- Page 1 DAN User manual...
-
Page 2: Introduction
Introduction Congratulations on purchasing your Dive System computer. Dive System, with the quality of its products, has always been at your side to guarantee comfort, en- joyment and safety in diving. The Dive System computer that you purchased is an extremely modern computer which includes com- prehensive software for recreational and technical diving. -
Page 3: Table Of Contents
Table of Contents Introduction ________________________ 2 Settings ____________________________ 28 Dive set ___________________________ 30 Table of Contents ____________________ 3 P. Safety - Security Level ______________ 30 Cautions ___________________________ 5 Safety Stop _______________________ 32 General instructions _________________ 5 Deep stop ________________________ 33 Danger warnings ___________________ 7 Max P P O2 ________________________ 34 Nitrox Diving ______________________ 9... - Page 4 Summary iDive - the data on the surface __________ 62 PC Mode __________________________ 47 Sys Set ____________________________ 48 iDive after immersion _________________ 63 UTC - Time zone ____________________ 48 No-Fly ____________________________ 63 Time ____________________________ 49 iDive in Gauge ______________________ 64 Format __________________________ 49 Gauge ____________________________ 64 Date ____________________________ 50...
-
Page 5: Cautions
This User’s Guide contains certain hazards and should be carefully read. • It is essential to read this user manual before using the Dive System computer. The incorrect use of the computer or its accessories will void the warranty and may cause permanent damage to the computer itself and / or its accessories. - Page 6 Cautions Oxygen Toxicity even if the diver scrupulously and correctly follows the instructions of dive tables or computers. • The computer is not able to take into account individual physiological variations that can alter day to day and for this reason it is good practice to use this instrument in a conservative and precau- tionary manner, remain well within the limits set by the computer in order to minimize the risk of decompression sickness and oxygen toxicity to the central nervous system.
-
Page 7: Danger Warnings
Cautions Danger warnings • The computer is NOT intended for PROFESSIONAL use! The computer is intended for sports use only. • Non compliance to the above may expose the diver to an increased risk of incurring decompression illness (DCI) It is therefore not recommended for commercial or professional diving. • Before diving you must check the battery level, DO NOT dive with the battery level of 30% or lower, check that the display does not show any sign of malfunction and that it is legible. - Page 8 Cautions • Keep in mind that our body has daily variations of which the computer cannot take into account. • You must avoid all behavior that increase risks associated with decompression sickness such as rapid ascents, yo-yo diving, decompression stop obligations, dives with surface intervals too close toge- ther and by any other behavior not dictated by common sense and training.
-
Page 9: Nitrox Diving
Cautions speed, observing the depth stops displayed helps meet this duration. • No FLY Time: it is prohibited to board a plane if the NO FLY TIME icon on the display is still on. Re- member to plan the last dive of the series taking into account the recommendations provided by DAN (Divers Alert Network). -
Page 10: Before A Dive
Cautions • Diving with Nitrox requires specific training, DO NOT dive without due training. Exceeding the maxi- mum PpO2 settings and those recommended imposes an immediate ascent to a lower level and in the event of a CNS value (Central Nervous System) approaches the recommended limits we advise a reduction of oxygen exposure. -
Page 11: Limits Of The Dive Computer
Cautions Limits of the dive computer • The computer reflects the latest guidelines on diving safety but keep in mind that these studies are to be considered of theoretical basis and processed to reduce but not eliminate the risk of de- compression sickness. - Page 12 Cautions unit is controlled periodically from the point of view of accuracy in reading, the depth and time. The level of precision required by European standards is +/- 3.5%. • The warranty is voided if the endcap is removed from a non-authorized service center. • The computer iDive is built to withstand use in sea water but at the end of the dive you have to rinse well with fresh water and do not expose to direct sunlight or heat sources to dry.
