USER MANUAL
CAR BLACK BOX EP-HD001
Instructions before use
This user manual will describe the usage of this product in details and at the same time provide
comprehensive
information including usage, operation, installation instructions and specification, etc. Please read
the manual
carefully and keep it properly. We hope our product will satisfy your need and provide you with
longterm services.
Product Guarantee
This product is approved by ISO9001:2000 International Quality Standard and certified with FCC,
CE and SGS.
Our customers can use this product free of apprehension.
Copyright infringement Warning
Please note this product is for personal use only. The forms of usage should not offend or infringe
international
or domestic copyright laws and regulations. All recorded videos should be for personal use only.
Please note that
using this product for recording of occasions like shows, exhibitions or commercial activities will
infringe others'
copyrights or legislation rights.
Check Product Accessories
Please check whether the following
accessories are present before use,
1. Vehicle Power Cable (4M) x1
2. Holder x1
3. USB Cable x1
4. User Manual x1
Product Structure
1. Lens
2. Record / Photo / OK
3. Power On/Off ;
Short Press Power On/Off ;Long
Press Forced Shutdown Button
4. MIC Switch
5. Playback Enter/Quit
6. Left/UP
7. Right/Down
8. Charging LED
Advertisement
Table of Contents
Related Manuals for Epine EP-HD001
Summary of Contents for Epine EP-HD001
- Page 1 USER MANUAL CAR BLACK BOX EP-HD001 Instructions before use This user manual will describe the usage of this product in details and at the same time provide comprehensive information including usage, operation, installation instructions and specification, etc. Please read the manual carefully and keep it properly.
- Page 2 9. Red Indicator Light (Recording) 10.Blue Indicator Light (GPS) 11. SD card Slot 12. Reset 13. Menu/Delete 14. Mode 15. USB Port/AV Output 16.HDMI Output Installation Holder Installation Install Memory Card Removing the Stand - hand pinch bracket exit slot can be directly (without moving any snaps).
- Page 3 Photo size Photos resolution can be configured during capture. Higher value means higher resolution and better picture quality. MENU Button 【Image Param】 Menu【Photo size】 【3M(2048X1536)】/ 【4M(2592x1728)】 / 【5M(2592x1944)】 /【8M (3200x2400)】 /【12M (4000x3000)】 Burst Burst option can be used to set the number of selftime-capture. MENU Button 【Image Param】Menu 【Burst】...
- Page 4 According to the brightness during shooting, selecting [AUTO] can set optimum ISO sensitivity. MENU Button【Image Param】Menu【ISO】 【Auto】/【100】/【200】/【400】/【800】/【1600】 If “EV” is adjusted to + side, you can avoid under-exposure, or dark objects as shooting against a bright background. If “EV” is adjusted to – side, then you can avoid over-exposure, or bright objects as shooting against a dark background or at night.
- Page 5 When there is a collision, with the help of the changes in XYZ curves,G Sensor or Gravity Sensor can determine the direct- ion of the collision and simultaneously set the recorded data to protection mode, and the data will not be overwritten by circulated recording.Adjust the sensitivity parameter of XYZ axles.
- Page 6 Setting Plate Set, can choose to record car number or not record car number during recording. MENU Button Menu【PLATE SET】Setting NUMBER: 【0】/【1】/【2】/../【7】/【8】/ 【9】/ 【A】/【B】/【C】/../【X】/【Y】/【Z】 Stamp Through this function, you can select whether to show time and date during recording. MENU Button【System Setup】Menu【Stamp】 【On】/【Off】 Date &...
- Page 7 Delete the single video clip currently selected. Playback button Select video Press Menu button【Delete file】 【No】/【Delete】Press OK button to process. Slideshow Video clips can be played continuously. Setting [1 second] means,after the video is over, it will pause for 1 second before playing the next video clip Playback button? Select video clips Press menu button 【Slideshow】...
- Page 8 For the video that don’t have gps signal in it, speed and map will not be showed on the GPS player. In the menu panel: “ ” play “ ” pause 1/2 1x 2x 4x speed up or slow speed “...
