Solar Dual Coil Tank
Installation & Operation
Manual
Models: SDT/SET065 - 119
Solar Electric Tank
This manual must only be used by
WARNING
a qualified heating installer / service
technician. Read all instructions
before installing. Perform steps in
the order given. Failure to comply
could result in severe personal
injury, death, or substantial property
damage.
Save this manual for future reference.
SDT-SET-I-O Rev E
SET
Advertisement
Table of Contents
Summary of Contents for Squire SDT065
- Page 1 SDT-SET-I-O Rev E Installation & Operation Manual Models: SDT/SET065 - 119 CAUTION: The heat transfer medium must be water or other nontoxic fluid having a toxicity rating or class of 1, as listed in Clinical Toxicology of Commercial Products, 5th edition. The pressure of the heat transfer medium must be limited to a maximum of 30 PSIG by an...
-
Page 2: Table Of Contents
Contents HAZARD DEFINITIONS ............ 2 Install Drain Valve ............12 PLEASE READ BEFORE PROCEEDING ......3 Temperature and Pressure (T&P) Relief Valve ..12 1. GENERAL INFORMATION Table 4A - Minimum Relief Valve (AGA Rating) ... 13 Operating Restrictions ............4 5. -
Page 3: Please Read Before Proceeding
SDT/SET Installation & Operation Manual Please read before proceeding Installer – Read all instructions before Failure to adhere to the guidelines on this WARNING WARNING installing. Perform steps in the order given. page can result in severe personal injury, death, or substantial property damage. Have this indirect water heater serviced/ When servicing the indirect water heater –... -
Page 4: General Information
(in.) (in.) (LBS) 9 1/8 27 15/16 33 5/8 47 3/16 52 5/16 59 7/8 3. BOILER WATER IN SDT065 3 5/16 27 15/16 40 3/16 53 3/4 61 13/16 69 3/8 3 5/16 9 1/8 4. BOILER WATER OUT... -
Page 5: Pre-Installation
SDT/SET Installation & Operation Manual Pre-installation Locating the Tank The installation must conform to the instructions in this manual and all applicable local, state, provincial, and national codes, laws, regulations, and Choose a location for your water heater centralized to the ordinances. -
Page 6: Boiler Side Piping (Sdt Models)
SDT/SET Installation & Operation Manual Boiler Side Piping (SDT models) Multiple Tank Connections (Boiler Side) Figures 3-1 thru 3-4 show typical boiler side piping for several common situations. Regardless of which system is Multiple tank installations must be done in the “reverse-return” used it is imperative that the flow rates called for in Table manner. - Page 7 COIL SQ FT SQ FT COIL MODEL (FT / HD) (FT / HD) LENGTH CONN. LENGTH SURFACE SURFACE (FT) AREA AREA (IN) (FT) SDT065 41.5 13.5 0.61 1.57 3.53 6.27 1.03 2.31 6.41 SDT080 41.5 13.5 0.61 1.57 3.53 6.27 1.03...
- Page 8 TEMPERATURE / PRESSURE GAUGE DRAIN RECIRCULATION PUMP PRESSURE SOLUTION RELIEF VALVE SQUIRE CHECK VALVE BOILER DRAIN SOLAR GAS SUPPLY ( FIELD SUPPLY ) HEAT EXCHANGER AUXILIARY CATCH PAN Please note that these illustrations are meant to show system piping concept only, the installer is responsible NOTICE for all equipment and detailing required by local codes.
- Page 9 RECIRCULATION PUMP PRESSURE SOLUTION RELIEF VALVE CHECK VALVE BOILER SQUIRE DRAIN SOLAR HEAT GAS SUPPLY ( FIELD SUPPLY ) EXCHANGER AUXILIARY CATCH PAN Please note that these illustrations are meant to show system piping concept only, the installer is responsible NOTICE for all equipment and detailing required by local codes.
- Page 10 SDT/SET Installation & Operation Manual Boiler Side Piping (SDT models) Figure 3-3 Knight Boiler Primary / Secondary Piping Please note that these illustrations are meant to show system piping concept only, the installer is responsible NOTICE for all equipment and detailing required by local codes.
- Page 11 SOLAR UNION RECIRCULATION (TYPICAL) PUMP CHECK VALVE DRAIN TEMPERATURE/ KNIGHT (TYPICAL) SOLAR SQUIRE PRESSURE GAUGE SQUIRE PRESSURE BOILER HEAT DRAIN RELIEF VALVE EXCHANGER (FILED SUPPLIED) (TYPICAL) Please note that these illustrations are meant to show system piping concept only, the installer is responsible for NOTICE all equipment and detailing required by local codes.
-
Page 12: Domestic Side (Tank) Piping Basic Domestic Piping
SDT/SET Installation & Operation Manual Domestic Side (Tank) Piping Domestic Water Piping for Distant Fixtures Basic Domestic Piping In some cases the furthest fixture may be quite distant from the Figure 4-2 on page 15 shows typical domestic water piping for a tank. -
Page 13: Anti-Scald Valves (Mixing Valves)
SDT/SET Installation & Operation Manual Domestic Side (Tank) Piping (continued) Temperature & Pressure (T&P) Relief Valve Anti-scald Valves (Mixing Valves) For protection against excessive temperatures Anti-scald valves used with water heaters are also called WARNING and pressure, install temperature and tempering valves or mixing valves. -
Page 14: Temperature And Pressure (T&P) Relief Valve
SDT/SET Installation & Operation Manual Domestic Side (Tank) Piping Verify that combination Standard Installation NOTICE temperature and pressure relief valve • Install the T&P relief valve in the connection marked complies with local codes. If the “Relief Valve”. combination temperature and pressure relief valve does not comply with local T&P Relief Valve Discharge Piping codes, replace it with one that does. - Page 15 PUMP CHECK VALVE CHECK VALVE TO SOLAR TEMPERATURE / PRESSURE DRAIN GAUGE SQUIRE DRAIN SOLAR (TYPICAL) ( FIELD SUPPLY) HEAT EXCHANGER Please note that these illustrations are meant to show system piping concept only, the installer is responsible NOTICE for all equipment and detailing required by local codes.
