- Page 1 SmartHome Security System Installation and Operating Instructions Version 1 Please read these instructions carefully before using these products and keep the manual for future reference.
-
Page 2: Table Of Contents
Contents Safety Notices ....................4 System Components..................7 Introduction....................9 Using the Power Switch sensor as a signal repeater.......14 Getting Started....................15 Download the Android version of the Smart-i Protect App......15 Download the iOS version of the Smart-i Protect App........15 1. Connect the SmartBox to the Internet..........16 2. - Page 3 Installing the Cube Camera................30 Installing the Pan Tilt Camera..............31 Installing the Indoor/Outdoor Bullet Camera...........32 How to install the Accessories..............33 1. Installing the PIR Sensor................33 2. Installing the Door/Window Contact.............34 3. Installing the Siren..................36 App Operation.....................37 Status Page Diagram..................37 1. Status Indicator/Edit................38 2.
-
Page 4: Safety Notices
IMPORTANT SAFETY NOTICE This information can help you safely use your security system. Follow and retain all information included with your system. Customer safety is important. Our products are developed to be safe and effective. However, the SmartBox, Accessories and Cameras are electronic devices. Power leads, power adapters, and other features can create potential safety risks that can result in physical injury or property damage, especially if misused. - Page 5 The cords and cables supplied with the system can present a potential strangulation hazard if the child plays with the cords or cables and it becomes wrapped around the neck. Please make sure cords and cables are placed out of reach of the child. Conditions that require immediate action Products can become damaged due to misuse or neglect.
- Page 6 In the unlikely event that you notice any of the following conditions, or if you have any safety concerns with your product, stop using the product and unplug it from the power source and telecommunication lines until you can speak to the Customer Support Team on 0871 222 1430 for further guidance.
-
Page 7: System Components
System Components DO NOT REMOVE THE INSULATING PLASTIC on the sensors. It will activate the pairing process. Please follow the sections below for easy installation. If you have already removed the insulating plastic tab, please refer to the section "If you need to pair the sensor again:" to add sensor(s) to the system. - Page 8 Wireless PIR Sensor SHDP 3x AA Batteries 1.5V Sticky Pad Set Wall Mount Set Bracket Wireless Power Control Socket and No Accessories Repeater SHP100R Wireless Door/ Window Contact 1x CR2032 Battery Sticky Pad Set SHDM Wireless Indoor Siren SHS100 Adaptor DC 5V/1A Bracket Wireless Remote...
-
Page 9: Introduction
Introduction The Smart-i SmartHome Security System is an expendable and extendable security system that combines power management to make your life more secure and energy efficient. You can scale up the coverage at anytime by implementing additional sensor(s) and/or camera(s). - Page 10 WiFi HD Offers day/night on-site/remote live-view (visual verification) and video Indoor Pan recording and storage (MicroSD 32GB, not included). The camera also Tilt Camera has motion detection with embedded video image analyser for maximum protection. WiFi HD Offers day/night on-site/remote live-view (visual verification) and video Indoor/ recording and storage (MicroSD 32GB, not included).
- Page 11 Wireless Installed on to door/window. After the system is armed the Door/Window Door/ Sensor can alert the system the door/window has been opened Window and activate On/Off Switch (turning on light), Siren (alert sound) and Contact Camera (view/record). Wireless The Siren can be controlled via Smart-i Protect App and Panic Remote Indoor Siren (activate/deactivate) or triggered by other devices such as Camera, Door/ Window Sensor and Motion Sensor.
- Page 12 The diagram below shows the suggested location(s) for SmartHome Security System. Use this as a guide for your installation. The system is extendable and expandable with additional Power Control Indoor/Outdoor Camera Remote Control Adaptor DC 5V/1.5A Battery CR2032 PIR Sensor SmartBox Battery AA 1.5V x 3...
- Page 13 compatible Wireless Cameras, Motion Sensors, Door/Window Contact sensor, Siren and other sensors for greater protection. Indoor Pan Tilt Camera Adaptor DC 5V/1.5A Indoor Siren Adaptor DC 5V/1A Indoor Cube Battery AA 1.5V x 4 Camera Door/Window Adaptor DC 5V/1.5A Sensor Battery CR2032...