-
Page 13: Specifications
Specifications Your computer is made in all stainless steel 316L with mineral glass, allowing in this so a high impact resistance and corrosion resistance. Display is equipped with an LCD Display 100% matrix. Particular effort has been put in the development of a navigation system that allows the diver access to the settings in an easy and intuitive. - Page 14 Specifications - Maximum error in the measurement of temperature: -2 / +6°C - Algorithm The computer adopts the model Buelhmann ZHL-16B and offers a choice of 4 levels of conservatism 0 Values of Gradient Factor High 93- Gradient Factor Low 93 1 Values of Gradient Factor High 91- Gradient Factor Low 91 2 Values of Gradient Factor High 89- Gradient Factor Low 89 3 Values of Gradient Factor High 75- Gradient Factor Low 73...
- Page 15 Specifications - Update tissue dive mode: 5 seconds. - Update tissues sleep mode: 1 minute. - Number of stored gas OC: 3. - Memory: 100 hours of immersion. - 100 hours of immersion. 1999 min. - Intuitive software for adaptive logic. - Connection to PC: USB cable - Firmware upgradeable.
- Page 16 Specifications - Battery It has a rechargeable battery with an autonomy of 25 days in clock mode, or 30 hours of diving. Perform a full charge cycle before the first use. The charge is made by connecting the computer via its USB cable to the PC or to a any USB port. The data shown may vary by +/-15%.
- Page 17 Specifications - Weight: 140gr - 100% compatible with the program of data collection DAN DL7 DSL Level 5 100% compatible with DAN DL7...
-
Page 18: Menus And Functions
Menus and Functions WATCH MODE iDive DIVE UNIT INFO MODE iDive GAUGE MENU & MODE SETTINGS iDive FREE MENU & MODE SETTINGS iDive MENU & SETTINGS... -
Page 19: Backlight
30%. To autonomy less than 30% the symbol will remain free always in evidence. model Information number rmware DIVE SYSTEM of serial version To view information click once on the button A if you are screen bat- iDive S/N: 900123 tery level. -
Page 20: Compass
Menus and Functions Compass weather To view the compass press once on the D if you are in screen battery lubber line, level. compass direction grade Turning the clock compass indicates the direction in front of us. 54° altitude sea level 200m +27°C 990mb... - Page 21 Menus and Functions The table below shows the meaning of each of the short for direction on the display: 54° Direction Meaning Direction Meaning 200m North Northeast +27°C 990mb East Southeast iDive South Southwest West Northwest...
-
Page 22: Weather
Menus and Functions Weather iDive also shows you the weather forecast. stable To view the weather forecast press once on the INFO button if you are in screen battery level. The next table shows how to interpret the weather forecast of the iDive worsening improvement in The weather forecast is based on the monitoring of atmospheric pres-... -
Page 23: Atmospheric Press., Altim. And Temp
weather Menus and Functions lubber line, compass direction grade Atmospheric pressure, altimeter and temperature 54° altitude To view information about atmospheric pressure, altimeter and tem- sea level 200m +27°C 990mb perature press the INFO button once if you are in the screen battery iDive level. - Page 24 Menus and Functions Through the function in the DISPLAY menu you can change the unit in ° C or ° F. When instead of the indications of the compass appears CALIBRATE you have to re-calibrate the compass. CALIBRATE You can calibrate the compass by following the instructions that you 200m find in the section “Compass”.
