According to operating instructions, motorized door installer and the manufacturer of the machinery have the same obligations: The technical documents and the annex to the AD425S Automatic Door Operator must be kept and placed at the disposal of competent national authorities for at least 5 years from the manufacturing dates.
Website: www.gianni.com.tw Herewith declares that AD425S Automatic Door Operator for swing doors: (One way direction only.) AD425S Automatic Door Operator can not be installed with other mechanism except electric door locks. Conformity with other CE directives: Electromagnetic Compatibility Directive 2004/108/EC(EN61000-6-1、...
Page 4
Input/Output Contact Description Remark PUSH HOLD Make sure the power input is applied correctly (AC110 or 220V). When turn on the power switch, it enters a learning mode. OPEN Power Switch AD425S Operating Arm turns clockwise. (See P. 9 Figure 5~8)
Page 5
AD425S Operating Arms turns counter-clockwise. (See P. 9 Figure 5~8) PUSH HOLD DIP3 switch “2”, when the external pressure force either “WIND” or “MAN MADE FORCE” occurs, AD425S can Locked be manually opened and closed or change to automatic mode by using “GO” switch.
Page 6
Automatic Door Operator Manual PUSH HOLD Jumper 1-8 is N.C., or using the “OPEN” switch. AD 425S becomes automatic mode when the connector is N.O. or using the “HOLD” switch. And then change to automatic mode by using “OPEN” switch. *Default is “OPEN”...
Page 7
Automatic Door Operator Manual Parameter illustration table Opening and Total Opening Maintain-open Opening and Maintain-open Time (See P. 8 Closing and Closing Closing Speed Time Adjustment Figure 4) Operation Time fastest 13 sec. 1 sec. fast 15 sec. 5 sec. slow 20 sec.
Automatic Door Operator Manual Specification Power Input 110V (or 220V) AC 50-60Hz Current (See Figure 2) 3A max., 0.6A average Torque 35Nm Opening/Closing time (VM) See P. 6 90° Maintain - Open time (TC) 1, 5, 10, 20 sec. Battery Specification 12V 1.2AH Temperature -20°C~+55°C (Battery 5°C~40°C)
TC Maintain time is main-open time. Prepare the installation To mount the AD425S depends on the direction way of the doors, out-swing, in-swing, right-hand and left-hand doors by adjusting the F/R switch and the direction of the Operating Arm. For the safety reason, AD425S must be installed indoor.
Page 10
Automatic Door Operator Manual Figure 5: For right-hand, out-swing door. F/R switch set 「ON」. Operating Arm mounts to left-side. Figure 6: For left-hand, out-swing door. F/R switch set 「1」. Operating Arm mounts to right-side. Figure 7: For right-hand, in-swing door. F/R switch set 「1」. Operating Arm mounts to left-side. Figure 8: For left-hand, in-swing door.
Page 11
Install AD425S on an in-swing door, make sure that the distance between Square Couplings and hinge is not more than 74mm , the space between header and the bottom of AD425S must be 23mm, and the space between header and Sliding Rail mounting hole must be 39mm (See Figure 16)
Page 12
Automatic Door Operator Manual AD425S Template Installation Instruction Figure 17: Out-swing door (Right-Hand Open) Figure 18: Out-swing door (Left-Hand Open) Figure 19: In-swing door (Right-Hand Open) Figure 20: In-swing door (Left-Hand Open)
Page 13
Installation Steps --Out-swing door( Right-Hand Open ) Step Figures Description Place the AD425S template to the right position on the door header. See the figure presented for an Step 1. out-swing door (Right-Hand Open), more details shown in P. 11 Figure 17 Step 2.
Page 14
Automatic Door Operator Manual Steps Figures Description Use Allen Wrench to tighten the Blind Nut. This will compress the screw so that it remains permanently Step 7. fixed in the hole. Repeat these steps on other Blind Nuts. (Do not over tighten the Blind Nut.) Blind Nuts Installation illustration Step 8.
Page 15
Automatic Door Operator Manual Steps Figures Description Use Allen Wrench to tighten the Blind Nut. This will compress the screw so that it remains permanently Step 12. fixed in the hole. Repeat these steps on other Blind Nuts. (Do not over tighten the Blind Nut.) Step 13.
Page 16
Automatic Door Operator Manual Steps Figures Description Step 18. Tighten screws. (6 pieces) Step 19. Mount the operating arm on Square Couplings. Insert screws (M6 x 16mm & gear-type washer) to the Operating Arm on Square Coupings, see the Step 20. figure presented for a out-swing door (Right-Hand Open), more details shown in P.
Page 17
Automatic Door Operator Manual Steps Figures Description Step 24. Attach two Side Ends. A Stopper Ball may be needed depending on the door Step 25. leaf opening angle. Optional electric lock, wireless push button, microwave sensor, reader and other accessories can be used with Step 26.
Automatic Door Operator Manual Steps Figures Description Step 30 Attach the Operating Arm cap. Make final settings and Please refer to page 3~6 for more details of the setting. adjustments Battery is located on the back of Control Board. Replace Remove the Fixing Plug and old battery, replace the battery new battery, then tighten the Fixing Plug.
Page 19
When the encoder is incorrect, please contact The Encoder may be automatically stops your local distributor. incorrect. before reaching the The AD425S stops operating preset destination. automatically when the door Recovery after 10 seconds. opening is interrupted for three times.
Turn the power on. Please ensure all switches are “ON”. Check the door movement stability. Check the condition of the hinges. Check all functions of the AD425S are working normally. Normal Operation: During maintenance, in case of malfunction or emergency, please ensure the power is “OFF” and the operator is working manually.
Page 21
The product must be used in visible place. The manufacturer will not be held responsible for any damage caused by improper use of this unit. Do not use the door closer with the AD425S. Do not put any obstacle in the door path when operating.
