Summary of Contents for IEI Technology IDS-200-A70Mi
- Page 1 IDS-200-A70Mi Digital Signage Player System MODEL: IDS-200-A70Mi Fanless Digital Signage Player with AMD R-260H Dual-Core CPU, AMD A70M Chipset, Four HDMI, GbE LAN, RS-232, USB 3.0, SD Slot, IPMI 2.0, RoHS Compliant User Manual Page I Rev. 1.00 – 14 February, 2014...
- Page 2 IDS-200-A70Mi Digital Signage Player Revision Date Version Changes 14 February, 2014 1.00 Initial release Page II...
- Page 3 IDS-200-A70Mi Digital Signage Player Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
- Page 4 IDS-200-A70Mi Digital Signage Player WARNING This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation.
-
Page 5: Table Of Contents
IDS-200-A70Mi Digital Signage Player Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 M ....................2 ODEL ARIATIONS 1.3 F ........................3 EATURES 1.4 F ......................3 RONT ANEL 1.5 R ....................... 4 ANEL 1.6 B ......................5... - Page 6 IDS-200-A70Mi Digital Signage Player 3.8.5 Power Connector (10 V ~ 30 V)............... 27 3.8.6 RS-232 Serial Port Connector ................. 27 3.8.7 USB 2.0 Connectors (Rear Panel) ..............28 3.8.8 USB 3.0 Connectors (Front Panel)..............29 3.9 IPMI S ..................30...
- Page 7 IDS-200-A70Mi Digital Signage Player 5.1 S ................. 56 YSTEM AINTENANCE VERVIEW 5.2 C ..............56 OMPONENT EPLACEMENT ROCEDURE 5.2.1 SO-DIMM Replacement................... 57 6 INTERFACE CONNECTORS ................... 59 6.1 P ..............60 ERIPHERAL NTERFACE ONNECTORS 6.2 I ..............61 NTERNAL ERIPHERAL ONNECTORS 6.2.1 BMC COM Debug Connector (BMC_COM1)..........
- Page 8 IDS-200-A70Mi Digital Signage Player List of Figures Figure 1-1: IDS-200-A70Mi Series Digital Signage Player ............2 Figure 1-2: Front Panel ........................4 Figure 1-3: Rear Panel........................5 Figure 1-4: Bottom Panel .......................5 Figure 1-5: IDS-200-A70Mi Dimensions (mm)................8 Figure 3-1: SD Card Slot Location ....................15 Figure 3-2: SD Card Installation ....................16...
- Page 9 IDS-200-A70Mi Digital Signage Player Figure 6-1: Main Board Layout Diagram (Front Side) ...............60 Figure 6-2: Main Board Layout Diagram (Solder Side) .............61 Page IX...
- Page 10 IDS-200-A70Mi Digital Signage Player List of Tables Table 1-1: Model Variations ......................2 Table 1-2: Technical Specifications....................7 Table 2-1: Package List Contents ....................12 Table 3-1: S/PDIF Connector Pinouts ..................25 Table 3-2: LAN Connector Pinouts .....................25 Table 3-3: RJ-45 Ethernet Connector LEDs ................26 Table 3-4: HDMI Connector Pinouts ...................26...
- Page 11 IDS-200-A70Mi Digital Signage Player List of BIOS Menus BIOS Menu 1: Main ........................36 BIOS Menu 2: Advanced ......................37 BIOS Menu 3: ACPI Configuration ....................38 BIOS Menu 4: RTC Wake Settings ....................39 BIOS Menu 5: CPU Configuration ....................40 BIOS Menu 6: IDE Configuration....................41 BIOS Menu 7: USB Configuration ....................42...