-
Page 25: Clock
Menus and Functions Clock The computer area has the functions of a clock with hour, minute, hour day, month, and day of the week. day of the 20:31 week 28/02 iDive day/month Dive To activate the Dive to dive you have to press the B button twice. depth time Once you enable this feature you can dive using air, programmed... -
Page 26: Gauge
Menus and Functions Gauge atcive setup depth To activate the Gauge to immerse you have to press the B button 3 dive time times. This function remains active for 15 minutes after the time clock GAUGE screen appears. count 3:00 With this function you can immerse yourself in using your clock as a down temp... -
Page 27: Free Dive
Menus and Functions active depth Free Dive setup To activate the Free Dive to immerse you must press the B button 4 times. FREE This function remains active for 15 minutes after the time appears. time DIVE DEPTH WARNING: If you do not set any function at the beginning dive the clock starts running DIVE. -
Page 28: Settings
Settings The computer comes standard with settings that allow for recreational diving, then dive up to 40 me- ters, within the no-decompression limits and without the use of gas decompression, without having to modify any parameter of your computer. If you proceed to make dives that make it necessary switches in decompression gases Nitrox you will need to set and enable the gas that will be used during the dive.. - Page 29 Settings iDive menu provides access to functions and settings are changed. To enter the menu, press the B button before entering the Dive screen and then press the A button WATCH MODE iDive DIVE UNIT INFO MODE iDive GAUGE MENU &...
-
Page 30: Dive Set
Settings By pressing the B or D from the main screen menu, you can scroll throu- gh the various menu items. When you see the name of a function you must press the A key to ac- cess the function. DIVE SET PLANNER Dive set... - Page 31 Warning: he control parameters of the conservatism of the algorithms need to be modified only and only if you have appropriate theoretical knowledge. Dive System is not responsible for damage to persons or property due to an incorrect setting of these parameters.
-
Page 32: Safety Stop
Settings Safety Stop Setting the timer to the safety stop. The timer for the safety stop will start automatically when the end of p.safety: the dive, you will reach a depth less than 6 m are you have performed safety stp: all decompression stops. -
Page 33: Deep Stop
Settings Deep stop In iDive you can enable or disable the deep stop. Press the B or D to set YES or NO and then the A button to confirm the setting. p.safety: safety stp: The stop is calculated in the middle of the maximum depth for a time deep stp: of 2.5 minutes. -
Page 34: Max P P O2
Settings Max P P O2 The value of PpO2 max determines the maximum operating depth (MOD) in relation to the mixture of oxygen used. Press the B or D to set increase or decrease the value and then the A p.safety: safety stp: button to confirm setting. -
Page 35: Salt And Fresh Water
Settings Salt and Fresh water iDive measure the pressure and converts it into depth using the density water as a constant. p.safety: safety stp: The depth of 10 m in salt water corresponds approximately to 10.3 m in deep stp: max ppo 1.60 fresh water. -
Page 36: Mix
Settings Press B or D key in order to scroll the various menu items and then the A button to confirm the setting. DIVE SET With iDive you can set more gas mix (Nitrox) PLANNER LOGBOOK ALARM iDive Mix 1 Press B or D in order to increase or decrease the percentage of oxygen and A to confirm the o2 percentage inserted. -
Page 37: Mix 2
Settings Mix 2 Press B or D in order to increase or decrease the percentage of oxygen and A to confirm the O2 percentage inserted. iDive automatically calculate the MOD. MIX 2 O2%: MOD: 29 Press A in order to move to NEXT and set the Mix 2. DECO: YES exit next... -
Page 38: Planner
Settings Planner Press B or D in order to scroll through the various menu items and press A to set Planner function. DIVE SET With iDive can plan your repetitive dives. PLANNER LOGBOOK ALARM iDive Press B or D in order to increase or decrease the percentage of oxyge- nand press A to confirm Press A to set the surface time and press B or D to increase or decrease PLANNER... - Page 39 Settings Press B to next table . Press B in order to exit form Planner function PLANNER PLANNER PLANNER depth time depth time depth time next next next iDive iDive iDive PLANNER ATTENTION: depth time If you find Dash line it means that this depth can not be planned in according with the MOD set.
-
Page 40: Logbook
Settings Logbook By pressing the B or D you can scroll through the various menu items. Pressing A will access the function. DIVE SET iDive store profiles of about 100 hours of diving. The data can be tran- PLANNER LOGBOOK sferred to a PC using the software DiveLogger ALARM iDive... - Page 41 Settings In the logbook menu is displayed a summary page number of that shows each dive that contain the following protection dive factor information: - Progressive number of dives dive time - Protection level start date 26.01.13 10:47 - Date dive - Hour time...
