Summary of Contents for TV Logic 960H08

  • Page 1: Digital Video Recorder

    Digital Video Recorder User’s Manual EYE-ON 960H Realtime 960H08/16/16R/20R/32R...
  • Page 2 Thank you for using our product. Thank you for using our product. 1. This is user's manual for H.264 960H 08/16/20/32CH Realtime DVR (Digital Video Recorder). 2. This manual contains product specification and introduction, installation guide, operating guide and other necessary matters for easy understanding. Users should read this user's manual carefully for proper use.

  • Page 3: Table Of Contents

    CONTENTS Contents CH 1. Product Introduction` 1-1. Product Contents 1-2. Specifications 1-3. Product Characteristics 1-4. Name of Each Part CH 2. Installation Guide and Cautions 2-1. Cautions 2-2. Product Installation 2-2-1. Power Connection 2-2-2. Connecting External Device CH 3. How to Use 3-1.
  • Page 4 CONTENTS Contents Trouble Shooting How to Connect xbox1...

  • Page 5: Ch1. Product Introduction

    CH 1 Product Introduction CH1. Product Introduction 1-1. Product Contents (EYE-ON 960H08, 16) After removing packing materials of this product, check whether all following contents are included. Main Body (DVR): This converts the analog video and audio signal to the digital signal and saves on HDD.
  • Page 6 CH 1 Product Introduction 1-1. Product Contents(EYE-ON 960H16R, 20R, 32R) After removing packing materials of this product, check whether all following contents are included. Main Body (DVR): This converts the analog video and audio signal to the digital signal and saves on HDD. Adapter: This 12V adapter supplies power to the product.

  • Page 7: Specifications

    CH 1 Product Introduction 1-2. Specifications EYE-ON 960H Realtime Model 960H08 960H16 960H16R 960H20R 960H32R Compact case 19” rack type 16 BNC 20 BNC Camera input 8 BNC 16 BNC 32 BNC (loop out) (loop out) Video Available source Composite/960H/Mixed...
  • Page 8 CH 1 Product Introduction 1-2. Specifications EYE-ON 960H Realtime Model 960H08 960H16 960H16R 960H20R 960H32R Compact case 19” rack type Network Interface Gigabit Ethernet Speed 100fps@720H 50fps@720H 100fps@720H 125fps@720H 200fps@720H Protocol TCP/IP, HTTP, DHCP Network Application Windows XP / 7 / 8 (PC Client system& IE)/MAC...

  • Page 9: Product Characteristics

    CH 1 Product Introduction 1-3. Product Characteristics 1) New Video Configuration optimized 16:9 widescreen This is the revolutionary 8/16/20/32CH D1 real time DVR for 16:9 widescreen even use the 4:3 video source. Also it displays real HD(1920X1080) resolution, and therefore it provides the most clear image quality and the best security level. 2) High reliability With Embedded hardware and software design, this maintains higher product reliability.
  • Page 10 CH 1 Product Introduction 11) Display information in easy-to-understand information method This enhanced convenience of user by displaying information (date, time, recording method, recording frame number, HDD capacity and others) in monitoring, recording and playing mode in easy-to-understand way. 12) P/T/Z control By built in RS485, various P/T/Z cameras can be used.

  • Page 11: Name Of Each Part

    CH 1 Product Introduction 1-4. Name of Each Part [Front Panel] <EYE-ON 960H08, 16> 1. USB ports : These USB ports are for mouse and USB devices. You should connect correctly the USB devices and mouse as picture directed. 2. Status lamps POWER : Blue color back light.
  • Page 12 CH 1 Product Introduction [Front Panel] <EYE-ON 960H16R/20R/32R> 1. Playback buttons : It will be used on playback. If you press these buttons in live mode, it will be automatically changed to the Instant Play mode. ‘Stop’ button changes from the play mode to the live mode. 2.