-
Page 13: Introduction
IDS-200-A70Mi Digital Signage Player Chapter Introduction Page 1... -
Page 14: Overview
1.1 Overview Figure 1-1: IDS-200-A70Mi Series Digital Signage Player The IDS-200-A70Mi series is a fanless digital signage player with AMD R-260H dual-core processor and AMD A70M APU Controller Hub. The IDS-200-A70Mi is preinstalled 4 GB of DDR3 SO-DIMMs and can accommodate up to 16 GB of DDR3 memory. Storage in the system is supported by the 2.5”... -
Page 15: Features
One S/PDIF connector RoHS compliant design 1.4 Front Panel The front panel of the IDS-200-A70Mi contains two USB 3.0 ports, LED indicators, a power button and a reset button. An overview of the front panel is shown in F igure 1-2. -
Page 16: Rear Panel
IDS-200-A70Mi Digital Signage Player Figure 1-2: Front Panel 1.5 Rear Panel The IDS-200-A70Mi rear panel provides access to the following external I/O connectors: 1 x 10 V ~ 30 V DC input jack 1 x Audio line-out jack 2 x GbE RJ-45 connectors... -
Page 17: Bottom Panel
Figure 1-3: Rear Panel 1.6 Bottom Panel The bottom panel of the IDS-200-A70Mi contains several screw holes for VESA mount and wall mounting brackets. The bottom panel also provides access to the internal components, including SO-DIMM slots, iRIS module slot and PCIe Mini card slots. -
Page 18: Technical Specifications
IDS-200-A70Mi Digital Signage Player 1.7 Technical Specifications The specifications for the IDS-200-A70Mi are listed below. IDS-200-A70Mi 2.1GHz AMD R-260H dual-core CPU (2MB L2 cache) System Chipset AMD A70M APM Controller Hub System Memory Two 2 GB DDR3 SDRAM SO-DIMMs preinstalled (system max. 16 GB) Graphics DirectX®... -
Page 19: Table 1-2: Technical Specifications
IDS-200-A70Mi Digital Signage Player Optional Wi-Fi 802.11b/g/n 2T2R Wireless Buttons One power button One reset button Chassis Construction Aluminum Alloy (top cover) with heavy duty metal VESA mount 75 mm Mounting Wall mount with brackets Power Input 10 V ~ 30 V DC Power Consumption 19 V @ 1.78 A (AMD R-260H with 4 GB memory) -
Page 20: Dimensions
IDS-200-A70Mi Digital Signage Player 1.8 Dimensions The physical dimensions of the IDS-200-A70Mi embedded systems are shown in Figure 1-5. Figure 1-5: IDS-200-A70Mi Dimensions (mm) Page 8... -
Page 21: Unpacking
IDS-200-A70Mi Digital Signage Player Chapter Unpacking Page 9... -
Page 22: Anti-Static Precautions
When the IDS-200-A70Mi is unpacked, please do the following: Follow the anti-static precautions outlined in Section 2.1. Make sure the packing box is facing upwards so the IDS-200-A70Mi does not fall out of the box. Make sure all the components shown in Section 2.3 are present. -
Page 23: Unpacking Checklist
If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the IDS-200-A70Mi from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@iei.com.tw. -
Page 24: Table 2-1: Package List Contents
IDS-200-A70Mi Digital Signage Player One Key Recovery CD Table 2-1: Package List Contents Page 12... -
Page 25: Installation
IDS-200-A70Mi Digital Signage Player Chapter Installation Page 13... -
Page 26: Installation Precautions
Electric shock and personal injury might occur if the rear panel of the IDS-200-A70Mi is opened while the power cord is still connected to an electrical outlet. -
Page 27: Sd Card Installation
3.2 SD Card Installation The IDS-200-A70Mi series has a SD card slot on the side panel. To install the SD card into the system, please follow the steps below. -
Page 28: Sim Card Installation
Step 3: 3.3 SIM Card Installation The IDS-200-A70Mi series has a SIM card slot on the side panel. To install the SIM card into the system, please follow the steps below. The SIM card slot is protected by a lockable cover on the side panel. Locate the Step 1: SIM card slot by opening the cover (Figure 3-3). -
