- Page 1 Item No.: 4SK909 User’s Manual Thank you for purchasing The Original Dash Cam Twister. Please review this guide fully before use. For any questions not answered in this guide, please visit www.GetDashCam.com...
-
Page 2: Table Of Contents
Contents About this Guide ..............3 WARNING ................4 Notice… ................4 Canada ................4 Battery warning..............4 Notes on Installation ............5 Caution ................5 Introduction ..............6 Features ..............6 Package Contents ............ 7 Product Overview ............. 8 Getting Started ............ - Page 3 2.5.4 Connecting as a Bluetooth Speaker ..17 Basic Setup ............18 2.6.1 Set the Date / Time ........18 Using TODC Twister ..........20 Recording Videos ........... 20 3.1.1 Record videos while driving ....20 3.1.2 Emergency Recording ......20 3.1.3 The Recording Screen ......
-
Page 4: About This Guide
About this Guide The content in this manual is for informational purposes only and is subject to change without prior notice. FCC declaration of conformity Responsible party: 4Sight, Inc. 12285 Colony Ave. Chino, CA 91710 (714) 988-5838 Fax: (714) 285-5828 This device complies with Part 15 of the FCC Rules. -
Page 5: Warning
WARNING THIS DEVICE SHOULD NOT BE ADJUSTED BY THE DRIVER WHILE DRIVING. IN THE EVENT OF AN ACCIDENT, DEVICE MAY DISLODGE AND BECOME UNSAFE FOR PASSENGERS. Notice Memory card comes pre-inserted. Please be sure memory card is in unit before recording. TODC Twister supports microSD cards up to 32GB When the battery is depleted, TODC Twister will display, “Out of Battery Power”... -
Page 6: Notes On Installation
Notes on Installation 1. This product is best used when installed near the rear view mirror, at the center and top of windshield (must follow all local laws related to mounted devices in vehicle). 2. Do not touch the lenses with your fingers. Finger grease may be left on the lens and will result in unclear videos or snapshots. -
Page 7: Product Features
1 Introduction Thank you for purchasing The Original Dash Cam Twister. If after reviewing this manual you still have questions, please visit TODC (The Original Dash Cam) website at www.GetDashCam.com 1.1 Features Two wide angle HD lenses Still snapshots for photographic evidence ... -
Page 8: Package Contents
1.2 Package Contents MicroSD Card Dash Cam Suction Cup Mount User’s manual USB Cable 12v Car Charger... -
Page 9: Product Overview
1.3 Product Overview... - Page 10 Item Item Up Button / IR sensor Mic 1 On/Off Menu / Back Button Mic 2 Down / Mute Button MicroSD Slot OK / Record Button Power Button Mode / Emergency Lock AV Out Button Connect Bluetooth 320° Rotating Lens Reset Button Micro USB Port Fixed Lens...
-
Page 11: Getting Started
2 Getting Started 2.1 Inserting the Memory Card Insert memory card with both the pins on the memory card and the screen of TODC Twister facing up, as illustrated below. Push the memory card in until a click sound is heard, indicating the card is locked in position. -
Page 12: Installing In Vehicle
2. Please use a minimum class 6 4GB microSD card, maximum class 10 32GB. 3. Please format the micro SD card before the initial use. 4. When removing the memory card, be careful that the card does not spring out and get lost. -
Page 13: Connecting To Power
Note: 1. The Seller or Manufacturer of The Original Dash Cam Twister 4SK909 shall not be held responsible for any traffic violations related to the positioning or improper use of this product. - Page 14 the power cord around the trim of your vehicle so that it will not obstruct your view while driving. Plug the other end of the car charger into the 12v port in your vehicle. Once the vehicle engine is started (depending on your vehicle), the device will automatically power on.
-
Page 15: Led Indicator
2.5 Powering the Device On / Off 2.5.1 Auto Power On/Off The Original Dash Cam Twister’s default settings are for TODC Twister to automatically power on and begin recording when TODC Twister is connected to a power source. Once the vehicle’s 12v... -
Page 16: Manual Power On/Off And Reset
outlet is powered on, and TODC Twister is connected, TODC Twister will automatically turn on and begin recording. When TODC Twister is unplugged, or otherwise disconnected from the power source, TODC Twister will automatically power down and save your footage. 2.5.2 Manual Power On/Off and Reset 2.5.2.1 Manual Power On... -
Page 17: Resetting The Device
footage will be stored on TODC Twister’s microSD card. Caution: removing the microSD card before powering off TODC Twister will corrupt your files and you will lose your footage. 2.5.2.3 Resetting the device If TODC Twister begins to function abnormally for any reason, try resetting TODC Twister. -
Page 18: Connecting As A Bluetooth Speaker
3. Press the OK Button, choose SD Card. You will be asked to confirm the format – if you are sure you wish to perform the format, use the OK Button to select OK. Note: 1. It is recommended you perform a format before using TODC Twister for the first time. -
Page 19: Basic Setup
2.6 Basic Setup Before using TODC Twister, we recommend setting up the correct Date and Time. Note: To access setup menus, TODC Twister must NOT be recording. Menus cannot be accessed while TODC Twister is recording. 2.6.1 Set the Date / Time To set the correct date and time, do the following: First be sure TODC Twister is NOT recording. - Page 20 Menu Button to return to the main recording screen. Note: 1. The Original Dash Cam Twister runs on a 24 hour military clock. 1:00pm shows as 13:00 on TODC Twister’s clock. For questions regarding the 24 clock, contact TODC at...