  • Page 13: Rear Panel

    (※ In menu and password setting, it is automatically converted to number buttons) 8. Backup device : You can use the versatile backup devices such as CD-RW and DVD-RW. [Rear Panel] <EYE-ON 960H08> 9. AUDIO OUT 10. AUDIO IN 8.SENSOR IN / RELAY / RS485 7.
  • Page 14 CH 1 Product Introduction [Rear Panel] <EYE-ON 960H16> 9. AUDIO OUT 10. AUDIO IN 8.SENSOR IN / RELAY / RS485 7. DC 12V 2.VIDEO IN 3.SPOT 5. VGA 1.FAN 6.HDMI 4. LAN 1. Fan : Cooling Fan 2. VIDEO IN : This receives images from SDI cameras or any camera. 3.
  • Page 15 CH 1 Product Introduction [Rear Panel] <EYE-ON 960H16R> 12. POWER SWITCH 14.Video In, Loop Out 13. AUDIO OUT 5. e-SATA 7. VGA 3. EXTEND 9. USB 11. DC 12V 4. RS232C 6. HDMI 8. LAN 10. SPOT 1. SENSOR IN / RS485, ALARM OUT 2.
  • Page 16 CH 1 Product Introduction [Rear Panel] <EYE-ON 960H20R> 12. POWER SWITCH 14.Video In, Loop Out 13. AUDIO OUT 5. e-SATA 7. VGA 3. EXTEND 9. USB 11. DC 12V 4. RS232C 6. HDMI 8. LAN 10. SPOT 1. SENSOR IN / RS485, ALARM OUT 2.
  • Page 17 CH 1 Product Introduction [Rear Panel] <EYE-ON 960H32R> 12. POWER SWITCH 14.Video In, Loop Out 13. AUDIO OUT 5. e-SATA 7. VGA 3. EXTEND 9. USB 11. DC 12V 4. RS232C 6. HDMI 8. LAN 10. SPOT 1. SENSOR IN / RS485, ALARM OUT 2.

  • Page 18: Cautions

    CH 2 Installation Method and Cautions CH2. Installation Method and Cautions 2-1. Cautions WARNING Risk of electric shock. Do not open the cover of the product. Servicing of this product by unauthorized personnel is prohibited and will result in a void of warranty. In order to ensure the most stable conditions for power, the use of a UPS (Uninterrupted Power Supply) is recommended.
  • Page 19 CH 2 Installation Method and Cautions - Keep the power cord untwisted. (May cause fire or electric shock.) - Use proper adapter. (Using too much electric power may cause fire or electric shock.) - Do not install it at where exposed to rain and wind and water drop. (May cause fire, electric shock and transformation.) - Keep away from fire.
  • Page 20 CH 2 Installation Method and Cautions Note : This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.

  • Page 21: Product Installation

    CH 2 Installation Method and Cautions 2-2 Product Installation This product may be composed of camera and monitor in default, and additionally the sensor, microphone, speaker and PC for network can be connected if necessary. 2-2-1. Power Connection 1) Connect adapter cable to power connection terminal at rear side. 2) Input AC power to the adapter.
  • Page 22 CH 2 Installation Method and Cautions 2) How to connect external sensor Sensor terminal is composed of 1 input channel and 1 output channel. Sensor out terminal is relay output with 1A, 24V or 0.5A,125V. SIREN SENSOR POWER Sensor In : Connect the sensors. The sensor are composed of both signal and ground terminals, with a voltage difference of 5V.
  • Page 23 CH 2 Installation Method and Cautions 4) Connection Using PTZ camera In case of using pan and tilt cameras, connect PAN/TILT DRIVE to product as shown at following figure. VIDEO CABLE SPEED RS485 CABLE DOME 5) Installing Hard disk drive In case of installing the hard disk drive, open the upper case and install the hard disk drive on the hard bracket.

  • Page 24: Ch3. How To Use

    CH 3 How to Use CH3. How to Use 3-1. General Usage Information The DVR system can be operated with a mouse or remote controller under the four main modes listed below: Live Mode – This is the “main or default” mode. From this mode you can view in real time all currently operating cameras, information regarding camera status, and have access to Pan/Tilt camera controls.