Page 29: Hdd Installation
Close the cover. Lock it if necessary. Step 3: 3.4 HDD Installation The IDS-200-A70Mi has a 2.5” HDD bay on the side panel. To install an HDD, follow the steps below. The HDD bay is protected by a lockable cover on the side panel. Locate the Step 1: HDD bay by opening the cover (Figure 3-3). -
Page 30: Figure 3-6: Hdd Bracket Retention Screw
IDS-200-A70Mi Digital Signage Player Locate the HDD bracket inside the side panel. The HDD bracket is secured with Step 2: a retention screw. Remove the retention screw and pull the HDD bracket out of the system. Figure 3-6: HDD Bracket Retention Screw... -
Page 31: At/Atx Power Mode Selection
Step 6: 3.5 AT/ATX Power Mode Selection AT and ATX power modes can both be used on the IDS-200-A70Mi series. The selection is made through an AT/ATX switch on the rear panel ( F igure 1-3). To select AT mode or ATX mode, follow the steps below. -
Page 32: Atx Power Mode
Manufacturing shop flow 3.5.2 ATX Power Mode With the ATX mode selected, the IDS-200-A70Mi panel PC goes in a standby mode when it is turned off. The panel PC can be easily turned on via network or a power switch in standby mode. -
Page 33: Figure 3-10: Bottom Panel Retention Screws
IDS-200-A70Mi Digital Signage Player Figure 3-10: Bottom Panel Retention Screws Locate the IPMI module slot inside the bottom panel (Figure 3-11). Step 2: Figure 3-11: IPMI Module Slot Location Align the iRIS-2400 module with the IPMI module slot. Align the notch on the Step 3: module with the notch on the IPMI module slot. -
Page 34: Mounting The System
After installing the iRIS-2400 module, refer to Section 3.9 for IPMI setup Step 6: procedure. 3.7 Mounting the System To mount the IDS-200-A70Mi onto a wall or some other surface using the two mounting brackets, please follow the steps below. Turn the embedded system over. Step 1:... -
Page 35: Figure 3-13: Mounting Bracket Retention Screws
Insert four retention screws, two in each bracket, to secure the system to the Step 6: wall. NOTE: The IDS-200-A70Mi can also be mounted on a VESA 75mm complaint mounting device. Follow the user manual came with the VESA mounting devices to mount the system. Page 23... -
Page 36: External Peripheral Interface Connection
HDMI monitors Serial port devices USB devices To install these devices, connect the corresponding cable connector from the actual device to the corresponding IDS-200-A70Mi external peripheral interface connector making sure the pins are properly aligned. 3.8.1 Audio Line-out Connector CN Label:... -
Page 37: Lan Connector
IDS-200-A70Mi Digital Signage Player Description S/PDIFOUT Table 3-1: S/PDIF Connector Pinouts 3.8.3 LAN Connector CN Label: LAN1, LAN2 RJ-45 CN Type: See Table 3-2 CN Pinouts: The LAN connector allows connection to an external network. Description Description MD0+ MD0- MD1+... -
Page 38: Hdmi Connector
IDS-200-A70Mi Digital Signage Player The RJ-45 Ethernet connector has two status LEDs, one green and one yellow. The green LED indicates activity on the port and the yellow LED indicates the port is linked. See Table 3-3. Activity/Link LED Speed LED... -
Page 39: Power Connector (10 V ~ 30 V)
IDS-200-A70Mi Digital Signage Player Figure 3-16: HDMI Connector NOTE: When connecting HDMI displays, the monitors connected to HDMI 2 and HDMI 4 connectors must be identical (in the same brand, model number and size). 3.8.5 Power Connector (10 V ~ 30 V) -
Page 40: Usb 2.0 Connectors (Rear Panel)
