GB
AWT 5108/4
Care
Programme
Labels
Cotton with prewash
Heavily soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and linen.
Heavily soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira), polyamide (Perlon,
Synthetic with prewash
Nylon) or blends with cotton.
Delicate with prewash
Heavily soiled curtains and delicate clothing, dresses, skirts, shirts and blouses.
Cotton
Normally to heavily soiled bed linen, table linen and underwear, towels, shirts etc. made of cotton and linen.
Coloured Cotton
Normally soiled bed linen, table linen and underwear, towels, shirts etc., made of cotton and linen.
Daily Mixed
Slightly to normally soiled textiles made of cotton and/or synthetics.
Mixed cotton/
Normally to heavily soiled blouses, shirts, overalls etc. made of polyester (Diolen, Trevira), polyamide
Synthetic
(Perlon, Nylon) or blends with cotton.
Synthetic
Normally soiled overalls and sportswear made of cotton, polyester, polyamide and blends with cotton.
Delicate
Curtains and delicate clothing, dresses, skirts, shirts and blouses.
Only woollens with a felt-free finish, labelled with the woolmark and identified as machine washable.
Wool
If you select "Rinse Hold" do not leave items to soak for too long.
Textiles made of silk, linen, wool and viscose marked as "handwashable".
Handwash
If you select "Rinse Hold" do not leave items to soak for too long.
Rinse + Gentle Spin
Programme for treating delicate laundry with starch or softener.
Rinse + Spin
Programme for treating cotton or linen laundry with starch or softener.
Spin
Programme to spin cotton or linen laundry intensively with maximum spin speed.
Gentle spin
Programme to spin delicate laundry gently with a restricted spin speed.
Drain
Drain only - no spinning. Alternative method of terminating programme after "Rinse Hold".
N.B. This machine is controlled by sensors. Please avoid excessive detergent dosing.
A
B
C
D
Type of wash / Notes
A. Programme Selection Knob
B. Temperature Selection Knob
C. "Spin Speed Selection" Knob
D. "On/Off" Button
Max.
Detergents and additives
load
Prewash Main
Wash
kg
5.0
Yes
1)
Yes
2.0
Yes
1)
Yes
1.5
Yes
1)
Yes
5.0
Yes
3.0
Yes
3.0
Yes
2.0
Yes
1.5
Yes
1.5
Yes
1.0
Yes
1.0
Yes
2.0
5.0
5.0
2.0
Cold
: option / Yes: dosing required
1)
Do not use liquid detergents.
2)
For improved garment care, spin speed is restricted to
800 rpm in this programme.
3)
For improved garment care spin speed is null in this
programme.
Special Options
Softener Bleach Rapid
Half
Intensive
Rinse
Load
Rinse
Hold
Whirlpool is a registered trademark of Whirlpool USA
5019 312 10149
Tempera-
Max.
ture
Spin
Speed
°C
rpm
Max. 90
1000
Max. 60
800
2)
Max. 40
800
2)
Max. 90
1000
Max. 60
1000
Max. 60
1000
Max. 60
800
2)
Max. 60
800
2)
Max. 40
800
2)
Max. 40
800
2)
3)
Max. 30
800
2)
1000
1000
800
2)