-
Page 14: Using The Power Switch Sensor As A Signal Repeater
Using the Power Control Socket as a Signal Repeater In some cases, pre-existing environmental factors may affect the performance of the wireless communication between the SmartBox and sensors, such as: - Numbers of walls between the SmartBox and the Sensor(s) - Materials of the building structure - Interference from unknown source When encountering such situation, you can use the Power Control Socket... -
Page 15: Getting Started
Getting Started The sensor(s) require sufficient battery power enable a successful pairing process and normal operation afterwords. If you cannot pair the sensor(s) to the SmartBox or operate control command, please first replace the battery supplied with a new one to resolve the issue. Download the Android version of the Smart-i Protect App Please go to the Google Play to search for 'Smart-i Protect' and install the app to your mobile device. -
Page 16: Connect The Smartbox To The Internet
1. Connect the SmartBox to the Internet (1) First connect the SmartBox to your Wi-Fi router via the Ethernet cable supplied, then power on the SmartBox by using the power adaptor supplied . (2) The RED LED indicator will light up and beep twice to indicate successful power up. Seconds later the SmartBox will again beep twice to indicate it is ready for setup via the 'Smart-i Protect' App. - Page 17 (3) Launch the 'Smart-i Protect' App. The App will first search for the SmartBox connected to the home Wi-Fi router and retrieve the DID automatically. Please assign the SmartBox with your preferred System Name and enter the Default Security Code '123456', tap to complete the setup. If the SmartBox DID/Security Code cannot be retrieved, please check to make sure it is powered on and the Ethernet cable is securely connected to the Wi-Fi router.
-
Page 18: Setup The Cameras
2. Setup the Cameras NOTE: You can ONLY setup camera(s) compatible with the system. If you have previously purchased and installed compatible camera(s), you will only need to complete steps (3) and (4) for your existing camera to work with the new system. (1) First connect the camera to the Wi-Fi router via the Ethernet cable supplied. - Page 19 NOTE: DO NOT begin the App setup process until both LEDs become steady on the camera. (3) Using 'Smart-i Protect', tap in the 'Status' section and choose to add a new camera to the SmartBox. The app will now search for the camera connected to the router and pull in the camera DID.
- Page 20 (4) Please now name your camera and specify the location of where the camera will be installed. The camera default Security Code is '123456' (previously installed camera may have been assigned with different security code). Tap 'Save' to complete pairing the camera to the SmartBox. NOTE: (1) The app will first search for the available camera connected to the Wi-Fi router.
- Page 21 (6) For the camera to work wirelessly with the SmartBox, you Status will need to add your router’s WiFi details to the camera: Go to Gi7-351 GO1-D-038 ,tap on upper right and select to enter camera on Table Room info, on the camera you want to connect to your router’s WiFi. Siren PowerSwitch In the camera info section, tap and enter the camera password...
-
Page 22: Pairing The Pir Sensor
3. Pair the Motion Sensor (1) Using 'Smart-i Protect', tap in the 'Status' section. (2) Choose 'Motion Sensor' and to initiate the pairing process. Select Device Step 1 of 3 Status Gi7-351 GO1-D-038 Please tap “Pair” to begin pairing Camera process on Table Room... -
Page 23: Pairing The Power On/Off Switch
(4) Enter 'Device Name' and 'Location', tap 'Save' to complete the pairing process. The newly paired sensor will now display in the App's 'Status' section. Verifying the Setup After pairing is complete, face the motion sensor towards a wall where no movement can be detected, wait for few minutes for the sensor to complete condition analysis. - Page 24 Select Device Step 1 of 3 Status Gi7-351 GO1-D-038 Please tap “Pair” to begin pairing Camera process on Table Room Siren Siren PowerSwitch Remote Key Hallway Book Room Door Sensor Door Sensor Back Door Lounge Motion Sensor Power Switch Remote Key Power Switch Status Scenario...
-
Page 25: Pairing The Door/Window Sensor
(4) Enter 'Device Name' and 'Location', tap 'Save' to complete the pairing process. The newly paired power control socket will now display in the App's 'Status' section. Verifying the Setup After pairing is complete, plug the power switch into an electrical socket and connect a light or lamp to the switch. - Page 26 Select Device Step 1 of 3 Status Gi7-351 GO1-D-038 Please tap “Pair” to begin pairing Camera process on Table Room Siren Siren PowerSwitch Remote Key Hallway Book Room Door Sensor Door Sensor Back Door Lounge Motion Sensor Remote Key Power Switch Status Scenario Event...
