Magnadyne Video Switching Center VCS-6 Installation Instructions

Features:
• Push-button type select the program by just
"one push".
• Deluxe plastic cabinet.
• Accepts 3 inputs:
1. TV Antenna
2. VCR
3. Auxiliary Input
UHF/VHF
Separator
1111 West Victoria Street
Compton, CA 90220
Installation Instructions
Video Switching Center
Connection Diagram
TO FROM
TV 3 AUX
VHF
UHF
Satellite
Receiver
• Provides 3 outputs:
1. TV 1
2. TV 2
3. TV 3
• High isolation.
• Low insertion loss.
• All passive, no power required.
FROM TO FROM
VCR TV 2 ANT
Model VCS-6
UHF/VHF
Separator
UHF
RF VHF
In
Out
Model: VCS-6
TO
TV 1
VHF
UHF/VHF
Separator
UHF
Outside
Antenna
VCS-6-IM Rev. A 5-31-07
© 2007 Copyright Magnadyne Corporation