-
Page 42: Alarm
Settings Alarm By pressing the B or D button you can scroll through the various menu items. DIVE SET Pressing A will access the function. PLANNER LOGBOOK With this function you can set the alarms. ALARM iDive ASC Speed By pressing the B or D button can be activated alarm (YES) or disable (NO) the alarm of scent speed. -
Page 43: Max Depth
Settings Max Depth By pressing the B or D button you can activate (YES) or disable (NO) alarm of maximum depth. the maximum depth depending on the PpO2 set and the gas used. asc speed: yes max depth: deco viol: yes Press A to confirm the setting and move to the next setting. -
Page 44: Display
Settings Display By pressing the B or D button you can scroll through the various menu items. DISPLAY Pressing A button will access to this function. PC MODE SYS SET DEFAULT This function allows you to adjust the display. COMPASS iDive BKL Level By pressing the B or D button it is possible to increase or decrease the... -
Page 45: Bkl Time
Settings BKL Time By pressing the B or D button it is possible to increase or decrease the duration of the back light, from 1 to 30 seconds. bkl level: Press A to confirm the setting and move to the next setting. bkl time: contrast: units:... -
Page 46: Units
Settings Units By pressing the B or D button you can set the unit metric or imperial system, m/°C - ft/°F. bkl level: Pressing A in order to confirm the value. bkl time: contrast: units: °C Pressing D button to return to watch mode. exit iDive... -
Page 47: Pc Mode
Settings PC Mode By pressing the B or D you can scroll through the various menu items. DISPLAY Pressing A button in order to computer connection (PC) to download PC MODE the dive profiles (Dive Logger) SYS SET DEFAULT By connecting the iDive to the PC also the battery is recharged. COMPASS iDive PC MODE... -
Page 48: Sys Set
Settings Sys Set By pressing the B or D button you can scroll through the various menu items. DISPLAY Pressing A button will access to the function. PC MODE SYS SET DEFAULT This function allows you to set the time zone, date, time and the format COMPASS iDive UTC - Time zone... -
Page 49: Time
Settings Time Set the hour and minutes. Pressing the B and D buttons to set the time. UTC: 1:00 UTC: 1:00 TIME: 20:46 Pressing A to move to minutes set and B or D TIME: 20:46 FORMAT: FORMAT: to set the minutes. DATE: 28.02.2013 DATE: 28.02.2013 exit... -
Page 50: Date
Settings Date Is possible to set day, month and year. Press the B and D buttons to select the exact day. UTC: 1:00 TIME: 20:46 FORMAT: Pressing the A button to confirm the setting and changes the setting of DATE: 28.02.2013 the month and once you set the month, press the A button to confirm exit the setting changes the setting of the year. -
Page 51: Default
Settings Default By pressing the B or D button you can scroll through the functions. Pressing A button in order to access. DISPLAY PC MODE SYS SET Default set will reset the iDive to the factory value DEFAULT COMPASS iDive Select with the B button the NO or YES and confirm with A button. -
Page 52: Compass
Settings Compass By pressing the B or D you can scroll through the functions. Pressing A button in order to access . DISPLAY PC MODE With this function you can calibrate the compass and also the declina- SYS SET DEFAULT tion and direction. -
Page 53: Dir
Settings By pressing the B or D button’s you can set the direction, EAST or WEST.. The direction is used to indicate the direction of the declination of the DECLIN: Earth magnetic field. DIR: EAST CALIB: START Pressing the A button to confirm the setting and to move to the next exit setting. - Page 54 Settings Turn the computer on the horizontal plane up to TILT indication appear. DECLIN: DIR: EAST CALIB: TILT exit iDive Rotate around the longitudinal axis until no signal appears OK as showed in the picture. Now the compass is calibrated. DECLIN: DIR: EAST...