IDS-200-A70Mi Digital Signage Player The RS-232 serial port connector allows connection to a serial device. Description Description DCD1 SOUT1 DSR2 CTS1 SIN1 DTR1 RTS1 Table 3-5: Serial Port Pinouts Figure 3-18: Serial Port Pinouts 3.8.7 USB 2.0 Connectors (Rear Panel) -
Page 41: Usb 3.0 Connectors (Front Panel)
IDS-200-A70Mi Digital Signage Player Figure 3-19: USB 2.0 Port Pinout Locations 3.8.8 USB 3.0 Connectors (Front Panel) CN Label: USB (USB_CON1, USB_CON2) USB 3.0 port CN Type: See Table 3-7 and Figure 3-20 CN Pinouts: The USB 3.0 ports are for connecting USB 2.0/3.0 peripheral devices to the system. -
Page 42: Ipmi Setup Procedure
To manage a client system from a remote console using IEI iMAN Web GUI, follow the steps below. Obtain the IP address of the IDS-200-A70Mi. It is recommended to use the IPMI Step 1: Tool on the managed system to obtain the IP address. To use IPMI Tool to obtain... -
Page 43: Figure 3-22: Iei Iman Web Address
IP address. Convert the hexadecimal numbers to decimal numbers. NOTE: An IP address will be assigned to the IDS-200-A70Mi after booting up for around one minute. Therefore, if the user fails to obtain the IP address, please try again later. -
Page 44: Figure 3-23: Iei Iman Web Gui
Figure 3-23: IEI iMAN Web GUI NOTE: To understand how to use the IEI iMAN Web GUI, please refer to the iRIS-2400 Web GUI user manual in the utility CD came with the IDS-200-A70Mi. The user manual describes each function in detail. Page 32... -
Page 45: Bios Screens
IDS-200-A70Mi Digital Signage Player Chapter BIOS Screens Page 33... -
Page 46: Introduction
IDS-200-A70Mi Digital Signage Player 4.1 Introduction The BIOS is programmed onto the BIOS chip. The BIOS setup program allows changes to certain system settings. This chapter outlines the options that can be changed. 4.1.1 Starting Setup The UEFI BIOS is activated when the computer is turned on. The setup program can be activated in one of two ways. -
Page 47: Getting Help
IDS-200-A70Mi Digital Signage Player Function Previous values Load optimized defaults Save changes and Exit BIOS Table 4-1: BIOS Navigation Keys 4.1.3 Getting Help When F1 is pressed a small help window describing the appropriate keys to use and the possible selections for the highlighted item appears. To exit the Help Window press E the F1 key again. -
Page 48: Main
IDS-200-A70Mi Digital Signage Player 4.2 Main The Main BIOS menu (BIOS Menu 1) appears when the BIOS Setup program is entered. The Main menu gives an overview of the basic system information. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. -
Page 49: Advanced
IDS-200-A70Mi Digital Signage Player System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year. System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds. -
Page 50: Acpi Settings
IDS-200-A70Mi Digital Signage Player 4.3.1 ACPI Settings The ACPI Settings menu (BIOS Menu 3) configures the Advanced Configuration and Power Interface (ACPI) options. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced ACPI Settings Select the highest ACPI... -
Page 51: Rtc Wake Settings
IDS-200-A70Mi Digital Signage Player 4.3.2 RTC Wake Settings The RTC Wake Settings menu (BIOS Menu 4) configures RTC wake event. The RTC wake function is supported in ACPI (S3/S4/S5) and APM soft off modes. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. -
Page 52: Cpu Configuration
IDS-200-A70Mi Digital Signage Player If selected, the following appears with values Enabled that can be selected: *Wake up every day *Wake up date *Wake up hour *Wake up minute *Wake up second After setting the alarm, the computer turns itself on from a suspend state when the alarm goes off. -
Page 53: Ide Configuration
