Page 1: Video Recorder
Digital Snitch Video Recorder User Manual Models: DTVI-DVR04H DTVI-DVR08H DTVI-DVR16H... -
Page 2: Table Of Contents
User Manual - Digital Snitch Video Recorder TABLE OF CONTENTS ...................... DVR Pre-Installation ......................DVR Installation ..................... Hard Disk Installation ......................... Front Panels ........................Rear Panels ....................Peripheral Connections ....................Wiring of Alarm Input .................... Wiring of Alarm Output ..................... - Page 3 User Manual - Digital Snitch Video Recorder Regulatory information FCC information This equipment has been tested and found to comply with the limits for a digital device, compliance: pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
-
Page 4: Trademarks And Registered Trademarks
User Manual - Digital Snitch Video Recorder Trademarks and Registered Trademarks Windows and Windows mark are trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries. HDMI, HDMI mark and High-Definition Multimedia Interface are trademarks or registered trademarks of ... - Page 5 User Manual - Digital Snitch Video Recorder Thank you for purchasing our product. If there is any question or request, please do not hesitate to contact dealer. This manual is applicable to 720P Turbo HD DVR...
-
Page 6: Dvr Pre-Installation
User Manual - Digital Snitch Video Recorder DVR Pre-Installation The HD-TVI series DVR is highly advanced surveillance equipment that should be installed carefully. Please take into consideration the following precautionary steps before installation of the DVR. 1. Keep all liquids away from the DVR. - Page 7 User Manual - Digital Snitch Video Recorder 3. Connect the power cable to the HDD. 4. Place the HDD on the bottom of the device and then fasten the screws on the bottom to fix the HDD. 5. Re-install the cover of the DVR and fasten screws.
-
Page 8: Front Panels
User Manual - Digital Snitch Video Recorder Front Panels Front Panel of 4/8/16ch DVR Description of Front Panel Name Function Description POWER POWER indicator turns green when DVR is powered up. STATUS STATUS indicator lights in red when data is being read from or written to HDD. -
Page 9: Rear Panels
User Manual - Digital Snitch Video Recorder Rear Panels The rear panel vaires according to different models. Rear panel of 4ch/8ch/16ch DVR Description of Rear Panel Item Description VIDEO IN BNC interface for TVI and analog video input. RCA connector... -
Page 10: Peripheral Connections
User Manual - Digital Snitch Video Recorder Peripheral Connections Wiring of Alarm Input The alarm input is an open/closed relay. To connect the alarm input to the device, use the following diagram. If the alarm input is not an open/close relay, please connect an external relay between the alarm input and the device. -
Page 11: Rs-485 And Controller Connection
User Manual - Digital Snitch Video Recorder 3. Connect pluggable block back into terminal block. RS-485 and Controller Connection For 4ch/8ch/16ch DVR To connect PTZ to the DVR: 1. Disconnect pluggable block from the RS-485 terminal block. 2. Press and hold the orange part of the pluggable block; insert signal cables into slots and release the orange part. -
Page 12: Specifications
User Manual - Digital Snitch Video Recorder Specifications Table 1 Specification Model 16ch Video compression H.264 Analog and HD-TVI video 4-ch 8-ch 16-ch BNC interface (1.0Vp-p, 75 Ω) input 720P/25, 720P/30, 720P/50, 720P/60, 1080P/25, 1080P/30, CVBS Supported camera types Video/Audio... - Page 13 User Manual - Digital Snitch Video Recorder Weight ≤ 1.5Kg (3.3lb) ≤ 2Kg (4.4lb) (without hard disks)
-
Page 14: Hdd Storage Calculation Chart
User Manual - Digital Snitch Video Recorder HDD Storage Calculation Chart The following chart shows an estimation of storage space used based on recording at one channel for an hour at a fixed bit rate. Bit Rate Storage Used 128K... -
Page 15: Accessing By Web Browser
User Manual - Digital Snitch Video Recorder Accessing by Web Browser Logging In You can get access to the device via web browser. Open web browser, input the IP address of the device and then press Enter. The login interface appears. -
Page 16: Recording
User Manual - Digital Snitch Video Recorder Name Description channel. Live View Window Displays the image of channel, and multi-window division is supported. Play Control Bar Play control operations are supported. Pan, tilt, zoom operations are supported, as well as preset editing and calling. -
Page 17: Playback
User Manual - Digital Snitch Video Recorder 1) Configure All Day or Customize Record: If you want to configure the all-day recording, please check the All Day checkbox. If you want to record in different time sections, check the Customize checkbox. Set the Start Time and End Time. -
Page 18: Log
User Manual - Digital Snitch Video Recorder 1. Click Playback on the menu bar to enter playback interface. 2. Click the camera from the device list for playback. 3. Select the date from the calendar and click Search. 4. Click the Play button to play the video file searched on the current date. -
Page 19: Menu Operation
User Manual - Digital Snitch Video Recorder Menu Operation Menu Structure Menu Playback Export Manual Record Camera Shutdown Configuration Maintenance Normal Record General Schedule General System Info Logout Event Advanced Encoding Image Network Shutdown Manual VQD Information Advanced Live View... -
Page 20: Live View
User Manual - Digital Snitch Video Recorder After the device starting up, the wizard will guide you through the basic settings, including edting password, date and time settings, network settings, HDD initializing, and recording. Live View Some icons are provided on screen in Live View mode to indicate different camera status. These icons include:... - Page 21 User Manual - Digital Snitch Video Recorder Select Add IP Camera in the pop-up menu to enter the IP Camera Management interface. The online cameras with same network segment will be displayed in the camera list. Click the button to add the camera.
-
Page 22: Record
User Manual - Digital Snitch Video Recorder You can edit the IP address, protocol, management port, and other information of the IP camera to be added. Click Add to add the camera. (For the encoders with multiple channels only) check the of Channel No. -
Page 23: Playback
User Manual - Digital Snitch Video Recorder Playback Play back the record files of a specific channel in the live view menu. OPTION 1: Choose a channel under live view using the mouse and click the button in the shortcut operation menu. -
Page 24: Backup
User Manual - Digital Snitch Video Recorder Backup Recorded files can be backed up to various devices, such as USB flash drives, USB HDDs or USB DVD writers. To export recorded files: 1. Enter Video Export interface. Choose the channel(s) you want to back up and click the Quick Export button.
