put an enrolled fingertip onto the sensor and rotate the handle. The green indicator should lights up and red indicator should flash. Step 2. -
Page 12: Maintenance Guide
4 Maintenance Guide 4.1 Daily Maintenance Sensor & Lock Surface Clean Daily Maintenance Keep sensor & lock surface clean Check fixing screws, handles, side and dry. Clean it with soft and dry plates and strike plates every two cloth if any stain on the lock surface. months. -
Page 13: Appendix
Appendix: A: Lock Installation Guide 1. Door Requirement 1.1 Wooden door with thickness from 38mm to 55mm. 1.2 If the door surface is decorated, the distance from the decorative edge to the doorframe must be between 108mm and 150mm. 1.3 If the lock is to be installed on a hollow door, underlay with a piece of wooden board the part of the door where the lock body is to be fixed on. - Page 14 Diagram 1...
- Page 15 Diagram 2 Diagram 3 Diagram 4 Diagram 5 Step 7. After the cylinder has been installed, insert the end with gutters on edges of the long square shaft into the square hole on the door to locate the outside handle. Step 8.
- Page 16 alkaline batteries. (Refer to Diagram 6). Diagram 6 Step 11. Tighten the armature plate by two screws; Step 12. Test the lock as per operation instruction. 4. Strike Installation Step 1. Make the five latches of the lock extended until that they touch the side of the door frame and draw lines on the frame according to the position of latches to decide the upper and lower lines of the strike.
-
Page 17: Left Handing & Right Handing
Diagram 7 B: Left Handing & Right Handing Stand outside and face the door, if the hinge is on the left, then the lock is a Left Handing one; if the hinge is on the right, and then the lock is a Right Handing one. To be shown as follows.
