FW5870 User's Manual
Class A Digital Device (industrial & commercial environment)
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE
and FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at his own expense.
M4051-01
FW5870 User's Manual

(Product Guide)

Version 4.14
April 13, 2012
１ １ １ １
Seyeon Tech Co., Ltd

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FlexWATCH FW5870 and is the answer not in the manual?

Questions and answers

Related Manuals for Seyeon Technology FlexWATCH FW5870

Summary of Contents for Seyeon Technology FlexWATCH FW5870

  • Page 1: Product Guide

    FW5870 User’s Manual FW5870 User’s Manual (Product Guide) Version 4.14 April 13, 2012 Class A Digital Device (industrial & commercial environment) This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to CE and FCC Rules.
  • Page 2 FW5870 User’s Manual FW5870 User’s Manual Document Part Number: M4051-01 Document Version: 4.14 Revised: April 13, 2012 About This Document This document is prepared for users of FW5870 supplied by Seyeon Tech Co., Ltd. It is assumed that the users are familiar with Microsoft Windows operating systems and Web browsers such as Internet Explorer. It is also assumed that the users are well aware of how to install and use the network equipment such as LAN, Hub, router, and having basic knowledge of network terminologies.

  • Page 3: Table Of Contents

    FW5870 User’s Manual Contents PRODUCT OVERVIEW ............................ ４ 1.1. FW5870 ...................................... ４ 1.2....................................５ EATURES 1.3................................ ６ ECHNICAL PECIFICATION 1.4. FW5870 P ................................９ ACKING PRODUCT DESCRIPTION .......................... １０ 2.1. FW5870 F ................................. １０ RONT 2.2. FW5870 R ................................

  • Page 4: Product Overview

    FW5870 User's Manual 1. Product Overview 1.1. FW5870 FlexWATCH® 5870 is a stand-alone, hybrid network Digital Video Recorder & server that provides full feature of video server and recorder. FW5870 provides complete Triplex mode (Live video transmission, on-site video recording and remote playback). It provides simultaneous recording and remote access to live views and playback of recorded images from up to 8ch IP camera or video servers, and 8ch analog cameras, digitize and transmit them over TCP/IP network.

  • Page 5: Key Features

    FW5870 User's Manual 1.2. Key Features • Standalone device with a built-in web server • 10M/100M/1000M Auto-Sensing Ethernet • Configuration and control device through Web browser • Max 120 fps transmission speed on TCP/IP network • Compressed audio transmission for each of 8 channels •...

  • Page 6: Technical Specification

    FW5870 User's Manual 1.3. Technical Specification 32bit Embedded CPU Flash 8Mbytes /SDRAM: 128Mbytes Hardware Linux Version 2.6.24.4 Operating System Battery backed up real-time clock MJPEG Video compression H.264 NTSC : 720x480, 704x480, 352x240, 160x112 Resolution PAL : 720x576, 704x576, 352x288, 160x144 Frame rate Up to 120 fps @D1 (each channel)
  • Page 7 FW5870 User's Manual Output Impedance : 230 Ohm Output Power : 50 mW Audio Output(SPK) Output Voltage : Peek To Peek 1 Volt Jack : 3.5mm Stereo Power Over Ethernet Not Supported Two serial ports for console, serial input/output device, PTZ COM Port is RS-232 Serial Interface AUX port can be configured as RS-232, RS-485...
  • Page 8 FW5870 User's Manual Pentium 4, 2 GHz, 2GB(RAM) or higher Video Card: 256MB RAM, 1024x768 resolution or higher Minimum Web browsing 100Mbps Network Adaptor or faster requirements Windows XP Pro or later Internet Explorer 6.x or later Powerful API for software integration available at http://www.flexwatch.com, including Simple Viewer API, FlexWATCH Control SDK, event trigger data in video System integration stream, embedded scripting and access to serial port...

  • Page 9: Fw5870 Packing List

    FW5870 User's Manual 1.4. FW5870 Packing List FW5870 1 EA Power Supply Unit 1 EA (Power Cable & SMPS DC12V 5A Adapter) CD (User’s Manual, IP Installer and etc) 1 EA Table 2 : FW5870 Packing list Note: Please make sure all the listed items are included in the package. For any missing items, please contact your local distributor.

  • Page 10: Product Description

    FW5870 User's Manual 2. Product Description 2.1. FW5870 Front View Picture 2 : FW5870 Front panel B C D E F G This switch is used to turn FW5870 On or Off. Power Switch (Note: Never turn off during formatting the HDD because it may cause a severe damage to it.) Power LED This green LED is lit during FW5870 is powered on.
  • Page 11 FW5870 User's Manual Beep Sound Description Condition Beep Sound Power ON One short beep if boot-up is started normally. System Ready Two short beeps if boot-up is finished normally. Power Off Two beeps in case of power-off during operation (0.5 second). One 5 second long beep in case of HDD failure during operation.

  • Page 12: Fw5870 Rear View

    FW5870 User's Manual 2.2. FW5870 Rear View Picture 3 : FW5870 Real panel L M N O A FW5870 unit is consists of two function modules, module 1 and 2. Each module has 4 camera inputs, 4 audio inputs, 4 DI ports, and 4 DO ports. Name Description Mod1, Video-In 1...

  • Page 13: Com Port Description

    FW5870 User's Manual Mod0, Audio-In 1 3.5mm Audio Jack for Audio-In 1 of Module 0 Mod0, Audio-In 2 3.5mm Audio Jack for Audio-In 2 of Module 1 Mod0, Audio-In 3 3.5mm Audio Jack for Audio-In 3 of Module 1 Mod0, Audio-In 4 3.5mm Audio Jack for Audio-In 4 of Module 1 Mod0/DI Sensor/Contact Input Port for Module 0...

  • Page 14: Fw5870 Installation And Basic Setup

    FW5870 User's Manual 3. FW5870 Installation and Basic Setup 3.1. Before Installation Read carefully User's Manual. Check User’s Network (IP Address, Network Mask and default gateway) Secure IP address for FW5870. 3.2. Factory Default Settings The following table shows the factory default condition. Please refer to this when you need to change the values on admin menu.