  • Page 25: Live Mode

    CH 3 How to Use 3-2. LIVE Mode In this section you will know how to split the video mode into 1, 4, 6, 8, 9, 12, 16, as well as auto sequencing, PTZ Control, Mouse control, Setup configurations, Backup. 3-2-1.
  • Page 26 CH 3 How to Use Date Time Screen Split mode change Sequence activation Hard drive usage Lock/ Unlock indicator Scheduler activation indicator Network connection indicator Audio out channel indicator Audio Mute indicator 3) Live Popup Menu By Right-Clicking anywhere on Live Screen, you may view the Live Popup Menu. By using the Live Popup Menu, you can quickly jump to the necessary configuration and settings.

  • Page 27: Live Mode Feature

    CH 3 How to Use 3-2-2. LIVE Mode Feature 1) Setup : refer to 3-4 2) Split Change video split mode for Live View. 3) Audio Out You can choose the audio out from this menu. 4) Instant Replay This is very convenient function to catch the abrupt accident. During live viewing, you can go directly to the playback screen.
  • Page 28 CH 3 How to Use 6) Backup There are two ways to enter the backup. The first one is that right click on the live screen, and the second one is that enter directly from ‘Search’ upon playback. If you choose the ‘backup’...
  • Page 29 CH 3 How to Use 7) Snapshot You can save the live snapshot by this menu. All channel will be saved individually to the USB memory by JPG format . You should put in USB memory before saving. 8) Freeze You can freeze the current live video channels.
  • Page 30 CH 3 How to Use • Preset : You can enter the preset number using the keypad appearing the preset button or ‘Enter’ button on the remote controller. Run[Enter] Move to preset number Set[PTZ/SEARCH] Set a position and name of a preset number Clear[Stop/BACKUP] Clear a preset set Exit...
  • Page 31 CH 3 How to Use • : You can choose the PTZ camera with mouse or [0] buttons on the remote controller • : If you press Setup using mouse (or [9] button on the remote controller) in PTZ Menu, PTZ setup window will appear.
  • Page 32 CH 3 How to Use 10) Zoom Digital zoom of live screen for selected channel. It can be 8x zoom and also control the position by mouse dragging. CH 1 (x2) • : You can choose the camera for zoom with mouse or [0] buttons on the remote controller.
  • Page 33 CH 3 How to Use 11) Sequence Sequence Mode On /Off: Switches screens as set on Dwell time under Screen Setup 12) OSD This feature shows current settings of product through GUI (Graphic User Interface) and INFO button at front side is used for this feature. When you CH 1 (x2) turn on power, this will show current date and time, System Lock Setting, HDD usage, Video Loss Check, Sensor ON/OFF, Motion Detection Check, Recording Status...
  • Page 34 CH 3 How to Use 15) Alarm Control You can control all alarms connected and the DVR system buzzer. CH 1 (x2)

  • Page 35: Search Mode

    CH 3 How to Use 3-3. Search Mode Search mode consists of two different modes of searching. The video data can be selected by 5 modes. Time Search by Month / Day / Time selection. Event Select from Event Log. Search by POS transaction data.
  • Page 36 CH 3 How to Use 2) Event Based Search Selection • Select search date from calendar • Event log will be displayed according to the chosen date • Preview pane above the Event Log will show preview of currently selected video 3) POS Search •...
  • Page 37 CH 3 How to Use 4) Thumbnail Search • Select search date from calendar • Choose the channel and interval, then select the time from bar or typing • The selected channel will be played individually by interval time difference 5) Panorama Search •...
  • Page 38 CH 3 How to Use 6) Search Related buttons • You may click on Refresh, Option, Backup, Import, Exit , Full Screen for additional features and options Reload all data list. Search option. Backup recorded data to external USB device. Playback recorded data from external USB device.

  • Page 39: Play Mode

    CH 3 How to Use 3-3-2. Play Mode If you choose ‘Full Screen’, the full screen appear. You can control the play speed in here. ▶ Play Screen GUI 1. Split Screen 2. Sequence 3. FB (Fast Backward): FB×2, 4, 8, 16, 32, 64 times faster 4.

