Using the power override wire
If your keypad does not respond, don't be alarmed. Most likely
the batteries are dead and need replacing.
You will be able to open the safe using the power override wire
as follow:
1. Take a 9V battery and plug it in the
power override wire connector as
shown in fig.5
2. Locate the connector under the
keypad and plug it in snugly,
making sure that the two prongs
go into the two tiny holes. See
fig.4
The battery override
feature is used to
Two Prongs
give power to the
lock from the outside
of the safe when the
internal batteries are
dead.
3. While the battery is plugged in, go a head
and enter your 6 digit code as you normally
would and open the safe.
4. Now you can replace the batteries inside
the safe by referring to the previous page
in this manual.
TIPS:
Plug the override wire to the keypad with red wire
to the right.
The override wire is only to be used in an emergency
when the internal batteries die or very low.
Unplug the override wire after replacing the internal
batteries.
NEVER LOCK THE OVERRIDE WIRE INSIDE THE SAFE
http://www.monomachines.com/
fig.4
fig.5
For More Info
-5-
Click Here - - ->
LED Interior Light System (Optional)
You may have purchased your safe with an optional LED interior light
system installed.
The LED interior light will go on for 30 seconds after the safe is opened.
You can toggle the light ON and OFF by pressing the # key during those 30 seconds.
The power for LED light system is coming from the same batteries that power
the keypad lock.
Since it's a very low power consumption light system, it will not drain the batteries
any faster then it would without the light.
It is best to shut off the light after closing the door by pressing the # key once.
The blue LED light on the keypad will stay "on" when the interior light is "on".
Adjusting the shelves:
The safe model you purchased may include
adjustable velvet shelves.
These shelves may be adjusted to various heights,
by changing the position of the lower shelf clip on
the side rails, see fig.6
You may dispose of the top (90 degree angle) clip
as it is used for shipping purposes only.
(Okay to dispose)
Lower shelf clip,
used to hold the shelf
Top clip
fig.6
