- Page 1 Gas Stock Pot Burners Item # 37525, 37529 Instruction Manual Version 2 3115 Pepper Mill Court, Mississauga, ON, L5L 4X5 1-800-465-0234 4450 Witmer Industrial Estates, Unit 4, Niagara Falls, NY, 14305 www.omcan.com...
-
Page 2: Table Of Contents
Table of Contents Item # 37525 / Item # 37529 Section Page General Information -------------------------------------------------------------------------------- 3 Safety & Warranty ------------------------------------------------------------------------------ 3 - 4 Technical Specifications ---------------------------------------------------------------------- 4 - 5 Installation --------------------------------------------------------------------------------------- 5 - 7 Operation --------------------------------------------------------------------------------------------- 7 Maintenance ------------------------------------------------------------------------------------- 7 - 8 Instructions for Field Conversion between LP &... -
Page 3: General Information
If the package has suffered rough handling, bumps or damage (visible or concealed), please note it on the bill of lading before accepting the delivery and contact Omcan within 24 hours, so we may initiate a claim with the carrier. A detailed report on the extent of the damage caused to the machine must be filled out within three days, from the delivery date shown in the shipping documents. -
Page 4: Technical Specifications
Safety & Warranty use a telephone within close proximity. • Never attempt to move grate while cooking. 1 YEAR WARRANTY WARNING: The packaging components are classified as normal solid urban waste and can therefore be disposed of without difficulty. In any case, for suitable recycling, we suggest disposing of the products separately (differentiated waste) according to the current norms. -
Page 5: Installation
These kinds of gas stoves can be operated by LPG or Natural gas. You may replace the nozzles. But please contact Omcan for details of diameter of nozzles. The nozzles are included with the stove or can be ordered from manufacturer. The slightest difference in diameter would influence the performance of the burners. - Page 6 Installation PRESSURE REGULATOR • All commercial cooking equipment must have a pressure regulator on the incoming service line for safe and efficient operation. The regulator provided for this equipment is adaptable for both Natural gas and LP gas. • Regulator specifications: ¾” NPT inlet and outlet, factory adjusted for 5” WC Natural Gas standard and may be converted by qualified personnel to be used for Propane at 10”...
-
Page 7: Operation
Installation PILOT FLAME REGULATION • The pilot flame on the equipment has been factory adjusted. When adjustment is necessary, adjust the pilot flames as small as possible but high enough to light the burner. Immediately after, turn the burner valve to the highest setting. - Page 8 Maintenance equipment with steel wool. 1. Allow the equipment to cool completely before cleaning. 2. Using a wire brush, scrape the grill grate(s) to remove any food residue. 3. To clean equipment, use either a damp cloth, sponge with soapy water or a metal scraper. 4.
-
Page 9: Instructions For Field Conversion Between Lp & Ng
Instructions for Field Conversion between LP & NG GAS CONVERSION OF STOCK POT BURNER • Conversion from Natural Gas to Liquid Propane (LP) or vice versa may only be performed by the factory or its authorized service agent. In case of troubleshooting, ensure the correct orifice sizes of the spuds have been provided. - Page 10 Instructions for Field Conversion between LP & NG CAUTION: ENSURE THE GAS SUPPLY IS SHUT OFF AT THE MANUAL SHUT OFF VALVE BEFORE PROCEEDING WITH THE CONVERSION. 1. Switch off the gas at the main supply valve and allow the unit to cool down before commencing with the conversion.
- Page 11 Instructions for Field Conversion between LP & NG Fig 4. Gas Pressure Regulator Fig 5. Conversion Setting the pilot burner: When changing from natural gas to LPG it is necessary to adjust the pilot burner flame as well. This is done in the following steps: 1.
-
Page 12: Parts Breakdown
Parts Breakdown Model TH-RB-1 37525... - Page 13 Parts Breakdown Model TH-RB-1 37525 Description Position Description Position Description Position Front Panel Burner Supporter Gas Pilot Pipe Body Sides Pilot Igniter Gas Pilot Valve Top Grates Pilot Supporter Adjustable Feet Support Gas Valve Body Back Lower Body Panel Join Part...
- Page 14 Parts Breakdown Model TH-RB-2A 37529...
- Page 15 Parts Breakdown Model TH-RB-2A 37529 Description Position Description Position Description Position Body Sides Connection Pipe-Short Nozzle Supporter Drip Pan Rail Gas Pipe Burner Supporter Front Panel Nozzle Join Part B Pilot Supporter Gas Pipe Holder Join Part M16 x 1.25 Nut with Dia 10 Body Sides Support Connection Pipe-Long Drip Pan...
-
Page 17: Warranty Registration
Warranty Registration Thank you for purchasing an Omcan product. To register your warranty for this product, complete the information below, tear off the card at the perforation and then send to the address specified below. You can also register online by visiting: www.omcan.com/warrantyregistration.html... - Page 20 Over the last 60 years, Omcan has grown to become a leading supplier to the food service industry in Canada and the USA. Our success over these many years is directly attributed to our established relationships with all of our valued customers and through providing them with Diverse, Dependable and Proven products.
