Operating Instructions
LCD Television
Thank you for purchasing this Panasonic product.
Please read these instructions carefully before operating this product and retain them
for future reference.
Please carefully read the "Safety Precautions" of this manual before use.
The images shown in this manual are for illustrative purposes only.
M0215-0
For more detailed instructions, please refer to
[eHELP] (Built-in Operating Instructions).
●
How to use [eHELP]
Model No.
TX-40CX680B
TX-50CX680B
TX-55CX680B
(p. 15)
TQB0E2531U
English
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Panasonic Viera TX-40CX680B
Summary of Contents for Panasonic Viera TX-40CX680B
-
Page 1: Operating Instructions
● How to use [eHELP] (p. 15) Thank you for purchasing this Panasonic product. Please read these instructions carefully before operating this product and retain them for future reference. Please carefully read the “Safety Precautions” of this manual before use. -
Page 2: Quick Start Guide
● For information about the trademarks, refer to [eHELP] (Support > Licence). Contents Be Sure to Read Important Notice 3 Safety Precautions 3 Quick Start Guide Accessories 6 Connections 8 Identifying Controls 12 First time Auto Setup 14 Using your VIERA Watching TV15 How to Use eHELP 15... -
Page 3: Important Notice
IMPORTANT: http://panasonic.net/viera/support THE MOULDED MAINS PLUG FOR YOUR SAFETY, PLEASE READ THE Panasonic does not guarantee operation and FOLLOWING TEXT CAREFULLY. performance of peripheral devices made by other This TV is supplied with a moulded 3-pin mains plug manufacturers; and we disclaim any liability or damage for your safety and convenience. - Page 4 ● Do not use an unapproved pedestal / mounting accidents due to malfunction. equipment. Be sure to ask your local Panasonic dealer to perform the setup or installation of approved ● Do not use the TV near any automatic control wall-hanging brackets.
- Page 5 Minimum distance: Declaration of Conformity (DoC) “Hereby, Panasonic Corporation declares that this TV is in compliance with the essential requirements and other (cm) relevant provisions of the Directive 1999/5/EC.”...
-
Page 6: Assembling The Pedestal
Accessories Assembling / Removing the pedestal 40-inch model Assembly screw (4) Remote Control (p. 12) M5 × 10 ● N2QAYB001010 Assembly screw (4) M4 × 12 Pedestal Bracket (2) 40-inch model (p. 6) Base 50-inch model 55-inch model ■ Assembling the pedestal Mains lead (p. -
Page 7: Assembling The Pedestal
Base 50-inch model 55-inch model ■ Assembling the pedestal 50-inch model 55-inch model Assembly screw (4) M5 × 15 Assembly screw (4) M4 × 12 Bracket (2) English... - Page 8 Connections ● External equipment and cables shown are not supplied with this TV. ● Please ensure that the unit is disconnected from the mains socket before attaching or disconnecting any cables. ● Check the terminal type and cable plugs are correct for connection.
- Page 9 9 DIGITAL AUDIO AV devices 10 HDMI1 - 2 (p. 9, 10) ■ DVD Recorder / VCR ● To watch content in 4K format, use HDMI terminal. (p. 10) Basic connections ■ Mains lead AC 220-240 V 50 / 60 Hz Mains lead (supplied) Insert the mains plug firmly into place.
-
Page 10: Wired Connection
Network Other connections ■ DVD Player A broadband network environment is required to be able to use internet services. (COMPONENT equipment) ● If you do not have any broadband network services, please consult your retailer for assistance. ● Prepare the internet environment for wired connection or wireless connection. -
Page 11: Common Interface
HDMI cable Amplifier with speaker system External equipment (DVD Player, etc.) ■ Headphones ● For information about the volume settings, refer to [eHELP] (Settings > Sound). (M3 stereo mini plug) ■ Common Interface ● Turn the TV off with Mains Power On / Off switch whenever inserting or removing the CI module. -
Page 12: Identifying Controls
Identifying Controls 8 [Option Menu] ● Easy optional setting for viewing, sound, etc. 9 Coloured buttons (red-green-yellow-blue) ● Used for the selection, navigation and operation of Remote Control various functions. 10 Volume Up / Down 11 Numeric buttons ● Changes channel and teletext pages. ●... - Page 13 ■ Installing / Removing batteries 6 Volume Up / Down ● Cursor Left / Right (when in the menu system) 7 Mains power On / Off switch Pull open ● Use to switch the mains power. Hook Close Note the correct polarity (+ or -) Indicator / Control panel ●...
-
Page 14: First Time Auto Setup
First time Auto Setup If tuning has failed check the RF cable, and the network connection, and then follow the on-screen instructions. Note ● The TV goes into Standby mode when no operation When the TV is turned on for the first time, it will is performed for 4 hours if [Auto Standby] in the Timer automatically search for available TV channels and give Menu is set to [On]. -
Page 15: How To Use Ehelp
Watching TV How to Use eHELP [eHELP] is the detailed operating instructions built into Turn power on the TV, and gives a more detailed explanation for a better understanding of the operation of each feature. (TV) Display [eHELP] (Remote Control) ●... - Page 16 Auto power standby function is activated. family member to show you how. Alternatively, go to your local electrical retailer, contact your local The remote control does not work or is intermittent Panasonic dealer or visit freeview.co.uk/retune ● Are the batteries installed correctly? (p. 13) Re-tuning only takes a few minutes, just follow the ●...
-
Page 17: Specifications
Maintenance Specifications ■ First, remove the mains plug from the mains socket. Model No. : TX-40CX680B Display panel, Cabinet, Pedestal 40-inch model : TX-50CX680B 50-inch model Regular care: : TX-55CX680B 55-inch model Gently wipe the surface of the display panel, cabinet, Dimensions (W ×... - Page 18 Receiving systems / Band name WPA-PSK (TKIP/AES) Check the latest information on the available services at WEP (64 bit/128 bit) the following website. http://panasonic.net/viera/support *: The frequency and channel differ depending on the country. DVB-T / T2 Note Digital terrestrial services ●...
-
Page 19: When Using Wall-Hanging Bracket
■ When using the wall-hanging bracket Please contact your local Panasonic dealer to purchase the recommended wall-hanging bracket. ● Holes for wall-hanging bracket installation Rear of the TV 40-inch model a: 200 mm b: 200 mm 50-inch model 55-inch model... - Page 20 • Or go on line through our Internet Accessory ordering application at www.pas-europe.com. • Most major credit and debit cards accepted. • All enquiries transactions and distribution facilities are provided directly by Panasonic UK. • It couldn’t be simpler! • Also available through our Internet is direct shopping for a wide range of finished products. Take a browse on our website for further details.