-
Page 27: Pairing The Indoor Siren
6. Pair the Indoor Siren (1) Using 'Smart-i Protect', tap in the 'Status' section. (2) Choose 'Siren' and to initiate the pairing process. Status Select Device Step 1 of 3 Gi7-351 GO1-D-038 Please tap “Pair” to begin pairing Camera process on Table Room Siren... -
Page 28: Pairing The Remote Key
(4) Enter 'Device Name' and 'Location', tap 'Save' to complete the pairing process. The newly paired siren will now display in the App's 'Status' section. Verifying the Setup From the 'Status' section, tap the Siren icon and turn the Siren's alert sound On and Off. 7. - Page 29 (3A) Auto Pairing Method (3B) Manual Pairing Method Remove the insulating Press and hold the 'Camera' plastic tab to start the button on the front of the pairing signal. Remote Key until the blue LED begins flashing. Verifying the Setup Press the 'Disarm' button the SmartBox will beep once indicating the system has been disarmed.
-
Page 30: How To Install The Cameras
How to install the Cameras SAFETY AND INSTALLATION TIPS Do not attempt to open the units with the power adaptor plug connected to avoid any risk of personal injury. When installing CCTV camera(s), always follow manufacturer's advice when using power tools, steps, ladders, etc. and wear suitable protective equipment (e.g. safety goggles) when drilling holes. -
Page 31: Installing The Pan Tilt Camera
Installing the Pan Tilt Camera (1) Place the camera on a level surface away from obstacles or potential hazards. (2) Attach the Antenna and plug the power supply into the back of the camera. -
Page 32: Installing The Indoor/Outdoor Bullet Camera
Installing the Indoor/Outdoor Bullet Camera (1) Secure the camera stand on a level surface or wall mount using screws provided. (2) Attach the Antenna and plug the power supply into the back of the camera. (3) Mount the camera on to camera bracket. Adjust the viewing angle and fix the camera tightly. -
Page 33: How To Install The Accessories
How to install the Accessories Installing the PIR Sensor Please read the following items before installation to ensure maximum coverage of a monitored area. (1) The PIR Sensor is most effective in areas such as hallways and entry points where intruders may likely passing through. (2) The PIR Sensor can monitor movement up to 16 metres away, with 110 degrees detection angle. -
Page 34: Installing The Door/Window Contact
The thick double-sided tapes are The thin double-sided tapes are for corner install use. Mounting Option A Mounting Option B/C Installing the Door/Window Contact Mounting Option A - Double-Sided Tape (1) Apply the double-sided tape to the back of each part of the Door/Window sensor. - Page 35 (2) Select a location on the door/window. The large piece of the sensor should be fixed on the immovable frame of the door/window. Align the small piece to the large one. Fix the small piece on the movable part of the door/window frame.
-
Page 36: Installing The Siren
Installing the Siren It is recommended to install the siren in a highly visible location with minimum obstacles near by for maximum visual/sound alert. If using the A/C power option (as opposed to batteries) please select suitable installation location within easy reach of an electrical socket. Secure to wall using bracket and fixing screws. -
Page 37: App Operation
App Operation Upon selecting the SmartBox you will enter 'Status' section. In this section you can have an overview of all the cameras/sensors connected to the system and the real-time status of each, also you can carry out many important functions, such as arm/part-arm/disarm system, add/edit devices, view live-feed from cameras, control power switches, activate sirens. -
Page 38: Status Indicator/Edit
1. Status Indicator / Edit The App displays device status Status Door/Window Close Gi7-351 GO1-D-038 using sharp contrast icons so Door/Window Open Status on Table Room you can clearly interpret and Sensor On react to the situation/event. Status Indicator Sensor Off Siren PowerSwitch Sensor Triggered... - Page 39 Control Camera No SIM 11.34 appcam 25 Camera Control driveway Tap on the Camera icon for live-view and to control Snapshot Camera Live-View Camera/Sensor(s). Speaker Note: For Pan Tilt swipe left Record PowerSwitch Sensor and right to move camera. Preset View-Points Control Siren Microphone...
-
Page 40: Scenario
Control Remote Tap on remote icon to activate in-app remote Remote System Arm Camera Record System Disarm Panic Lounge See 'Scenario' section for more detail 2. Scenario Scenario Scenario One-touch scenario Camera Panic Motion Sensor Living room Sequence scenario Wireless Camera Front Door Status Scenario... - Page 41 Both the 'One-touch Scenario' and the 'Sequence Scenario' are designed for your system to carry out customised security functions after setup, such as activate single/multiple cameras and sensors for recording and alert. One-touch Scenario Allowing you to conveniently activate the security function with a single touch when required. The one-touch scenario section has three default controls and they connect with the control buttons on the remote controller.
