Seura DSM-10.3 User Manual

Televisio mirror
Hide thumbs
Table of Contents

Advertisement

Quick Links

Version 3
DsM-10.3, DsM-19.3
Te l e v i s i o n M i r r o r
User M anUal
Model No: _______________________
Serial No: ________________________
w w w. s e u r a . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DSM-10.3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Seura DSM-10.3

Summary of Contents for Seura DSM-10.3

  • Page 1 Version 3 DsM-10.3, DsM-19.3 Te l e v i s i o n M i r r o r User M anUal Model No: _______________________ Serial No: ________________________ w w w. s e u r a . c o m...
  • Page 2 Thank you for selecting a Séura Television Mirror. This product has been inspected and packaged carefully before shipment. Please read this guide before beginning installation. Please keep this manual for future reference. Information in this manual is subject to change without prior notice. FCC Information This equipment has been tested and found to comply with limits for a class B digital device, pursuant to Part 15 of the FCC Rules.

  • Page 3: Table Of Contents

    Contents CHaPTER 1 CHaPTER 4 Before Use Menu In The Box ..........5 The Menu System ........21 Parts ............5 Video Menu ..........21 Connections ..........6 audio Menu ..........25 Remote Control ......... 8 TV Menu ........... 26 Insert Remote Control Batteries ....

  • Page 4: Before Use

    Before Use In The Box Parts Connections Remote Control Insert Remote Control Batteries Menu Controls on Remote Menu Configuration Basic Operation...

  • Page 5: In The Box

    In The Box Please make sure the following items are included. Television Mirror Product Waterproof Remote Control Recycle Power Cord & Power adapter User Manual all Séura packaging is 100% recyclable. Please utilize recycling facilities in your area to dispose of all paper and plastic packaging materials.

  • Page 6: Connections

    Connections 19" LCD Back View Stereo audio 2 Channel amplified (green) IR Input (pink) PC audio In Speaker Out (blue) Power Line audio 15 Pin RS232 adapter IR Output (blue) RF Coaxial Internal/External HDMI Component Input Input antenna Sound Selector (black) Input Input...

  • Page 7: Back View

    Connections (cont.) 10" LCD Back View Stereo audio 2 Channel amplified (green) IR Input (pink) PC audio In Speaker Out Line audio (blue) Power 15 Pin RS232 adapter RF Coaxial HDMI Component (black) Input Input antenna Input Input Input YPbPr Composite IR Output (blue) On-Unit...

  • Page 8: Remote Control

    Remote Control 2010 Remote Redesign Final ReMoTe FuncTionS Power Turns television mirror on and off Last Recalls last channel viewed guide last Closed Caption Turns on/off subtitles mute guide View available electronic program guide sleep Mute Turns off/on audio zoom sleep activates sleep timer Zoom...

  • Page 9: Insert Remote Control Batteries

    Insert Remote Control Batteries 2010 Remote Redesign Final Remove the battery cover on the bottom of the remote using the tool included or a coin. Insert 2 aaa batteries. Ensure waterproof ring is securely in place before returning cover. Return cover and turn to “CLOSE” position. guide last Menu Controls on Remote...

  • Page 10: Menu Configuration

    2010 Remote Redesign 2010 Remote Redesign mute Final Final Menu Configuration sleep Press MEnU to open the menu window. navigate using 5 or 6 to select the desired menu. Press 4 or OK to enter the menu. Use 5 or 6 within the selected menu to navigate to a submenu or setting to adjust.

  • Page 11: Installation

    Installation Recommended Location Installation Instructions WARninGS Do not handle or remove your television mirror from the packaging until it is ready to be installed. To avoid damage to the television mirror, only transport it in a vertical position. It is highly recommended that at least three (3) persons assist in the installation of the television mirror. Mirror suction cups are not recommended for use in the installation of your television mirror.

  • Page 12: Recommended Location

    Recommended Installation Location The environment in which the television mirror product is installed will affect the product’s performance. The key factor to consider for proper installation is surrounding and ambient light. Use the following guidelines to maximize the performance of the SÉURa product: Type of Lighting: avoid direct natural sunlight and excessive fluorescent lighting on the television...

  • Page 13: Connection

    Connection Preparation Connecting Power Connecting TV antenna Connecting VIDEO / S-VIDEO Connecting HDMI Connecting Component Video Connecting PC Connecting Speaker Output Connecting RS-232C PC Control 3-10 Connecting IR Output 3-11 Connecting IR Input...

  • Page 14: Preparation

    Preparation Please read the relevant external equipment operation manual (DVD player, etc.) carefully before making connections. WARninG Whenever you connect an external audio or video system to your TV, ensure that all elements are switched off. Connecting Power The TV automatically adjusts voltage. Power Outlet Power cable is USa a-Type 3-conductor, shielded, Power Outlet...

