Summary of Contents for Moving Air 10” FSe2
- Page 1 8” & 10” e² Subwoofer Installation Manual...
- Page 2 8” FS e² Subwoofer Installation Guide...
- Page 3 8” Subwoofer Installation with Passive Radiator • Recommended Cube Enclosure of outer dimension 250mm x 250mm x 250mm using 15mm (min.) to 25mm thick MDF board. • Box internal Volume needed is 8 (mins) to 10 liters (+/-10%). • Drivers Should be mounted back to back as shown below.
- Page 4 8” Subwoofer Driver Dimension...
- Page 5 8” Passive Radiator Dimension...
- Page 6 10” FS e² Subwoofer Installation Guide...
- Page 7 10” FS Subwoofer Installation with Passive Radiator • Recommended Cube Enclosure of outer dimension 300mm x 300mm x 300mm using 15mm (min.) 25mm thick MDF board. • Box internal Volume needed is 15.6 (min.) to 19.6 liters (+/-10%). • Drivers Should be mounted back to back as shown below.
- Page 8 10” e2 Subwoofer Driver Dimension...
- Page 9 10” e2 Passive Radiator Dimension...
