Microfast MFPT01 Manual

Feature:
Vandalproof Mini Speed Dome Camera
Pan range: 0°~360° Continue
Tilt range: 0°~90° Flip
Pan Speed: Max 50°/sec
Preset: 16
Weatherproof Outdoor IP66
RS485, Pelco D/P supported
Specification:
Model
Image Sensor
Horizontal Resolution
CCD+DSP
Pixels
TV System
Lens
Sync System
Usable Illumination
S/N Ratio
Gamma Correction
Video Out
Scanning System
Electronic Shutter Time
Operation Temperature
Storage Temperature
White Balance
Power Source
MINI PTZ Dome Camera Feature
MFPT01
1/3" Super HAD II Sony CCD, Effio-e 12X(f=5~60mm),
Color 650TVL, Black 700TVL
Effio-e 12X(f=5~60mm),
PAL:976 (H)× 494(V) NTSC :976 (H) ×582 (V)
PAL/NTSC
12X optical zoom lens(f=5~60mm)
Internal
0.001Lux/F2.0
65dB (AGC OFF)
0.45
Composite Signal (1.0Vp-p, 75 )
PAL:625 Lines, 50 Field/Sec;NTSC:525 Lines, 60 Field/Sec
Auto:PAL 1/50-1/100, 000Sec;NTSC 1/60-1/100, 000Sec
-10 ~ +50
-20 ~ +60
Auto
DC12V 700mA
RH95% Max
RH95% Max