  • Page 15: Connecting Video / S-Video

    Séura TV Mirror (back view) Connecting VIDEO Connect Video/audio cables to the video ports of the TV and camcorder, gaming consoles, VCR, DVD Video Source player or Set-Top box. Video Source Press SOURCE on the remote control and select Video Source a/V Video.

  • Page 16: Connecting Pc

    Connecting PC Connect 15-pin cable to 15-pin port on the TV and PC. PC Source Connect audio cable to audio output of a PC PC Source (stereo jack) and PC audio input port of the TV. Press SOURCE on the remote control to select PC Audio In Vga.

  • Page 17: Connecting Rs-232C Pc Control

    Séura TV Mirror (back view) Connecting RS-232C PC Control attach RS-232C cable cross-type to the supplied Din/D-Sub RS-232C. Set the RS-232C communication settings on the PC to match the PC Source communication conditions listed. COMMUnICaTIOn COnDITIOnS Model: 19.3 Model: 19.3 aLT / Hydra / 10.3 Baud rate: 9600 bps Baud rate:...

  • Page 18: Connecting Ir Output

    Control System attach a 3.5mm mono plug into the LCD or other AV System Control and use the discrete IR codes provided at www.seura.com/IRCodes.doc IR Receiver, Keypad, or other AV System Control Séura TV Mirror (back view) Séura TV Mirror (back view)
  • Page 19 000a 001F 000a 0047 000a 001F 000a 06C8 000a 0047 000a 001F 000a 001F 000a 001F 000a 001F 000a 001F 000a 001F 000a 001F 000a 001F 000a 0047 000a 001F 000a 0047 000a 0047 000a 001F 000a 0047 000a 06EE Download these codes at http://www.seura.com/IRCodes.doc...

  • Page 20: Menu

    Menu The Menu System Video Menu audio Menu TV Menu Setup Menu Parental Menu...

  • Page 21: The Menu System

    The Menu System after you have installed the battery in the remote control, you may want to set some preferences on the LCD using the menu system. • The buttons for On-Screen Display (OSD) option adjustment include MENU, 3, 4, 5, 6, OK or EnTER and EXIT buttons. • Press MENU to open the OSD Menu then press 5 or 6 button to select the pages. The pages are displayed in the following sequence (circular display) Video audio...
  • Page 22 Video Menu (cont.) adjustment of “Brightness” or “Contrast” 1) Press MEnU for the “Video” menu to appear 2) Press 4 or OK to select the “Video” menu 3) Press 5 or 6 to highlight your selection 4) Press 3 or 4 to adjust 5) Press MEnU or EXIT to return or exit menu mode adjustment of “saturation”...
  • Page 23 Video Menu (cont.) selection of “Color Temperature” 1) Press MEnU for the “Video” menu to appear 2) Press 4 or OK to select the “Video” menu 3) Press 5 or 6 to highlight your selection 4) Press 4 or OK to enter the sub-menu 5) Press 3 or 4 button to select one of “Cool”, “Standard”, “Warm”...
  • Page 24 Video Menu (cont.) selection of “Vga” (only for Vga) 1) Press MEnU for the “Video” menu to appear. 2) Press 4 or OK to select the “Video” menu. 3) Press 5 or 6 to highlight your selection. 4) Press 4 or OK to enter the sub-menu. selection of “auto adjust”...

  • Page 25: Audio Menu

    Audio Menu adjustment of “Balance”, “Bass” or “Treble” 1) Press MEnU, then press 6 for the “audio” menu to appear. 2) Press 4 or OK to select the “audio” menu. 3) Press 5 or 6 to highlight your selection. 4) Press 3 or 4 to adjust. 5) Press MEnU or EXIT to return or exit menu mode note: to toggle between Fixed and Variable audio output, use the Internal / External speaker selector switch on the LCD unit.

  • Page 26: Tv Menu

    TV Menu specifying “Tuner Mode” 1) Press MEnU, then press 6 until the “TV” menu appears 2) Press 4 or OK to select the “TV” menu 3) Press 5 or 6 to highlight your selection 4) Press 3 or 4 to select “Cable” or “antenna” 5) Press MEnU or EXIT to return or exit menu mode...
  • Page 27 TV Menu (cont.) Using the “Channel scan” 1) Press MEnU, then press 6 until the “TV” menu appears 2) Press 4 or OK to enter the “TV” menu 3) Press 5 or 6 to highlight your selection 4) Press 4 or OK to start searching The channels that are found will save automatically 5) If you want to stop searching, press MEnU or EXIT to return or exit menu mode...
  • Page 28 TV Menu (cont.) selecting Channel 1) Press the channel control buttons (V ) button to search the channels — the channel number will increase or decrease, excluding skipped channels. 2) Press numbered buttons 0~9 to select the channel you want. If the channel number is bigger than 9, press the two number buttons successively. If the channel number is bigger than 100, press the three number buttons successively.