-
Page 21: Using Todc Twister
1, 3 or 5 minute video clips. 3.1.2 Emergency Recording The Original Dash Cam Twister has a built in emergency recording function which, when activated, prevents video files from being overwritten by TODC Twisters Loop Recording feature. To manually... -
Page 22: The Recording Screen
When the Emergency recording function is activated, one looping cycle will be locked, recording will return to normal when the next loop begins (Caution: formatting the memory card will erase all files, including emergency protected files!). Note: 1. If the G-Sensor function is enabled and a collision is detected, emergency recording will automatically be triggered. - Page 23 Icon Item Description Video Mode When on screen, indicates you are in video mode. Icon Loop Indicates the currently selected Recording video loop length (1, 3, or 5 minute) Icon Indicates your currently selected Exposure Exposure Value (EV). Date Stamp Indicates the current date.
-
Page 24: Motion Detection
When this icon appears screen, the IR sensors are turned IR Sensor on. To turn them off, while Indicator recording quick press the UP / IR Sensor Button. When this icon flashes on screen, it indicates that you are currently Recording recording. -
Page 25: G-Sensor
Use the Up or Down Button to highlight On and press the OK Button. Motion Detection is now enabled, press Menu to return to the home screen. Note: 1. When the battery is fully charged, Motion Detection can record continuously for about 25 minutes. - Page 26 Use the Down Button to highlight G-Sensor and press the OK Button. Use the Up / Down Buttons to highlight your desired sensitivity (2G is most sensitive, 8G is least) and press OK. Your desired G-Sensor settings are now saved, press the Menu Button to return to the recording screen.
-
Page 27: Playback Videos
Note: Caution: formatting the microSD card will delete all videos, including emergency locked videos. 3.2 Playback Videos 3.2.1 Playing Videos To playback video files on TODC Twister’s LCD screen, follow these instructions: Be sure TODC Twister is NOT recording. Press the Mode Button to enter Video Playback Mode. Use the OK Button to begin playing back the currently selected video. - Page 28 When your desired video is highlighted, press the OK Button to playback the video. When video is playing, the Up and Down Buttons control the volume. Once you begin playing back a video, you cannot select a different video until the video playback comes to an end.
-
Page 29: The Playback Screen
3.2.2 The Playback Screen Icon Item Description Playbac This icon indicates you are in video k Mode playback mode, ready to play a Indicator video. Embedd Time & Date ed Time This is the time & date stamp that is Stamp &... -
Page 30: Deleting Files
Icon Item Description Date in Indicates the date the video you are Video watching was recorded. Resoluti Indicates the resolution of the recorded video. Video Indicates the name of the video file File being played back. Name 3.2.3 Deleting Files To delete file(s), do the following: Be sure TODC Twister is NOT recording. - Page 31 Use the Down Button to highlight Delete and press the OK Button. Use the Down Button to highlight Delete Current to delete the currently selected video, or highlight Delete All to delete all footage from TODC Twister. You will asked to confirm your Deletion, if you are sure, use the Down Button to highlight OK and press the OK button.
-
Page 32: Adjusting The Settings
4 Adjusting the Settings 4.1 Using the Menu There are two setup menus that you can access; Video Settings Menu, and Setup Settings Menu. To access each settings menu do the following: Accessing the Video Settings Menu Be sure TODC Twister is NOT recording. Press the Menu Button to enter the Video Settings Menu. -
Page 33: Menu Items
Use the Up / Down Buttons to highlight different menu options in the Setup Settings Menu. Press the OK Button to enter the highlighted settings sub-menu. 4.2 Menu Items Refer to the below table for details of each menu option and its function. - Page 34 Available Menu Setting Description Options loops are easier upload social media. +2.0, +5/3, Adjusts +4/3, +1, +2/3, amount of light let Exposure. +1/3, 0, -1/3, TODC -2/3, -1.0, -4/3, Twister’s Lens. -5/3, -2.0 Motion On/Off Turn on/off. Detection When on, TODC Twister will record Record On/Off...
- Page 35 Available Menu Setting Description Options English French German Italian Spanish Change Portuguese Language language of the Simplified settings menus. Chinese Traditional Chinese Japanese Russian Korean Choose 60Hz for 50Hz Frequency North America, 60Hz 50Hz for Europe. When on, TODC Twister’s screen will shut off after chosen...
- Page 36 Available Menu Setting Description Options Perform a format when powering on TODC Twister for the first time. If experiencing memory issues, try formatting the card SD Card Format troubleshoot OK/Cancel (Caution: performing format will erase ALL files on the SD card including locked videos).
-
Page 37: Transferring Videos To Pc
5 Transferring Videos to PC 5.1 Using included USB Cable Included with TODC Twister is a microUSB cable, this cable will be used to transfer video from the Dash Cam to your PC. Follow these instructions to transfer videos to your PC: Connect the microUSB tip of the USB cable to TODC Twister. - Page 38 If the Auto Play pop-up box above does not appear on your computer once you have selected, Mass Storage on the camera; launch the My Computer application on your computer.
- Page 39 You will see a new disk drive named something similar “Removable Disk (E:)” – the letter following Removable Disk will vary from computer to computer. Double click on this disk to enter TODC Twister’s microSD card and navigate to the screen below.
- Page 40 Note: 1. For additional assistance transferring files from TODC Twister to your computer, contact The Original Dash Cam team at www.GetDashCam.com Copyright © 2015 All rights reserved. All other marks, products or company names mentioned in this guide are...