IDS-200-A70Mi Digital Signage Player SVM Mode [Enabled] Use the SVM Mode option to enable or disable virtualization on the system. Disables CPU virtualization Disabled Enables CPU virtualization Enabled EFAULT 4.3.4 IDE Configuration Use the IDE Configuration menu (BIOS Menu 6) to change and/or set the configuration of the SATA devices installed in the system. -
Page 54: Usb Configuration
IDS-200-A70Mi Digital Signage Player 4.3.5 USB Configuration Use the USB Configuration menu (BIOS Menu 7) to read USB configuration information and configure the USB settings. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced USB Configuration Enables Legacy USB support. -
Page 55: Super Io Configuration
IDS-200-A70Mi Digital Signage Player Legacy USB support disabled Disabled Legacy USB support disabled if no USB devices are Auto connected 4.3.6 Super IO Configuration Use the Super IO Configuration menu (BIOS Menu 8) to set or change the configurations for the serial ports. -
Page 56: Serial Port 1 Configuration
IDS-200-A70Mi Digital Signage Player 4.3.6.1 Serial Port 1 Configuration Use the Serial Port 1 Configuration menu (BIOS Menu 9) to configure the serial port 1. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Advanced Serial Port 1 Configuration... -
Page 57: Iwdd H/W Monitor
IDS-200-A70Mi Digital Signage Player Serial Port I/O port address is 3F8h and the IO=3F8h; interrupt address is IRQ3,4 IRQ=3, 4 Serial Port I/O port address is 2F8h and the IO=2F8h; interrupt address is IRQ3, 4 IRQ=3, 4 Serial Port I/O port address is 3E8h and the IO=3E8h;... -
Page 58: Serial Port Console Redirection
IDS-200-A70Mi Digital Signage Player +12V +DDR3 +5VSB +3.3V 4.3.8 Serial Port Console Redirection The Serial Port Console Redirection menu (BIOS Menu 11) allows the console redirection options to be configured. Console redirection allows users to maintain a system remotely by re-directing keyboard input and text output through the serial port. -
Page 59: Chipset
IDS-200-A70Mi Digital Signage Player 4.4 Chipset Use the Chipset menu (BIOS Menu 12) to configure the system chipset. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Main Advanced Chipset Boot Security Save & Exit > South Bridge South Bridge Parameters >... -
Page 60: Sb Sata Configuration
IDS-200-A70Mi Digital Signage Player Restore on AC Power Loss [Last State] Use the Restore on AC Power Loss BIOS option to specify what state the system returns to if there is a sudden loss of power to the system. The system remains turned off... -
Page 61: Sb Hd Azalia Configuration
IDS-200-A70Mi Digital Signage Player OnChip SATA Type [Native IDE] Use the OnChip SATA Type BIOS option to configure SATA devices as normal IDE devices. Configures SATA devices as normal IDE device. Native IDE EFAULT Configures SATA devices as AHCI device. -
Page 62: North Bridge
IDS-200-A70Mi Digital Signage Player 4.4.2 North Bridge Use the North Bridge menu (BIOS Menu 16) to view the memory information. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. Chipset North Bridge Configuration South Bridge Parameters Memory Information Total Memory: 4096 MB (DDR3) --------------------- >... -
Page 63: Bootup Numlock State [On]
IDS-200-A70Mi Digital Signage Player Bootup NumLock State [On] Use the Bootup NumLock State BIOS option to specify if the number lock setting must be modified during boot up. Allows the Number Lock on the keyboard to be EFAULT enabled automatically when the computer system boots up. -
Page 64: Security
IDS-200-A70Mi Digital Signage Player Launch PXE OpROM [Disabled] Use the Launch PXE OpROM option to enable or disable boot option for legacy network devices. Ignore all PXE Option ROMs Disabled EFAULT Load PXE Option ROMs Enabled UEFI Boot [Disabled] Use the UEFI Boot option to enable or disable to boot from a UEFI device. -
