- Page 1 LavryBlack Series Model MP10 Stereo Microphone Preamplifier Lavry Engineering, Inc. P.O. Box 4602 Rolling Bay, WA 98061 http://lavryengineering.com email: techsupport@lavryengineering.com Version 1.0 September 5, 2008...
- Page 3 “Unbal.” The output will be unbalanced “Pin 2 Hot” when the switch is in the “unbal” position. AC POWER: The MP10 automatically adjusts to AC power inputs in the range of 90 to 264 Volts AC and line frequencies between 47 and 63 Hertz. There are no settings to change.
- Page 4 +24 dBu. Even so, when feeding the output of the MP10 to an unbalanced “-10” level input, care should be taken to set the gain so that the peak signal level displayed on the MP10’s meter does not exceed “-6.” This corresponds to the (approximate) 12 dB difference between the peak level for a “+4dBu”...
-
Page 5: Specifications
G. Balanced/Unbalanced Switch The XLR outputs of the MP10 are electronically balanced and should not be connected to an unbalanced input without first setting the rear panel switch to “unbal.” Doing so will not cause damage to the amplifiers, but will raise the distortion level of the outputs significantly. - Page 6 Subject to the conditions set forth below, for one year after the original purchase date of the product, Lavry Engineering will repair the product free of charge in the United States in the event of a defect in materials or workmanship.
