Summary of Contents for Elecate Grill ELVGRL-X
- Page 1 USER MANUAL For Model: ELVGRL-X IMPORTANT DANGER & WARNINGS You Must Read This User Manual Before Operating Your Gas Grill Keep This Manual For Future Reference © 2015 PointElevate, Inc. POINTELEVATE.COM...
-
Page 2: Danger & Warnings
DANGER & WARNINGS This manual contains important information necessary for proper assembly and safe use of the appliance. Read and follow all warnings and instructions before assembling and using the appliance. Follow all warning and instructions when using the appliance. DANGER DANGER 1. - Page 3 DANGER & WARNINGS You must read this owner’s manual before operating your gas grill for the first time. GENERAL INSTRUCTIONS • Follow all-leak check procedures carefully • Never place hands or fingers on the edge of listed in this manual prior to barbecue the cooking surface while grill is operating operation.
- Page 4 • Do not tamper, alter or modify any parts of this grill. In doing so may cause explosion resulting in property damage and serious bodily harm, which may result in severe injuries or death. • Do not use this grill as a campfire or heater.
- Page 5 KNOWING YOUR GRILL PARTS LIST: Grill Regulator Burner Assembly Gas Circuit Knob Drip Tray Grill Housing Handle Assembly Canister Door Housing Top Grill Housing Bracket Lower Housing Bracket Side Cover Battery Cover Feet MODEL #: ELVGRL-X...
-
Page 6: Battery Installation
BATTERY INSTALLATION 1. Locate Battery Compartment on the bottom of 4. Insert battery negative first. the base. 2. Remove battery compartment cover. 5. Replace and tighten battery cap. 3. Rotate counter-clockwise to loosen battery cap. 6. Replace battery compartment cover. - Page 7 SETTING UP YOUR GRILL FOR THE FIRST TIME 1. Place grill on steady flat surface with the base 4. Insert the grate indentation under the grill lip level to the surface. and then lower gently until grate rests evenly in the grill. 2.
-
Page 8: Leak Testing
LEAK TESTING After a period of nonuse, we recommend that you perform the following maintenance procedures WARNING for your safety. If you see, smell or hear the hiss • Inspect the burner for correct flame pattern. of escaping gas from the propane Clean if necessary, following the procedures outlined in the “Maintanence”... - Page 9 ATTACHING REGULATOR & PROPANE CYLINDER (16.4 CANISTER) Note: Use only propane cylinders with the capacity of 16.4 oz./465 g (1.02 lbs.). You can find these tanks available in most sporting and hardware stores. Statement: The LP gas supply cylinder must be constructed and marked in accordance with the specifications for LP gas cylinders, U.S.
- Page 10 5. Grill with regulator and propane cylinder properly assembled. (Fig. 04) WARNING If there is a leak at connection, remove the propane cylinder. Do not operate grill and use a different propane cylinder. FIG. 04 6. Never operate grill with propane cylinder in an inverted position.
- Page 11 STARTING THE GRILL Note: Always check for gas leaks before starting your grill. Refer to page 8, Attaching Regulator & Propane Cylinder. 5. Release volume control button. 1. Ensure ON/OFF button is OFF and volume control knobs are in the OFF position. 6.
- Page 12 TURNING OFF YOUR GRILL 1. Return volume control knobs to OFF position. 4. Wait for grill to completely cool before closing. 2. Press ON/OFF button to OFF position. 5. Fold grill to upright position and raise handles until joined and locked. 3.
- Page 13 REMOVING REGULATOR & PROPANE CYLINDER 1. Unscrew locking mechanism counter clock- wise until loose. WARNING Do not use wrench to loosen the propane cylinder from the regulator. Using a wrench could damage the regulator and propane cylinder. WARNING Always detach propane cylinder after each use.
- Page 14 STORING PROPANE CYLINDER IN BASE 1. Press down on latch and move cover in a downward motion. WARNING Store propane cylinder in accordance to manufacturer guidelines. DANGER Never store propane cylinder near high heat, open flames, pilot lights direct sunlight and other ignition sources.
- Page 15 USING GRATE REMOVAL TOOL 1. Use the grate removal tool supplied and insert into one of the slits nearest the center of the WARNING grill. (Fig. 06) Do not attempt to lift grates when it is HOT. Make sure grill is cool before attempting to use grate removal tool.
- Page 16 REMOVING GREASE TRAY Note: Grate must be removed to access grease tray. Refer to page 14, Using Grate Removal Tool. 1. Lift burners gently to the maximum position. (Fig. 09) WARNING Do not attempt to remove grease tray when HOT. CAUTION Grease tray has built-in reservoir for excess debris when transporting.
- Page 17 CLEANING & MAINTAINING YOUR GRILL Note: Do not use oven cleaner, abrasive cleansers, cleaners that contain citrus products or abrasive cleaning pads on any part of the grill. GRATES WARNING 1. Make sure grates are cool. Attempt to clean only when burners 2.
- Page 18 HOW TO VISUALLY CHECKING BURNER FLAMES A good flame should be blue with minimal yellow tip. Some yellow tips on flames are acceptable as long as no carbon or soot deposits appear. Blue Yellow WARNING Keep appliance area clear and free from combustible materials, gasoline and other flammable vapors and liquids.
-
Page 19: List Of Optional Accessories
LIST OF OPTIONAL ACCESSORIES • Aluminum Griddle Plate (Model #: ELVAGP) • Ceramic Pizza Stone (Model #: ELVCPS) • Aluminum Cooking Grates (Model #: ELVACG) LIMITED WARRANTY The limited warranty does not cover damage due to such PointElevate (“Seller”) and the person or entity that things as accident, misuse, abuse, mishandling, neglect, acquires these goods from Seller (“Purchaser”) acts of God, fires, earthquakes, floods, high winds,... - Page 20 FOR OUTDOOR USE ONLY If you have any questions about assembly, operations, warranty or service, Contact PointElevate at: PointElevate, Inc. 16770 E Johnson Dr. City of Industry, CA 91745 Phone: 877-551-0484 Email: info@pointelevate.com...