Page 65: Exit
IDS-200-A70Mi Digital Signage Player User Password Use the User Password to set or change a user password. 4.7 Exit Use the Exit menu (BIOS Menu 19) to load default BIOS values, optimal failsafe values and to save configuration changes. Aptio Setup Utility – Copyright (C) 2012 American Megatrends, Inc. -
Page 66: Save As User Defaults
IDS-200-A70Mi Digital Signage Player Save as User Defaults Use the Save as User Defaults option to save the changes done so far as user defaults. Restore User Defaults Use the Restore User Defaults option to restore the user defaults to all the setup options. -
Page 67: Maintenance
IDS-200-A70Mi Digital Signage Player Chapter Maintenance Page 55... -
Page 68: System Maintenance Overview
Failure to follow these instructions may lead to personal injury and system damage. To preserve the working integrity of the IDS-200-A70Mi, the system must be properly maintained. If internal components need replacement, the proper maintenance procedures must be followed to ensure the system can continue to operate normally. -
Page 69: So-Dimm Replacement
5.2.1 SO-DIMM Replacement WARNING: Using incorrectly specified SO-DIMM may cause permanently damage the IDS-200-A70Mi. Please make sure the purchased SO-DIMM complies with the memory specifications of the IDS-200-A70Mi. To replace a SO-DIMM memory module into a SO-DIMM socket, please follow the steps below. -
Page 70: Figure 5-2: So-Dimm Locations
IDS-200-A70Mi Digital Signage Player Figure 5-2: SO-DIMM Locations Remove the SO-DIMM by releasing the arms on the SO-DIMM socket. Align the Step 3: new SO-DIMM with the socket. The SO-DIMM must be oriented in such a way that the notch in the middle of the SO-DIMM must be aligned with the plastic bridge in the socket ( F igure 5-3). -
Page 71: Interface Connectors
IDS-200-A70Mi Digital Signage Player Chapter Interface Connectors Page 59... -
Page 72: Peripheral Interface Connectors
IDS-200-A70Mi Digital Signage Player 6.1 Peripheral Interface Connectors The IDS-200-A70Mi series’ motherboard comes with a number of peripheral interface connectors and configuration jumpers. The connector locations are shown in Figure 6-1. The Pin 1 locations of the on-board connectors are also indicated in the diagrams below. -
Page 73: Internal Peripheral Connectors
Internal peripheral connectors are found on the motherboard and are only accessible when the motherboard is outside of the chassis. The table below shows a list of the peripheral interface connectors on the IDS-200-A70Mi motherboard. Pinouts of these connectors can be found in the following sections. -
Page 74: Bmc Com Debug Connector (Bmc_Com1)
IDS-200-A70Mi Digital Signage Player Connector Type Label SD card slot SD card slot SIM card slot SIM card slot SIM1 SO-DIMM connectors SO-DIMM connector DIMM1, DIMM2 SPI Flash connector 8-pin header JSPI1 SPI Flash connector, EC 8-pin header JSPI2 TPM connector... -
Page 75: Fan Connector (Fan1)
IDS-200-A70Mi Digital Signage Player PIN NO. DESCRIPTION PIN NO. DESCRIPTION EC_EPP_PD1 EC_EPP_INIT# EC_EPP_PD2 EC_EPP_SLIN# EC_EPP_PD3 EC_EPP_PD4 EC_EPP_PD5 EC_EPP_BUSY EC_EPP_PD6 EC_EPP_KSI5 EC_EPP_PD7 EC_EPP_KSI4 Table 6-4: EC Debug Connector (LPT_DB1) Pinouts 6.2.4 Fan Connector (FAN1) PIN NO. DESCRIPTION Rotation Signal +12V Table 6-5: Fan Connector (FAN1) Pinouts 6.2.5 PCIe Mini Slot (M_PCIE1, M_PCIE2) -
Page 76: Sata Connector (Sata1)
IDS-200-A70Mi Digital Signage Player PIN NO. DESCRIPTION PIN NO. DESCRIPTION PERN2 3VDual PERP2 1.5V SMBCLK PETN2 SMBDATA PETP2 USBD- USBD+ 1.5V VCC3 Table 6-6: PCIe Mini Card Slot Pinouts 6.2.6 SATA Connector (SATA1) SATA PIN NO. DESCRIPTION PIN NO. DESCRIPTION SATA Power PIN NO. -