  • Page 40: Setup Mode

    CH 3 How to Use 3-4. SETUP Mode Access Setup menu from Right Clicking mouse button to Popup Menu. Configure Display, Record, Device, Network, System which is navigated by clicking on corresponding tab menu at the top of the screen. Apply Apply changes Default...
  • Page 41 CH 3 How to Use 2) Display • You can use dual monitors that show same image by setting VGA+HDMI. • Configure and view Resolution, Sequence Dwell Time and Display control settings. 1280x720(60Hz), 1280x720(50Hz), Resolution 1280x1024(60Hz),1920x1080(60Hz), 1920x1080(50Hz) Device VGA+HDMI, VGA, HDMI Sequence dwell time 1 sec ~ 60 sec Skip a video loss channel when you set the...
  • Page 42 CH 3 How to Use 3) HD Spot • If you are not using VGA+HDMI for display, you can use HD Spot. 1280x720(60Hz), 1280x720(50Hz), Resolution 1280x1024(60Hz),1920x1080(60Hz), 1920x1080(50Hz) Device VGA, HDMI, None Mode (Split Screen ) 1, 4, 9, 16 Screen Sequence dwell time 1 ~ 60 sec Skip a video loss channel for the sequence of the...
  • Page 43 CH 3 How to Use 4) SPOT Control • Set the SPOT output . CVBS Choose NTSC or PAL Mode 1, 4, 9, 16 Screen Sequence dwell time 1 ~ 60 sec Skip a video loss channel for the sequence of the Skip Video Loss Spot.
  • Page 44 CH 3 How to Use 5) Color • Adjust color of analog cameras. Brightness Adjust brightness Contrast Adjust contrast Saturation Adjust saturation Adjust hue Default Return to factory default settings. Apply All Apply changes to all channels.

  • Page 45: Record

    CH 3 How to Use 3-4-2. Record Configure and view Event In, Record, Group, Holiday settings 1) Record Rec type None, Conti, Event, C/E Audio Rec To select audio recording or not. v ALL Apply Apply the setting to whole channel. Resolution 1920x1080, 1280x720, 960x540 Continuous...
  • Page 46 CH 3 How to Use v Event recording has priority in recording. In C/E recording, the recording will follow conti recording setup in normal condition while it would follow event recording setup in event generation. v For convenience, you can use the ‘Apply All’ menu to change with the same preference.
  • Page 47 CH 3 How to Use 3) Schedule • In recording, Schedule recording setting is most preferred. So if you activate the weekly scheduler, you cannot record manually. • Schedule On : The weekly scheduler is activated. • Holiday On : The holiday that set by user is activated. •...
  • Page 48 CH 3 How to Use 4) Holiday With this menu, you can add the holidays. Use the ‘Add’ button for adding the holiday and use the ‘Delete’ or ‘Delete All’ buttons for removing the existing holidays.
  • Page 49 CH 3 How to Use 5) Event In • With this menu, you can set sensor input, motion detection setup. You can also set each channel individually. • Although you set Motion Detection and Sensor Setting to On in Event menu, if Event Input in Rec Menu is set to None, it only detects and does not record.