  • Page 29: Setup Menu

    Setup Menu selection of “OsD Language” 1) Press MEnU, then press 6 until the “Setup” menu appears. 2) Press 4 or OK to select the “Setup” menu. 3) Press 5 or 6 to highlight your selection. 4) Press 3 or 4 to select “English”, “Español” or “Français”. English Español Français...
  • Page 30 Setup Menu (cont.) selection of “Time Zone” after entering the “Time setup” menu 1) Press 5 or 6 to highlight your selection. 2) Press 3 or 4 to select “Hawaii”, “Eastern Time”, “Indiana”, “Central Time”, “Mountain Time”, “arizona”, “Pacific Time” or “alaska”. Hawaii Eastern Time Indiana...
  • Page 31 Setup Menu (cont.) selection of “sleep Timer” after entering the “Time setup” menu 1) Press 5 or 6 to highlight your selection. 2) Press 3 or 4 to select “10”, “20”, “30”, “40”, “50”, “60”, “90”, “120”, “180”, “240”, Minutes or Off”. 3) Press MEnU or EXIT to return or exit menu mode To use Closed Caption (only for TV, aV, s-Video)
  • Page 32 Setup Menu (cont.) The analog closed caption features have two options • Captions A n on-screen display of the dialogue, narration, and sound effects of the TV programs and videos that are closed captioned (usually marked as “C/C” in TV listings. • Text A n on-screen display of information not related to the current program, such as weather or stock data (when provided by individual stations). • T o view captions, highlight CC1, CC2, CC3, or CC4 (CC1 displays translation of the primary language in your area).
  • Page 33 Setup Menu (cont.) Font Size To set the Font Size value from Large, Small and Medium. Font Color To set the Font Color value from White, green, Blue, Red, Cyan, Yellow, Magenta and Black. Font Opacity To set the Font Opacity value from Solid, Translucent and Transparent.

  • Page 34: Parental Menu

    Parental Menu Some programs and movies include signals that classify the content of the program (dialog, language, sex, violence). The “Parental” control feature in this detects these signals and blocks the programs according to your selections. To use this feature, perform the following. Parental control only available for TV, aV, s-VIDEO sources.
  • Page 35 Parental Menu (cont.) Using the “Change Password” item 1) after entering the “Parental” menu, press 5 or 6 to highlight the “Change Password” item. 2) Press 4 or OK to confirm. 3) Use 0~9 buttons input your new password in the “new Password” blank. 4) Use 0~9 buttons input your new password again in the “Confirm Password”...
  • Page 36 Parental Menu (cont.) Using the ratings items 1) after entering the “Program Block” menu, press 5 or 6 to highlight a ratings item (category options are listed on the following page) 2) Press 4 or OK to enter 3) Press 5, 6, 3, or 4 to select an item, then press OK to lock (display “ ”) or unlock (display “...
  • Page 37 Parental Menu (cont.) Unlocking programs temporarily If you try to watch a program that exceeds the restrictions you specified, the system enters program lock mode. You can either unlock the program temporarily by entering your password, or select a non-locked program to watch. V-Chip BLOCK To temporarily unlock the program, press the number buttons (0 - 9) to enter TV-Pg...

  • Page 38: Specifications

    Specifications Specifications...

  • Page 39: Specifications

    Specifications Display Features Tuner 10" 19" nTSC Display technology LED-LCD TFT-LCD Digital aTSC/QaM Screen Size 10" 19" Format 16:9 16:9 amplified audio Brightness 450 cd/m2 450 cd/m2 Viewing angle 170° 170° Output amplifier Power 5W x 2 Speaker Output Contrast 1000:1 1000:1 Internal Speakers...

  • Page 40: Maintenance

    Maintenance Mirror Care Troubleshooting...

  • Page 41: Mirror Care

    Mirror Care Our patented mirror technology has been developed to completely protect the mirror surface and allow ease of maintenance for the consumer. Please follow the guidelines listed for proper mirror care and cleaning: • T he glass surface can be cleaned with any conventional non-ammoniated glass cleaner. Care should be taken to use only a soft lint-free cloth. apply all cleaners directly to the cloth and not the mirror surface.
  • Page 42 Troubleshooting (cont.) PC Monitor-related problems no image on the monitor Check whether the D-Sub cable is firmly connected to the TV and a PC. Check whether a graphic card is correctly inserted into the slot. Check whether the power of a PC and the TV is on. Check whether a graphic card or mode is set appropriately on a PC.
  • Page 43 Notes...
  • Page 44 8 0 0 . 9 5 7. 3 8 7 2 w w w. seur a .com SÉURA, Inc. 1230 Ontario Road Green Bay, WI 54311 800.95.SEURA t: 920.857.9069 f: 920.857.9490 © SÉURA 2011 ® All Rights Reserved 2-1-11...
