1. INSTALLATION
1.1. Arm Condition Memory
If power to the alarm is removed it will remain in the same status when power it restored.
1.2. Immobiliser Relay Wiring
The system offers two ways of wiring the immobiliser as shown below.
When wired for Normally Open the immobiliser relay is switched on when the alarm is disarmed (fail secure). When wired as Normally
Closed the relay is on when the alarm is armed (fail safe).
1.3. Programming New Remote Controls
The included remote controls have been programmed to the system in the factory. Follow the procedure below to program a new
remote control to the system:
-
Turn the ignition on with the system disarmed.
-
Within 10 seconds, press valet switch 6 times.
-
The siren sounds for 2 sec. to confirm the system is now in code learning mode.
-
Within 10 sec., press any button of 1
The siren will sound for 1 sec. and hazard lights flash twice to confirm the 1
the previous codes in the system will be erased entirely.
-
Within 10 sec., repeat for the 2
*
Up to 4 remotes can be programmed to the system
*
The system will leave the code learning mode after programming 4 remotes to the system and the siren will sound for 2
seconds to confirm.
*
If no buttons are pressed within 10 seconds, the system will leave the learning code mode and the siren will sound for 2 seconds
to confirm.
*
The system will leave the code learning mode if the ignition is turned off at any time and the siren will sound for 2 seconds to
confirm.
SNIPER X2 VEHICLE SECURITY SYSTEM
Installation Manual
Wiring Diagram - Immobiliser Relay NO & NC
Normally Open Immobiliser Connection (Fail Secure)
Start
On
Acc
Off
fig. 1
W2-7
Normally Closed Immobiliser Connection (Fail Safe)
Start
On
Acc
Off
fig. 2
W2-8
st
remote control
nd
remote control and again for 3
To Acc.
87
86
30
87a
85
87a - Normally Closed
87 - Normally Open
To +12V DC or Acc.
87
86
30
87a
85
87a - Normally Closed
87 - Normally Open
st
remote has been programmed to the system and all
rd
th
and 4
remotes as applicable.
-
