Magnadyne Linear LS6000 Owner's Manual

Magnadyne Linear LS6000 Owner's Manual

Linear series am/fm stereo receiver and auto stop cassette player
Hide thumbs

Advertisement

Table of Contents

OWNER'S MANUAL
LS6000, LS6300
AM/FM Stereo Receiver and Auto Stop Cassette Player
Designed for In-Wall Installation of All Recreational Vehicles, Motor Homes and Mobile Housings
12 Volts DC
A Registered Trademark of Magnadyne Corporation

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Linear LS6000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Magnadyne Linear LS6000

  • Page 1 OWNER'S MANUAL LS6000, LS6300 AM/FM Stereo Receiver and Auto Stop Cassette Player Designed for In-Wall Installation of All Recreational Vehicles, Motor Homes and Mobile Housings 12 Volts DC A Registered Trademark of Magnadyne Corporation...

  • Page 2: Controls And Functions

    INTRODUCTION Please read all of the information in this booklet before using this unit to insure that you fully understand the capabilities of this unit. CONTROLS AND FUNCTIONS LS6000 600 700 1000 1200 1400 1600 LS6100 STEREO ON / OFF...
  • Page 3 CONTROLS AND FUNCTIONS 1. On / Off Button Press this button in to turn the unit on. Press again to turn the unit off. 2. AM / FM / AUX Function Knob After turning the unit on, select the desired playing mode with this knob.
  • Page 4 "headphone" receptacle of your portable CD player It is strongly recommended to use the "line out" receptacle of the portable CD player. The LS6000 and LS6300's volume, balance and tone controls will operate normally when the CD input is used 17.
  • Page 5 CONTROLS AND FUNCTIONS How to Set the Date and Time (LS6300 Only) 1. With the normal time display showing, press the mode button 4 times. (The month will display) 2. Press the set button until the correct month appears. 3. Press the mode button again. (The day will display) 4.
  • Page 6 CONTROLS AND FUNCTIONS How to Turn On/Off the Alarm Clock and Hour Chime (LS6300 Only) 1. With the normal time display showing, press the mode button. (The time display will begin to flash) 2. Press the set button. (The alarm on indicator will be displayed at the top the display area) Press Press...

  • Page 7: Installation

    INSTALLATION Wall Panel Structural Stud A N D IO B R A D A U X V O L H IG L O W A N C O R T B A L N S P O S T T R A T O N A U T E J E...
  • Page 8 POWER / AUX CONNECTIONS This unit for use only with a 12 volt DC power source with a negative ground.

  • Page 9: Speaker Connections

    SPEAKER CONNECTIONS Left Speaker (A) BROWN Wire ORANGE Wire GREEN Wire Left Speaker (B) Speaker Connections: Do not confuse the A and B speaker sets Right Speaker (A) GRAY Wire WHITE Wire BLUE Wire Right Speaker (B)

  • Page 10: Antenna Connections

    If an automotive antenna is not available or is undesired, we recommend the use of a Magnadyne DP36AXT di-pole antenna substitute. Plug the male plug from the DP36AXT into the female receptacle of the LS6000 or LS6300 unit and allow the cable of the antenna to lay inside the wall.

  • Page 11: Safety Instructions

    SAFETY INSTRUCTIONS Read Instructions: All the safety and operating instructions should be read before the appliance is operated. Retain Instructions: The safety and operating instructions should be retained for future reference. Heed Warnings: All warnings on the appliance and in the operating instructions should be adhered to.

  • Page 12: Operation And Maintenance

    Magnadyne Corporation or its authorized agents, if said product or part is found defective in materials or workmanship, when properly connected and operating on the correct power requirements designated for the specific product.

This manual is also suitable for:

Linear ls6300

Table of Contents
