- Page 1 Owner's Manual 7 '' Screen Model: MV750G (Gray) MV750T (Tan) For operational or technical assistance, after reading this manual, please call us toll free at (800) 638-3600 or visit www.magnadyne.com...
-
Page 2: Monitor Functions
1. 3.5mm Headphone Jack: Plug in headphones to listen to audio output. Note: Headphones with built-in volume control are required for proper operation. 2. Audio/Video (2) Input: Use the supplied cable to connect to an external audio/video source (AV2). 3. Screen Release Lever: Press it to release the monitor. -
Page 3: Screen Functions
Turning the Unit On: When the screen housing is open the unit automatically turns on. Closing the screen will automatically turn the unit off. Adjusting the Monitor: Press the MENU button to activate the moni- tor adjustment menu. The following will be displayed on the screen: Use the UP and DOWN buttons on the screen housing to adjust the brightness. - Page 4 Screen’s Remote Eye: Point your DVD player's remote control at the MovieVision screen's remote eye to control player. The screen will receive the signal and send it directly to the player. *Screen's remote eye output cable must be connected to DVD player to enable this feature.
-
Page 5: Wiring Diagram
Audio Output (Female RCA) *Note: If external cable is used for Audio/Video Input 2 the internal Audio/Video Input 2 RCA’s will not function. Remote Eye Connection Note: When creating passage holes for the power wires, use grommets to eliminate any sharp edges made during drilling. -
Page 6: Installation
Ceiling Support Beam Mount support bracket using screws (not supplied) with the “This Side Mounts Against Roof/Ceiling” label against ceiling support beam(s). Warning: Take extra care to not penetrate the roof of your car. Roofmount with Intsallation Shroud Installation Roofmount without Intsallation Shroud Long screw (actual size) Attach the screen housing to the metal support bracket using the screws... -
Page 7: Use This Product Safely
Power Harness Wiring: The 3 wire harness provides battery and igni- tion 12 volts as well as a chassis ground. Route the power harness to the point in the vehicle that you will make the connections. Red Wire: The red wire in the harness should be connected to a +12 volt power wire that is turned On and Off by the position of the ignition key. -
Page 8: Troubleshooting
• Check to see if that power to the outlet is properly working. Magnadyne Corporation or its authorized agents will within 1 year from the date of sale to you, repair, replace or refund the retail sales price of said product or any part thereof, at the option of the...
