Summary of Contents for avd Confidea G3
- Page 1 Quick Guide Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 2 Charge the batteries when you receive system! Do not transport system with batteries in charger! 12 battery charger Please note that G2 and G3 systems are not compatible! Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 3 Do not charge with the lids on the chargers as there is a heat build up. Do not charge after use if going back into storage as it is best to leave batteries at about 50% charge if stored for a prolonged period. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk...
- Page 4 Stage 1 Power the Access Point Plug in PSU and switch on Stage 2 Put together the microphone bases Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 5 Stage 4 Press the microphone button on each unit in sequence. The lights will flash as the microphone is registered onto the system via the access point. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 6 The default mode of operation is ‘Direct’ where microphones can be switch on and off at will. When used in ‘Request’ mode the microphone lights green and the Chair can make the next speaker live by pressing ‘B’. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk...
- Page 7 The out put is a standard balanced line level analogue audio signal and can connect to a PA system, a Recording device, a Video / Telephone conference codec, or any other audio device. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 8 Connect external audio to the Access Point via the TRS Jack socket marked ‘AUX BALANCED‘ This allows the speakers in the microphone bases to carry other audio sources or a full mix of audio. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 9 Click on the ‘cogs’ Audio routing ‘Distance conferencing’ to access settings The above are different to ‘Factory Reset’ defaults menu and should be adjusted after a reset. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 10 Once connected you will be asked to log in, the default log in is ‘admin’ and ‘admin’. Please refer to the system manual for further information and functionality. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 11 Point server control. This will allow the microphone speakers to carry all audio but remove incoming VC audio from the audio going back to the VC so eliminating feedback / echo. Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk...
- Page 12 Top table Cabaret tables Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 13 Top table Classroom tables Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
- Page 14 Boardroom table Seated observers Title: Guide to Confidea G3 Wireless Microphones AV Department Limited www.avdept.co.uk 01383 825709...