  • Page 50: Device

    CH 3 How to Use 3-4-3. Device • Configure and view Camera, Private Zone, Audio, Motion Detection, Alarm Out, PTZ settings and Controller. 1) Camera Signal type All video input is detected automatically Detected Detected camera video type Name You can set the camera name. Disable current camera.
  • Page 51 CH 3 How to Use 2) Private Zone If you want to hide some part of the picture for privacy, you can choose the area by dragging the mouse. The selected area will be changed to black screen. All Off All off the private zone Apply All Apply the setting to whole channel...
  • Page 52 CH 3 How to Use 3) Audio Audio 1~4 Audio 1~8 Assign audio input to a video channel. Audio 1~16 Audio Out Select which channel will be heard during Live View.
  • Page 53 CH 3 How to Use 4) Motion Detection • Change settings for Motion Grid selection and Sensitivity Level. You can set multiple area. Sensitivity Low, Mid, High All On This will activate the motion detection of the all area. All Off This will deactivate the motion detection of the all area.
  • Page 54 CH 3 How to Use 5) Alarm Out • There are 4 types trigger such as sensor input, motion detection, POS and video loss. This setting is related that which trigger will be activate the action such as Relay, Popup, and Buzzer Alarm Out. Each type can have separate Duration value and also linked to selected camera.
  • Page 55 CH 3 How to Use 5-2) Sensor In • You can choose the action after sensor in between relay, buzzer sound, pop up, spot pop up and HD spot pop up. Also you can choose more than one action. • Choose a sensor connected to a channel. •...
  • Page 56 CH 3 How to Use • Also you can choose more than one action. Furthermore you can set the preset position number by motion detection. If you push the ‘setup’ you can see the preset screen. • You can assign the preset position individually by specific motion.
  • Page 57 CH 3 How to Use 5-3) Motion Detection • You can choose the action after motion detection between relay, buzzer sound, pop up, spot pop up, and HD spot pop up. • Also you can choose more than one action. Furthermore you can set the preset position number by motion detection.
  • Page 58 CH 3 How to Use 5-4) POS • You can choose the action after POS transaction or video loss between relay, buzzer sound, pop up, spot pop up and HD spot pop up. • Also you can choose more than one action.
  • Page 59 CH 3 How to Use 5-5) Video Loss • You can choose the action after motion detection between relay, buzzer sound, pop up, spot pop up, and HD spot pop up. • Also you can choose more than one action.
  • Page 60 CH 3 How to Use 5-6) Duration • You can choose the duration time from 5 to 60 seconds after motion detection between relay, buzzer sound, pop up, spot pop up, HD spot pop up, and preset.
  • Page 61 CH 3 How to Use 5-7) Name • You can set a name of the alarms.
  • Page 62 CH 3 How to Use 6) PTZ Configure Pan/Tilt/Zoom camera for control via DVR System and Remote client. Driver Choose Driver to be suitable for PAN/TILT Camera manufacturer. Address Choose address to be suitable for PAN/TILT Camera manufacturer. Baudrate Choose baudrate to be suitable for PAN/TILT Camera manufacturer. •...
  • Page 63 CH 3 How to Use v There are more kinds of camera which can be supported. Please contact the tech support to want to know the other cameras. Driver Baudrate PELCO D type 2400~9600 PELCO P type 2400 PANASONIC 2400~19200 ORIENTAL 2400(Fixed) LPT-A100L...
  • Page 64 CH 3 How to Use 7) Controller This sets the ID of remote control and system keyboard. If you have many DVRs in the same place, you can control separately the DVR by different remote control ID. v Remote controller ID setup Use the ID setup and number key to set the ID of remote control on the remote controller.
  • Page 65 CH 3 How to Use 8) POS This sets the POS interface(text inserter) with the DVR and cash register. ※ If you are using a USB hub, you can use up to 4 USB POS. Channel Select a Channel of POS Baudrate Select a baudrate of POS Type a start word of transaction...
  • Page 66 CH 3 How to Use v How to Connect POS 1. Connect the RS-232 cable or USB to RS232 serial cable between POS and DVR. RS232 *POS *DVR RS232 2. To set manually, at first you should know the setting values of the POS. You can get the information from the POS setting screen.

