- Page 1 Solutions for Demanding Applications VarTech Systems Inc. Industrial CRT and Flat Panel Displays VT201CHC VT201CHC-IR 20.1” Honeywell Configured Flat Panel User’s Guide Read these instructions completely before attempting to operate your new Color Display. VT201CHC User Guide 150-060...
-
Page 2: Table Of Contents
Table Of Contents Section Page Section Page Section 1 Section 4 Introduction Touch screen 1.1 VT201CHC Display Family 4.1 Touch Screen Introduction 1.2 Product Safety Precautions Section 5 Section 2 Troubleshooting Tips Display Setup 2.1 Display Features Section 6 2.2 Unpacking The Display Cleaning &... -
Page 3: Introduction
INTRODUCTION INTRODUCTION VT201CHC Display Family The VT201CHC is part of a series of LCD replacement displays for the Honeywell "Z" Style replacement furniture. The VT201CHC display is an upgrade solution for US and UxS based systems. The VT201CHC is compatible with EPDG, EPDG2, and TPDG video. -
Page 4: Product Safety Precautions
The display does not operate normally when the operating instructions are ⇒ followed. The display has been dropped or the enclosure has been damaged. ⇒ The display exhibits a distinct change in performance, indicating a need for ⇒ service. VT201CHC User Guide 150-060... -
Page 5: Display Setup
The VT201CHC comes with a HD15 Input Connector. The VT201CHC also includes an HD15 ⇒ to DB9 Video Adapter Cable. The VT201CHC is supplied with a remote membrane switch assembly that mounts to the front ⇒ of the console bezel for OSD controls. -
Page 6: Unpacking The Display
Note: The displays are factory OSD adjusted for each configuration. However, additional OSD adjustments may be required (See section 3). Signal Connections To avoid irregular operation and /or damage to the display, please insure correct video is being supplied as shown on the following page. VT201CHC User Guide 150-060... - Page 7 HD-15 video connector. Signal Red Video HD15 Connector Female Green Video Blue Video Not Used Not Used Red Video Ground Green Video Ground Blue Video Ground Not Used Ground Ground Not Used Horizontal Sync Vertical Sync Not Used VT201CHC User Guide 150-060...
-
Page 8: Getting Started
Increase Contrast or Increment Selected Parameter Decrease Contrast or Decrement Selected Parameter Increase Backlight Brightness or Increment Selected Parameter Decrease Backlight Brightness or Decrement Selected Parameter For Use With VarTech Console Bezel For Use With Honeywell Console Bezel VT201CHC User Guide 150-060... - Page 9 If its setup has been saved, the user number of the signal is also displayed. (These figures are for guidance only). Brightness and Contrast OSD Agent Description These perform the same functions as the direct brightness and direct Brightness and Contrast contrast button operations listed above. VT201CHC User Guide 150-060...
-
Page 10: Adjustment Procedure
They should be Individual Color adjusted for the desired color balance and to minimize noise on low Adjustments intensity colors and greys. Color tints can be added as required. VT201CHC User Guide 150-060... - Page 11 Please note this function will only be effective if Text Enhance / the signal resolution is close to the resolution of the panel, no harm Normal will be done to the unit by trying the enhanced and normal text options for other input resolutions. VT201CHC User Guide 150-060...
-
Page 12: Touch Screen
TOUCH SCREEN Touch Screen Introduction The VT201CHC-IR is supplied with a new flat IR touch frame which is compatible with the original monitor IR touch frame. Connect the DB9 cable connector of the original IR touch interface cable to the DB9 connector on the new IR touch frame. -
Page 13: Troubleshooting Tips
I/O adapter board. 2. Adjust the OSD control for correct color balance. 1. OSD adjustment is incorrect. Please consult section 3 for OSD Disturbances on Screen screen adjustment procedures. VT201CHC User Guide 150-060... - Page 14 For best results cleaning a monitor with the optional antireflective tempered glass display shield, a solution of denatured alcohol is recommended to thoroughly clean the display. Other Maintenance Qualified service personnel should perform all maintenance, except for the power cord replacement described above. VT201CHC User Guide 150-060...
-
Page 15: Mechanical Drawings
7. Connect the membrane extension cable to the membrane tab that projects through the front console bezel. 8. Mount the VT201CHC display and secure to the side mounting brackets with the provided screws. 9. Connect the membrane extension cable to the display where marked. Connect the video cable and power cord to the display where marked. - Page 17 TOUCH OUTPUT AC INPUT 100-220 VAC FAN TO HAVE 1.5"[38,1] 50/60 Hz CLEAR AIR SPACE 0.75A CLEAN FILTER AS REQUIRED VIDEO VIDEO COMP VIDEO REMOTE DISPLAY CONTROLS...
- Page 18 VarTech Systems...
- Page 19 TOUCH OUTPUT AC INPUT 100-220 VAC FAN TO HAVE 1.5"[38,1] 50/60 Hz CLEAR AIR SPACE 0.75A CLEAN FILTER AS REQUIRED VIDEO VIDEO COMP VIDEO REMOTE DISPLAY CONTROLS...
- Page 20 Normal: 55Watts DPMS: < 3Watts Operating Temperature 0 to 50ºC Storage Temperature -20 to 60ºC Operating Humidity 0 to 95%NC Storage Humidity 0 to 95%NC Operating Altitude Up to 10,000 ft Storage Altitude Up to 40,000 ft VT201CHC User Guide 150-060...
- Page 21 VARTECH SYSTEMS HEADQUARTERS 11529 Sun Belt Ct. Baton Rouge, Louisiana 70809 Toll-Free: 800.223.8050 International Phone: 001.225.298.0300 Fax: 225.297.2440 E-mail: sales@vartechsystems.com www.vartechsystems.com 150-060-001 12.28.04 VT201CHC User Guide 150-060...
