Summary of Contents for Leaf NP-100
- Page 1 Network Digital Signage Player NP-100 User Guide User Guide 1/22/2013...
- Page 2 Connect audio cable (Red and White) to TV’s audio port. (no need this if HDMI output) e) Connect Ethernet cable to NP-100’s LAN port and the other end to router’s LAN port Plug in 12V AC power adapter (do not use other voltage) g) Turn on power and wait for server connection.
- Page 3 Desktop Status: 1. Top Row: a. Stop: shows current player’s status (Stop, Play, Downloading…) b. Status: shows current playlist’s status (OK and error messages) 2. Bottom Row a. Storage: shows selected storage device(Internal Disk/SD/USB) and its memory usage. b. Date: shows local time and date c.
- Page 4 Setup Main Menu: (Press “Main Menu” key of remote control) Key Operation Navigation keys: only 4 arrow keys and middle key (orange color) are used to navigate all settings Middle key (ENTER): pop up selection menu or go to sub-menu or action on cursor highlight text 1.
- Page 5 a. Clock Display : HH:MM on the playback screen location i. Top Left ii. Bottom Left iii. Top Right iv. Bottom Right v. Off : Disable clock display b. Storage Priority : Decide which device to use for playback/download i. Auto : Start from USB =>...
- Page 6 c. Device Address : Setup either DHCP or Static IP 3. Date & Time a. Year/Month/Day/Hour/Minute : use 0-9 number keys or cursor up/down to adjust and : use cursor left/right to move to next field b. Date Format : MM/DD/YYYY, DD/MM/YYYY, or YYYY/MM/DD c.
- Page 7 4. Screen Mode (must save & reboot after change mode, also icat3 must use right template) a. Landscape : Landscape mode b. Portrait : Portrait mode 5. Factory Default : Restore all settings to default values 6. Save & Reboot : All settings will be saved and reboot from power-up 7.
- Page 8 ICAT-3 web address: http://np.miatek.com To support all the new features (1080P HD video and resizable multi-zone) of NP-100, icat-3 has new user interface and operation. Below is user guide how to use it. Account: You will receive user ID and password from your reseller. Normally ID and password are same. You can change your password under “Account”...
- Page 9 Step 1: Create Group Click on , a new group edit window will appear below (left). Just enter group name and save. Download Time is to setup when to download content for this group’s players. You can leave it blank. Player will download new content any time as long as a new playlist/schedule is published.
- Page 10 associated with this player for future operation. Just enter these 10 digits on player’s setup under “Device” page. Enter number key 1 6 1 3 4 4 2 6 7 7. And use arrow keys to move field. Step 3: Upload media content 3 types of content can be uploaded to server and saved in the media library for future use.
- Page 11 Step 4: Create Template NP-100 supports multiple zones screen including 1 video zone and 3 image zones. Weather zone and Time/date zone are OSD (On Screen Display) that can be overlapped on any video and image zone or wallpaper. Template is the screen layout for defining each zone’s size and position. icat-3 provides standard system template and custom template.
- Page 12 You first decide your screen mode either landscape (1920 x 1080) or portrait (1080 x 1920) then save. A blank template will appear. The Icons on top row are wallpaper, video zone, image1/2/3 zone, RSS/Text, Date/Time and Weather zone. Wallpaper is a jpeg file that will occupy entire screen. So you can leave it empty for black screen or choose one jpeg only for your wallpaper picture.
- Page 13 Step 5: Create Playlist Playlist is a sequence of media files that are assigned to each zone. Click on to create a new playlist. Define your name of the playlist, then choose template (System or User) then save. Each zone Icon are on the top row.
- Page 14 Step 6: Create Schedule Schedule is to predefine a time range for selected playlists to playback. Player will playback according to the schedule/playlist. Click on to create a new schedule file. After enter “schedule name” and add. There are three things to enter here besides schedule name and description. 1).
- Page 15 Optional settings: Download Time Download Time is to define a time range when you want player to download content in the background during playback. Click on to create a new “Download Time”. After enter Name and set time range. If you plan to add more, just click on “+”...
- Page 16 Folder List: Optional Settings: FTP FTP is to let user create FTP server that can browse media files for playlist. Player will download FTP media files from FTP server instead of icat-3 server. But those ftp files are just for video zone, not for image zone. Click on to create a new “FTP”...
- Page 17 FTP files of the media library file list: - End - User Guide 1/22/2013...