- Page 42 (a) Arm/Part-Arm/Disarm: Arm or Part-Arm preselected camera(s) and sensor(s). Select Disarm to disable system's Arm or Part-Arm status. Only after you have armed the system you will be able to receive Email/Push Notifications (see System Setting/Notifications Setup for detail). You will have 30 seconds to exit the premise after initiating the Arm or Part-Arm function. (b) Camera: Activate selected camera(s) for sudden recording needs.
- Page 43 1. Tap to activate the edit mode. 2. Tap the one-touch scenario you wish to edit. 3. Rename the one-touch scenario if you wish to do so. Check mark the items you wish to include for Arm/Part-Arm, Camera and Panic scenario. Only the items selected will be activated. 4.
- Page 44 Sequence Scenario Allowing the system to automatically react to the sudden situation and carry out other predefined tasks. For example, once the motion sensor is activated, the camera will begin recording and the light turns on. To setup the sequence scenario(s), please go to the Scenario section and follow the steps below: 1.
- Page 45 (b). Click the ' Add ' icon to add corresponding sensor. This means when the PIR motion sensor is triggered, these actions will also be performed. For example, if you want the camera to record, click the ' Add ' icon and choose wireless camera from the list (MicroSD card required, not supplied).
- Page 46 How to activate/deactivate the scenario: Go to the Scenario setup page and tap 'On' to activate the selected sequence scenario, or 'Off' to deactivate it. Scenario Setup When... Door Sensor Back Door Then... The system will take about 10 seconds to be fully ready to deploy the scenario application after activating the scenario.
-
Page 47: Event List
3. Event List Events Power Switch Power Switch Power Switch Power Switch All triggered events are recorded and displayed here in the 'Event' section. You will be able to identify exactly which sensor was triggered, including the time and the date. You can also review recorded video file by tapping on the camera trigger event.* *Camera must have MicroSD card fitted, not supplied. -
Page 48: Settings
4. Settings The system settings contain various options allowing you to setup/configure the system details. The default admin password is '123456'. Setting 123456 NOTE: Only the user who has the admin password can alter the system settings. Please change the default password immediately and make a note for future reference. - Page 49 IP Setup Setup the Internet protocol settings for the system. XXX.XXX.XXX.XX XXX.XXX.XXX.X XXX.XXX.XXX.XXX...
-
Page 50: Security Setup
Security Setup Here you can alter the system's default 'Security Code' and 'Admin Password'. Also you can enable/disable and setup the PIN Lock for the app. Once setup and enabled, you will need to enter the PIN Lock code every time you open the App. -
Page 51: Notification Setup
Notification Setup Here you can turn On/Off the Email Alert and Push Notification. For the Email Alert to function properly you will need to enter an effective email address. Both Email/Push Notification are available for system Arm, Disarm and trigger events generated from camera, motion sensor and door/window sensor selected in the Arm/Disarm scenario section. -
Page 52: Schedule Setup
Schedule Setup This is designed specifically for the power switch. After you have setup the selected power switch(s) can turn on/off accordingly. Please follow the steps below to complete setup: 1. From the list, tap the switch you wish to setup. 2. - Page 53 For Power Switch, you can also select Random On/Off. This is good for creating "someone is home" scenario to deter possible intruders. NOTE: Since the system automatically synchronises its clock with Network Time Protocol (NTP) via the Internet therefore the Protect schedule setup will not operate normally if the system is not connected to the Internet.
-
Page 54: Firmware Updates
Firmware Updates Here you can check to see if any new updates are available. To begin, tap on 'Download' and if a new update is available, the popup screen will ask you if you wish to proceed, select 'Yes' and the Smart-i Protect app will automatically download and install the new update. - Page 55 Remote Style The 'Remote Control' mode is designed for easy operation. The control functions are the same as the 'One-touch Scenario' and the remote controller. Once you have activated the function, next time you start the Smart-i Protect App or go back to the Home screen it will only display the 'Remote Control'.
- Page 56 Advance Control Here you can turn on the 'Zone' function. This function is for advanced users only. The 'Zone' function can control camera(s) and power switch(s) and can be activated/deactivated with one single touch. You can have up to 9 Zone controls, with each customised to fit your needs. To activate the 'Zone' function, please follow the steps below: 1.
- Page 57 About The system ID (DID), firmware and App information. To setup the 'Zone' control, please go to 'Zone' section follow the steps below to complete the setup. 1. Tap to begin. 2. You can personalise the Zone name. 3. Check mark the camera(s) and/or power switch(s) you wish to include for control. 4.