Page 77: Spi Flash Connector (Jspi1)
IDS-200-A70Mi Digital Signage Player SATA PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 6-7: SATA Connector (SATA1) Pinouts 6.2.7 SPI Flash Connector (JSPI1) PIN NO. DESCRIPTION PIN NO. DESCRIPTION +V3.3M_SPI_CON SPI_CS SPI_SO_SW SPI_CLK_SW SPI_SI_SW Table 6-8: SPI Flash Connector (JSPI1) Pinouts 6.2.8 SPI Flash Connector, EC (JSPI2) -
Page 78: Clear Coms Jumper (Jp1)
IDS-200-A70Mi Digital Signage Player on the IDS-200-A70Mi motherboard. Jumper settings can be found in the following sections. Jumper Type Label Clear CMOS 3-pin header COM1 pin 9 selection 6-pin header Table 6-10: Internal Jumpers 6.3.1 Clear COMS Jumper (JP1) Setting... -
Page 79: External Interface Panel Connectors
IDS-200-A70Mi Digital Signage Player 6.4 External Interface Panel Connectors The table below lists the rear panel connectors on the IDS-200-A70Mi motherboard. Pinouts for these connectors can be found in Section 3.8: External Peripheral Interface Connection. Connector Type Label Audio line-out connector... -
Page 80: A Safety Precautions
IDS-200-A70Mi Digital Signage Player Appendix Safety Precautions Page 68... -
Page 81: Safety Precautions
Do not apply voltage levels that exceed the specified voltage range. Doing so may cause fire and/or an electrical shock. Electric shocks can occur if the IDS-200-A70Mi chassis is opened when the IDS-200-A70Mi is running. Do not drop or insert any objects into the ventilation openings of the IDS-200-A70Mi. -
Page 82: Anti-Static Precautions
Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IDS-200-A70Mi. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the IDS-200-A70Mi is opened and any of the electrical components are handled, the following anti-static precautions are strictly adhered to. -
Page 83: Product Disposal
Please follow the national guidelines for electrical and electronic product disposal. A.2 Maintenance and Cleaning Precautions When maintaining or cleaning the IDS-200-A70Mi, please follow the guidelines below. A.2.1 Maintenance and Cleaning Prior to cleaning any part or component of the IDS-200-A70Mi, please read the details below. Page 71... -
Page 84: Cleaning Tools
In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the IDS-200-A70Mi. C loth – Although paper towels or tissues can be used, a soft, clean piece of cloth is recommended when cleaning the IDS-200-A70Mi. -
Page 85: Bbios Menu Options
IDS-200-A70Mi Digital Signage Player Appendix BIOS Menu Options Page 73... -
Page 86: Bios Configuration Options
IDS-200-A70Mi Digital Signage Player B.1 BIOS Configuration Options Below is a list of BIOS configuration options described in Chapter 4. System Overview .........................36 System Date [xx/xx/xx] ......................37 System Time [xx:xx:xx] .......................37 ACPI Sleep State [S1 (CPU Stop Clock)] ................38 ... -
Page 87: C Watchdog Timer
IDS-200-A70Mi Digital Signage Player Appendix Watchdog Timer Page 75... - Page 88 IDS-200-A70Mi Digital Signage Player NOTE: The following discussion applies to DOS environment. IEI support is contacted or the IEI website visited for specific drivers for more sophisticated operating systems, e.g., Windows and Linux. The Watchdog Timer is provided to ensure that standalone systems can always recover from catastrophic conditions that cause the CPU to crash.
- Page 89 IDS-200-A70Mi Digital Signage Player NOTE: When exiting a program it is necessary to disable the Watchdog Timer, otherwise the system resets. Example program: ; INITIAL TIMER PERIOD COUNTER W_LOOP: AX, 6F02H ;setting the time-out value BL, 30 ;time-out value is 48 seconds ;...
