SpringCard Prox'N'Roll Reference Manual

Rfid scanner
Hide thumbs Also See for Prox'N'Roll:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
P
'N'R
ROX
OLL
Reference manual
Headquarters, Europa
SpringCard
13 voie la Cardon
Parc Gutenberg
91120 Palaiseau
FRANCE
Phone :
+33 (0) 164 53 20 10
Fax :
+33 (0) 164 53 20 18
SPRINGCARD, the SPRINGCARD logo, PRO ACTIVE and the PRO ACTIVE logo are registered trademarks of PRO ACTIVE SAS.
Information in this document is subject to change without notice. Reproduction without written permission of PRO ACTIVE is forbidden.
RFID S
CANNER
Americas
SpringCard
964 Fifth Avenue
Suite 235
San Diego, CA 92101
USA
Phone :
+1 (619) 544 1450
Fax :
+1 (619) 573 6867
All other brand names, product names, or trademarks belong to their respective holders.
PMA8N9P-BC
02/06/2009
www.springcard.com