-
Page 58: Another Useful Feature
Another useful feature Using the Power Switch as Repeater - Repeater Setup To Activate the Repeater Function of your Power Switch First make sure the Power Switch and the end Sensor have been successfully paired/connected to the SmartBox. See "Sensor Pairing" section for more detail. Step 1 - Press/hold the button located on the front of the Power Switch until the LED begins to flash in blue and orange. - Page 59 To Deactivate the Repeater Mode 1. Unplug the repeater Power Switch. 2. Press and hold the button in front of the switch and plug the switch back to the socket with the button pressed, do not let go of the button until the LED begins to flash (Blue). The LED indicator on the repeater Power Switch now should light up in Blue, indicating the repeater function has been deactivated.
-
Page 60: Troubleshooting
Troubleshooting Problem Possible Cause The SmartBox is not - Check the DC power adapter. Make sure it is correctly plugged in. working - Check the Ethernet cable. Make sure the connector is plugged into the Ethernet socket and the other end plugged into the router. The sensor is not - Check the battery polarity and make sure the battery has enough functioning... - Page 61 If the Green LED becomes STEADY GREEN instead of flashing, it means the network connection has failed. Please make sure the router is functioning properly, re-connect the Ethernet cable and power on the SmartBox again. What should I do if I - Press the Reset button on your router.
-
Page 62: Product Specifications
Product Specifications SmartBox Model Number SHG100 Operation Voltage DC 12V/1A Ethernet 10/100Mbps Signal Frequency 868.3 MHz Battery Backup Built-in (Up to 8 hours) Operating Environment Indoor Dimensions (WxHxD) 167 x 37.37 x 130mm WiFi HD Cube Camera with PIR Model Number SHC100 Wireless Compatible IEEE 802.11 b/g/n... - Page 63 Image Resolution HD 1280 x 720 Lens HD Wide Angle IR Distance 10 metres Power Source DC-in 5V/1.5A Operating Temp. -10°~50°C Operating Humidity 20~80% RH (none-condensing) Operating Environment Indoor Dimensions (WxHxD) 63 x 103 x 38mm WiFi HD Indoor Pan Tilt Camera Model Number SHC200 Wireless Compatible...
- Page 64 Power Source DC-in 5V/1.5A Operating Temp. -10°~50°C Operating Humidity 20~90% RH (none-condensing) Operating Environment Indoor Dimensions (WxHxD) 91.76 x 118 x 100.30mm WiFi HD Indoor/Outdoor Bullet Camera with PIR Model Number SHC300 Wireless Compatible IEEE 802.11 b/g/n Sensor Mega Pixel CMOS Frequency 2400MHz~2485MHz Protocol...
- Page 65 Wireless PIR Sensor Model Number SHDP Signal Frequency 868.3 MHz RF Range 150M (open field conditions) Max. Detection Range Detection Angle 110° Battery Type 3 x 1.5V AA Batteries (included) Battery Life Estimated up to 2 years (Based on 200 triggers per day) Low Battery Warning Yes (LED warning light and in App) Tamper Detection...
-
Page 66: Wireless Remote Control
Battery Life Estimated up to 2 years (Based on 10 triggers per day) Low Battery Warning Yes (LED warning light and in App) Tamper Detection Operating Temp. 0°~40°C Operating Humidity 10%~80%RH Operating Environment Indoor Dimensions (WxHxD) Large piece: 27 x 71 x 14mm Small piece: 13 x 71 x 13mm Wireless Remote Control Model Number... - Page 67 Wireless Power Control Socket and Repeater Model Number SHP100R Signal Frequency 868.3 MHz RF Range 150M (open field conditions) Plug Type Load Switch Capability 3000W Power Source 240V AC Operating Temp. 0°~40°C Operating Humidity 10%~80%RH Operating Environment Indoor Dimensions (WxHxD) 59.2 x 100.2 x 31.5mm Wireless Indoor Siren Model Number...
- Page 68 Tamper Detection Operating Temp. -10°~50°C Operating Humidity 10%~80%RH Operating Environment Indoor Dimensions (WxHxD) 80 x 120 x 35mm...
- Page 70 TECHNICAL SUPPORT For technical support, please contact your local distributor. Alternatively, call 0871 222 1430 Manufactured exclusively for: Smart-i UK, Unit 2 Valley Point, Beddington Farm Road, Croydon, Surrey CR0 4WP...