  • Page 67: Network

    CH 3 How to Use 3-4-4. NETWORK Configure and view Address, Port, DDNS, E-mail, Control and Status settings. 1) Address Configure Network information for Remote client connection. DVR Name Type the URL of DVR using virtual keyboard. Type It can be supported only Ethernet. Set whether you want to use DHCP or not (On/Off).
  • Page 68 CH 3 How to Use 2) Port There are 4 kinds of ports for the case such as watch, search, setup and web. You can individually set the port number of the DVR. The default is 8000. You can choose from 8000 to 9999.
  • Page 69 CH 3 How to Use 3) DDNS This is the function to automatically change the IP of DVR to URL. This product supports the automatic DDNS service using manufacture’s internal server. Also you can choose Dyndns. DDNS Type Choose a DDNS type. DDNS Server Defend on the DDNS type, it will be auto-typed or disable.
  • Page 70 CH 3 How to Use 4) E-mail You can send a notification of events by email. Fill all the information correctly and push the ‘Email Test’. Also you can select each event individually by ‘Event Set’. Receiptor Type the email address of the receiptor. Sender Type the name of the sender.
  • Page 71 CH 3 How to Use v Event Set Set events to send the email. Sensor Detect a sensor input. Motion Detect a motion detection. Video Loss Detect a video loss. Send inserted text of POS to the email. S.M.A.R.T. Send checked HDD S.M.A.R.T result to the email. System log Send system log to the email.
  • Page 72 CH 3 How to Use 5) Streaming CMS can use the ‘High resolution’ setting in the case of full screen or quad screen, and use the ‘Low resolution’ setting in the case of more than 4 split. You can adjust the number of split to switch from High to Low resolution.
  • Page 73 CH 3 How to Use 6) Status This shows the information how many connections and what is the action of each connection. MAC Address This displays MAC address of DVR. This displays all the connected IP. Connected IP This displays how many connection for live viewing. Watch User Search User This displays how many connection for playback.

  • Page 74: System

    CH 3 How to Use 3-4-5. SYSTEM Configure and view system Date/Time, User Authority, Storage, System Log and Configuration settings 1) Date/Time Choose the time zone of your site. If you using the NTP Timezone function, it must be set correctly to your zone. Daylight Saving Time It enables to adapt the day light saving time automatically.
  • Page 75 CH 3 How to Use 2) User Authority This sets User authority individually. You can give to each users the authorities such as setup, search, backup, PTZ, network and camera control. Type an ID. Password Type a password. Setup Authorizes the setting of the system. Search Authorizing the search of the system.
  • Page 76 CH 3 How to Use 3) Storage Display the information and usage of the hard disk drives. Display all the HDD usage being used for the product. If you press Total the ‘Enter’ button on here, all the hard disk drives will be formatted. HDD Check Check all the HDD.
  • Page 77 CH 3 How to Use 4) S.M.A.R.T :Self-Monitoring Analysis and Reporting Technology This function lets you probe the hard disk drives and investigate the status of the drivers automatically. S.M.A.R.T. S.M.A.R.T. On Set whether you want to use S.M.A.R.T. or not (On/Off). Determine the date to perform the S.M.A.R.T.
  • Page 78 CH 3 How to Use 5) System Log You may view all System administration log from Setup à System à System Log. Also you can export the system log and easily send it to technical support for trouble shooting. Refresh Refresh the system log.
  • Page 79 CH 3 How to Use 6) Configuration Shown at the following screen, from Setup à System à Firmware, you may view the current firmware version as well as Upgrade the firmware and additionally, Export, Import, and Default DVR Configuration. Firmware version It shows the firmware version.

  • Page 80: Firmware Upgrade

    CH 3 How to Use 3-5. Firmware Upgrade If you want to upgrade, please follow that; 1. Download the latest firmware to USB memory root directory. 2. Put this memory to USB slot of DVR. 3. Choose ‘Upgrade’ and you can see the below screen will appear. 4.
  • Page 81 CH 3 How to Use If you choose OK, you can see the below download window on the DVR screen. ☞ WARNING!!! Do not turn off the power during download procedure. If you power off manually, all memory will be deleted ! ※...

  • Page 82: Trouble Shooting

    Trouble Shooting Trouble Shooting Symptom Checkpoint Countermeasure ● Is DVR connected to power ● Can't turn on power. ● Connect power cable supply cable? ● There is no image on monitor ● Are DVR and monitor turned ● Turn on power. ●...

  • Page 83: How To Connect Xbox1

    How to Connect xbox 1 How to Connect xbox 1 1. Connect EXTEND FTP cable to Receiver (upto 350ft/100m). Refer to http://en.wikipedia.org/wiki/Twisted_pair about the FTP cable. Connect Monitor and Wired/Wireless Mouse to the Receiver FTP(Foiled Twisted Cable) Receiver 2. Because all the case has different cable length, you should adjust the GAIN and PHASE in Receiver to get a most proper VGA output.
  • Page 84 How to Connect xbox 1 3.This is the whole diagram.
