- Page 1 BRUsky-S version 1.0 Instruction manual Video indoor station with digital 8.9 cm (3.5“) TFT display for surface-mount, in anodised aluminium IVW2221...
- Page 2 BRUsky version 1.0 Congratulations to your new video indoor station with optional external image buffer! navigation button DOWN loudspeaker menu button digital 8.9 cm navigation button UP (3.5") TFT green ON incoming door call or internal call active voice communication green blinks busy speech and video channel newly stored image...
- Page 3 BRUsky version 1.0 Operation A ring tone signals an incoming call. The green LED is ON. Speaking Shortly press the speech button to accept the call or longer than 1 second to switch on simplex communication during the voice communication. The green LED is ON.
-
Page 4: Setting The Video Image
BRUsky version 1.0 Setting the video image The display The fade-in of the video images is realised immediately after pressing the image button or after receiving a door call. Optional, the speech button can be pressed in order to receive noises in addition to the video image when in stand-by mode (speaking and video off ). - Page 5 BRUsky version 1.0 Your settings in the OSD menu Setting ring tone volume and ring tones The setting of ring tone volume and the selection of the required ring tone is realised quickly and easily in the symbol menu of the display when in stand-by mode (speaking and video off ). 1.
-
Page 6: External Image Buffer
BRUsky version 1.0 External image buffer Setting date and time The setting of date and time for stored images in the external image buffer is realised quickly and easily in the OSD menu of the display when in stand-by mode (speaking and video off ). 1. - Page 7 BRUsky version 1.0 Store images Store images automatically and manually In connection with an external central image buffer FVM1000-0400 up to 64 images can be stored. Store an image automatically Activate the automatic image recording by pressing the menu button longer than 4 seconds.
-
Page 8: Image Buffer
BRUsky version 1.0 Image buffer Call and delete images View stored images If the image buffer indication blinks green, new images were stored at an incoming door call 1. Press the menu button to display the image of the image buffer. 2. -
Page 9: Configurable Functions
BRUsky version 1.0 Configurable functions The following functions can be configured at your video indoor station and for the use of menu further indoor stations. Therefore please contact your qualified electrician. internal call Switching lights, internal call, call diversion and door release automatic can be used only selected alternatively. - Page 10 BRUsky version 1.0 Send control function If control functions (max. 10) are programmed, those can be (de-)activated in the menu control function. The switching modes of the control functions (ON/OFF) are indicated by colored points (red/green). Call diversion (de-)activate control functions in the menu control functions The incoming call is diverted to a second indoor station.
- Page 11 BRUsky version 1.0 Additional functions Video surveillance Shortly press the image button to show the image of the front-door station on the dis- play. By pressing the button again, further cameras can be selected. Error indication If the two LEDs flicker continously and shortly and if there are beep tones when pressing the buttons, there is an error at the device or within the system.