-
Page 55: Idive During Diving
iDive during diving Dive depth dive time iDive has been studied to provide to be user friendly during the dive. 20.0 This can helps the diver to receive the most important and clear in- decompression formation’s. limit m/min 38.4 iDive max depth performed 20.0... -
Page 56: Cns And Temperature
iDive during diving CNS and temperature During the dive by pressing the B button once at the bottom the di- 20.0 splay shows the data for the CNS, on the left, and temperature on the right. Pressing the B button again shows the graph of the dive. TEMP °C iDive... -
Page 57: Extra Safety Stop
iDive during diving Extra Safety Stop In the event that you have set the safety stop, which is recommen- ded for all dives, as per the instructions of paragraph Dive Set this STOP will be displayed on the computer display during ascent from depth of 6.9 m. -
Page 58: Deep Stop
iDive during diving Deep Stop If you set Deep Stop function it appears 5m before the actual depth required and will be removed, if not done, 5 m after the required 20.0 depth. DEEP STOP The display has been designed so that the deep stop data will show in the middle of the display. -
Page 59: Deco Dive
iDive during diving Deco dive If the diver is required one or more mandatory decompression stop, not recommended, the central part of the display will be totally on a black background to draw attention to the diver. In the middle left STOP DECO of the display is the total time of ascent (TTS), is located next to the... -
Page 60: Dive Compass
iDive during diving Dive compass Dive compass Pressing the D key to access to underwater navigation. In the upper part of the screen shows the direction (Grade ). In order to set a shipping lane press B. 275° => As long as the direction that we are following is within the +/- 5 ° from the set course is shown the value of the direction. -
Page 61: Switch Gas During Dive
iDive during diving Switch gas during dive If you have set one or more decompression deco gas (maximum 3), when you get to the depth determined by the MOD of the first deco CHANGE MIX gas, the display starts flashing the current gas in the lower left. EAN 50 Pressing the A key you enter in switch gas screen . -
Page 62: Idive - The Data On The Surface
iDive - the data on the surface Once on the surface and 10 minutes has elapsed, by pressing the B button, you will see some important post-dive data as: • Desaturation Desat 11:47 No Fly 11:47 • No Fly Time Surf Time 00:12 • Surface... -
Page 63: Idive After Immersion
No-Fly Dive System recommended to follow the DAN Pre flight interval gui- delines The current indications (DAN http://www.diversalertnetwork.org/me- dical/ faq / faq.aspx? faqid = 54) recommend: • A minimum surface interval of 12 hours after a single dive before boarding a commercial aircraft. • An interval of at least 24 hours to divers using scuba for several days or for repetitive dives or dives have required mandatory decompres- sion stops. -
Page 64: Idive In Gauge
iDive in Gauge Gauge depth This mode allows you to use your computer as a common depth. time iDive has the ability to set a countdown. 30.0 gauge The iDive is set by default with a time to count down to 3 minutes. count 3:00 down... - Page 65 iDive in Gauge Pressing the A button in order to show T + + or T- -. Pressing the B button you can decrease the time to a minimum of 30.0 gauge 0:30 4:00 T - - TEMP 31.8 °C iDive...
-
Page 66: Idive In Free
iDive in Free ATTENTION: This function is not available and can not be accessed if the user have dived ,within 24 hours with Dive Mode or Gauge mode. Free mode during dive 19.2 FREE If your diving computer is set in Free mode this function will be main- tained for 15 minutes after which it will return in the Watch mode. -
Page 67: Free Mode On The Surface
iDive in Free Pressing the B button the display will show the temperature of the 13.1 FREE water on the left and on the right the maximum depth reached during the entire session dive. TEMP °C 25.5 iDive Free mode on the surface On the surface iDive shows the data of the last dive, on the left the FREE depth at zero value and on the right the button time of the last dive. - Page 68 ©2015 DiveSystem www.divesystem.com...