-
Page 16: Wiring
SDT/SET Installation & Operation Manual Wiring Electrical Connection (Squire solar water heater with electric back up only -- SET models only) Tank must be full before the unit is turned on! The heating element will be damaged if energized for even WARNING a short period of time while tank is dry! Be sure to ground the water heater. - Page 17 SDT/SET Installation & Operation Manual Wiring (continued) Table 5A Wiring SET065-SET119 SET Wiring (Single Element) Model Volts / Phase Watts / AMPS Breaker Type *Wire Gage SET065 240 VAC / 1 Ph 4500 / 18.3 25 AMP / DPDT 12 ga. THHW SET080 240 VAC / 1 Ph 4500 / 18.3...
-
Page 18: Indirect Water Heater Sensor Setup (Knight Boiler)
SDT/SET Installation & Operation Manual Wiring Indirect Water Heater Sensor Setup (Knight Boiler) Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and CAUTION dangerous operation. The supplied sensor contains an Auto Reset High Limit (194°F). NOTICE Install tank sensor Connect tank sensor... -
Page 19: Indirect Water Heater Controlled Using Aquastat And Zone Circulator
SDT/SET Installation & Operation Manual Wiring (continued) Indirect Water Heater Controlled Using Aquastat and Zone Circulator / Valve Install Aquastat to tank. Aquastat control (TST20016) can be ordered from your local Lochinvar distributor. Connect Aquastat to the zone controller for the Indirect Water Heater Zone. Adjust Aquastat to the desired temperature. -
Page 20: Start-Up And Check-Out
SDT/SET Installation & Operation Manual Start-up and Check-out 1. Make sure the system is free of leaks and that air is purged from the system. Fix any leaks found before proceeding CAUTION further. Leakage from the boiler piping can result in severe damage to the boiler. 2. -
Page 21: Maintenance
SDT/SET Installation & Operation Manual Maintenance The Lochinvar SDT/SET series indirect water heater is an Homeowner monthly maintenance to include: extremely simple device and it requires very little maintenance. Visually check valves, pipes, and fittings for leaks. Call a There are, however, several items which should be inspected qualified service technician to repair leaks. -
Page 22: Performance Data
Gallons 65 ° F Rise 90 ° F Rise 115 ° F 140 ° F Boiler Solar SDT065 128,000 SDT080 128,000 SDT119 217,000 Amount of water drawn from tank with no energy input How to Properly Size Your Indirect Water Heater Use the First Hour Rating (FHR) to properly size your indirect water heater. -
Page 23: Performance Data Charts
Note: Testing conducted with 50°F inlet cold water Table 8D First Hour Rating - 180°F Boiler Loop Water (Universal Sizing. Upper Coil SDT Models) First Hour Rating - 180°F Boiler Loop Water (Universal Sizing - 45,000 - 295,000 Btu/hr / SDT065-SDT119) Model SDT065... - Page 24 SDT/SET Installation & Operation Manual Performance Data Table 8E First Hour Rating 200°F Boiler Loop Water (Universal Sizing, Upper Coil SDT Models) First Hour Rating - 200°F Boiler Loop Water (Universal Sizing - 45,000 - 295,000 Btu/hr / SDT065-119) Model SDT065 SDT080...
-
Page 25: High Output Piping
SDT/SET Installation & Operation Manual High Output Piping High Domestic Hot Water Usage Parallel Piping With this style of installation, both heat exchanger are used at When a large amount of hot water is required by a Domestic the same time. Solar / boiler supply piping to the solar water Hot Water system, the dual coil indirect water heater can be IN and boiler coils will be at the same temperature at the piped together when given the high volume needed to satisfy... - Page 26 Loop Draw Rating Max Input BACKFLOW REDUCING VALVE Temperature GAL/HR* GAL* BTU/HR PREVENTER PRESSURE 180° F 284,886 GAUGE SDT065 180° F 293,133 SDT080 MAKE UP WATER SYSTEM SUPPLY 180° F 397,341 SDT119 SENSOR SEPARATOR * Tank temperature 140°F. FROM SYSTEM NOT TO EXCEED 4 PIPE DIA.
- Page 27 Loop Draw Rating Max Input REDUCING BACKFLOW Temperature GAL/HR* GAL* BTU/HR VALVE PREVENTER PRESSURE 180° F 253,399 SDT065 GAUGE 180° F 257,897 SDT080 MAKE UP WATER SYSTEM 180° F 349,360 SUPPLY SDT119 SENSOR SEPARATOR * Tank temperature 140°F. FROM SYSTEM SYSTEM NOT TO EXCEED 4 PIPE DIA.
-
Page 28: Revision Notes
Revision Notes: Revision A (ECO C05788) initial release. Revision B (ECO C05936) reflects the addition of “High Output Piping” section on pages 25-27, Series and Parallel piping diagrams on pages 26-27, and new friction loss charts for SDT Series and Parallel on pages 26 and 27. Revision C (ECO C06300) reflects the update of tank images and additional CSA cautions on manual cover, “Connect tank sensor”...
