- Page 1 VDS4020 Active IP over Coax extended kit User Manual...
-
Page 2: Key Features
Supports P/T/Z (pan, tilt, zoom) cameras. • Up to 800 meters range with DC power transmission. 2. Technical Specification Model Number VDS4020 SPECIFCATION OF VDS4020-R SENDER Ethernet 10/100Mbps Ethernet standard Link Signal: Downlink 18MHz (output signal) Link OUT/IN with DC IN Downlink Signal Bandwidth: 8.5MHz... - Page 3 Introduction The VDS4020 is a pair consisting of a Remote Unit and a Local Unit connected via coaxial cable (RG-6/U, 5C-2V or equivalents). The Remote Unit (RU; the “Transmitter"; the Sender) is placed at the IP camera end, and the Local Unit (LU;...
-
Page 4: Limited Warranty
Limited Warranty Genie grants a warranty of this product for 18 months. Please offer the purchase date and the serial number of the Bar-code on the back of the product to your distributor or retailer as a proof for this purpose. During the warranty period, in case of defects in material or workmanship, thedefective unit will be repaired or replaced according to the assessment of Genie. - Page 5 Connection Diagram The following illustration gives an overview of how the Sender and the Viewer connect. Please note that the coax- ial cable should always be connected to the LINK OUT side of the Sender. CHANGE THIS TO WHAT THE PRODUCT IS AND COPY INTO THE MASTER PAGE A...
- Page 6 Installation of Remote and Local Units The VDS4020 units can both be fixed to the wall or the desktop with the supplied mounting brackets. The mounting brackets can be fixed onto the rear, top, or bottom of either unit. Attaching the Mounting Brackets...
- Page 7 Power Supply Adaptor and Appearance With a power capacity of 60 watts, the Power Supply PD4860 provides enough power for the whole VDS4020 system and the camera on the remote side. Besides, it compensates for the power consumption caused by the DC resistance through the coaxial cable dur- ing power transmission.
-
Page 8: Packing Checklist
Remember that the total value of DC resistance is the sum of DC resistance from both the inner and outer conductors. Table 2. General Specifications of the RG-6/U Coax Packing Checklist Carefully unpack the packing box of the VDS4020 and check if the following items are included: • VDS4020-R Sender (Remote Unit) •... - Page 9 GENIE CCTV LTD. CCTV House, City Park, Watchmead, Welwyn Garden City, Hertfordshire, AL7 ILT Tel: +44 (0) 1707 330541 Fax: +44 (0) 1707 330543 www.geniecctv.com Edition. GN-February 2015...
