- Page 1 MODEL • DYNA TWC 901 • DYNA TWC 902 Operating Manual (Owner’ s Manual) IMPORTANT: Read these instructions before installing, operating, or servicing this system. First Edition Manual No. ET001...
-
Page 3: Table Of Contents
CONTENTS SYMBOL LEGEND---------------------------------------------------------------------------------------------------2 STATEMENT OF WARRANTY------------------------------------------------------------------------------------3 GENERAL INFORMATION-------------------------------------------------------------------------------4 1.01 Notes, Cautions and Warnings------------------------------------------------------------------------4 1.02 Important Safety Precautions--------------------------------------------------------------------------4 1.03 Transporting methods-----------------------------------------------------------------------------------6 INSTALLATION RECOMMENDATION----------------------------------------------------------------7 OPERATOR CONTROLS---------------------------------------------------------------------------------8 SPECIFICATIONS------------------------------------------------------------------------------------------9 PARTS LIST--------------------------------------------------------------------------------------------------9 REMARK-----------------------------------------------------------------------------------------------------12 - 1 - DYNA TWC 901、902 Operating Manual... -
Page 4: Symbol Legend
Gas Post-Flow Time 2T (GTAW) Gas Pre-Flow Time Voltage Reduction 4T (GTAW) Device Circuit — Repeat Function (GTAW) Negative Spot Function (GTAW) Positive High Frequency Starting Gas Input (GTAW) Lift Start （GTAW） Gas Output - 2 - DYNA TWC 901、902 Operating Manual... -
Page 5: Statement Of Warranty
FCW ‘ s sole option, of any components or parts of the product determined by FCW to be defective. -
Page 6: General Information
Do not use the welding torch in an area where combustible or explosive gases or materials are located. Phosgene, a toxic gas, is generated from the vapors of chlorinated solvents and cleansers. Remove all sources of these vapors. - 4 - DYNA TWC 901、902 Operating Manual... - Page 7 Wear welding gloves and suitable clothing to protect your skin from the arc rays and sparks. Keep helmet and safety glasses in good condition. Replace lenses when cracked, chipped or dirty. Protect others in the work area from the arc rays. Use protective booths, screens or shields. - 5 - DYNA TWC 901、902 Operating Manual...
-
Page 8: Transporting Methods
Lift unit with handle on top of case. Use handcart or similar device of adequate capacity. If using a fork lift vehicle, place and secure unit on a proper skid before transporting. - 6 - DYNA TWC 901、902 Operating Manual... -
Page 9: Installation Recommendation
Ambient temperature: between -10 degrees C for cooling. to 40 degrees C. WARNING 1 FCW advises that this equipment be electrically connected by a qualified electrician. - 7 - DYNA TWC 901、902 Operating Manual... -
Page 10: Operator Controls
Main Power Switch— Switching to the ON position power source. WARNING When the welder is connected to the primary supply voltage, the internal electrical components maybe at primary potential with respect to earth. - 8 - DYNA TWC 901、902 Operating Manual... -
Page 11: Specifications
220V 1ph 50/60Hz Input Current 3.4A 1.7A Duty Cycle (40º C) 100% 100% Flow 3.0L/min 3.0L/min Pressure 0.121MPa 0.121MPa Capacity 7Litre 7Litre Weight 15kg 15kg Dimensions (mm) 530*260*320mm 530*260*320mm Table 1 PARTS LIST - 9 - DYNA TWC 901、902 Operating Manual... - Page 12 Figure 2 - 10 - DYNA TWC 901、902 Operating Manual...
- Page 13 FAN D200 4WER001D200 CONDENSATOR 240*185*90 4WER001 FUSE HOLDER 4FUSH15X250XD6 FUSE 5A D6*30 4FUS6X30X5A FUSE 3A D6*30 4FUS6X30X3A HOSE WATER 13*18 8HPVCG13X18 POWER SUPPLY LINE 3*1MM 8FCWWC3X1BK Remark transformer 380-200V-110V (100A) 3EER32001 Table 2 - 11 - DYNA TWC 901、902 Operating Manual...
-
Page 14: Remark
Storing ambient temperature is -25℃~ +55℃. When long-time does not use, every two months should electrify a time, a humidity month of every two week should electrify use a time, by use own thermal row of tide. - 12 - DYNA TWC 901、902 Operating Manual...
