Reverend Guitars

Reverend Hellhound Amplifier Owner's Manual

CAUTION!

Do not open amp chassis - risk of fatal electrical shock.

No user serviceable parts inside amp.

Never operate in damp or wet conditions.

Tube and chassis surfaces very hot.

High volume use can cause permanent hearing damage - always use ear protection.

SET-UP PROCEDURE

INSTALL POWER TUBES - To prevent damage, power tubes are shipped in boxes inside

cabinet.

Lay amp face down on non-damaging surface. Be sure amp is unplugged.

Unscrew and remove back panel.

Install power tubes. Alignment pin protruding from center of tube MUST align with hole

in tube socket - pin has ridge that MUST align with groove in socket hole. Push tubes

in firmly.

Re-mount back panel.

POWER UP AMP - Plug in amp. Turn VOL all the way down. Make sure speaker is

connected to speaker jack. Turn amp on. Amp is now ready to use.

READ ENTIRE OWNER'S MANUAL BEFORE OPERATING! - Please read manual carefully

to achieve maximum performance and maintain safe operation of your amp.

FRONT CONTROL PANEL

ON - Powers amp. WARNING: Always have a speaker connected to the amp before turning

on, otherwise serious damage could occur to amp! VOL should be turned all the way down

before turning amp on or off. Leave amp on during short break periods, simply turn down the

volume on your guitar or amp.

SCHIZO - UK mode introduces an upper-midrange boost, similar to the classic British amps

with increased overdrive and note clarity. US mode has less midrange, similar to the classic

American amps with a cleaner, softer sound.

GAIN - Controls the amount of overdrive. Higher settings produce more distortion, lower

settings produce a cleaner sound. GAIN will affect the volume level, but this can be adjusted

with the VOL control.

VOL - Controls the overall volume. For the cleanest possible sound set VOL to maximum

and use the GAIN control as your volume control.

TREB - Controls treble frequencies. TREB control is more responsive when the MID control

hellhound_manual.html[6/30/2015 11:36:47 AM]

Page 1 Reverend Guitars Reverend Hellhound Amplifier Owner's Manual CAUTION! Do not open amp chassis - risk of fatal electrical shock. No user serviceable parts inside amp. Never operate in damp or wet conditions. Tube and chassis surfaces very hot. High volume use can cause permanent hearing damage - always use ear protection.
Page 2 When using two cabinets that have the same ohm rating, a Y adapter (available from Reverend) must be used to run both cabinets into one jack. Total ohm rating will then equal half of one cabinet (example: two 8 ohm cabinets will equal 4 ohms, so use the 4 ohm jack with a Y adapter).
Page 3 Reverend Guitars PRE-AMP TUBES - Use 12AX7 type only. Replace when noisy or malfunctioning. Selected tubes available from Reverend. 1st PRE-AMP TUBE - This is the tube farthest to the right when facing the back of the amp. 12AX7 is stock, however a 12AT7 tube may be substituted for more clean headroom - see Sample Settings.
