Marinediesel 6,5L V8 Owner's Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Application .............................................................................
Identification ...........................................................................
Break in procedure .....................................................................
Starting procedure .....................................................................
Winter storage..........................................................................
Procedures after winter storage ......................................................
Periodic maintenance .................................................................
Technical maintenance specifications ..............................................
Warranty ................................................................................
Dealer & Service directory ...........................................................
Exhaust manifolds .....................................................................
Supercharger and intercooler system ...............................................
Impeller pump .........................................................................
Raw water and fuel connections ....................................................
Oil filter relocator ......................................................................
2. ENGINE MECHANICAL
Specifications ..........................................................................
Diagnostic ... ...........................................................................
Cylinder block and components .....................................................
Front cover, oilpan and components ................................................
Fuel system components ..............................................................
Serpentine belt system .................................................................
Valve cover replacement ..............................................................
Rocker arm replacement ...............................................................
Valve lifter replacement ..............................................................
Crankshaft Balancer replacement ..... ..............................................
Engine front cover replacement .....................................................
Timing chain replacement ...........................................................
Camshaft replacement ................................................................
Crankshaft rear oil seal replacement ...............................................
Oilfilter adapter replacement ........................................................
Oil pan replacement ..................................................................
Oil pump replacement ................................................................
Fuel injection pump removal ........................................................
Timing chain wear check .............................................................
Engine disassembly and assembly ..................................................
Engine component description .......................................................

TABLE OF CONTENTS

1
2
2
2
3
4
5
5
5
6
6
7
11
11
12
13
18
29
31
33
34
41
45
53
58
61
67
70
74
77
78
81
84
87
90
145

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6,5L V8 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Marinediesel 6,5L V8

  • Page 1: Table Of Contents

    TABLE OF CONTENTS 1. GENERAL INFORMATION Application ………………………………………………………………….. Identification ………………………………………………………………... Break in procedure ...………………………………………………………... Starting procedure …………………………………………………………... Winter storage……………………………………………………………….. Procedures after winter storage ……………………………………………... Periodic maintenance ……………………………………………………….. Technical maintenance specifications ………………………………………. Warranty …………………………………………………………………….. Dealer & Service directory ………………………………………………….. Exhaust manifolds …...……………………………………………………… Supercharger and intercooler system ………………………………………..
  • Page 2 3. DIAGNOSTIC INFORMATION Diagnostic Strategy 4. INSTALLATION Important installation notes ..……………………………………………….. Engine ………………………………………………………………………. Air Intake System …………………………………………………………… Fuel System ..………………………………………………………………... Exhaust System ……………………………………………………………. Cooling System ……………………………………………………………... Electrical System ..…………………………………………………………... Predelivery …………………...……………………………………………... Predelivery inspection checklist …………………………………………….. 5. SERVICE INSTRUCTIONS Service information...

  • Page 3: Application

    APPLICATION In 1998, Marinediesel introduced it’s 6,5L V8 supercharged, intercooled marine engine (see drawing below) for light duty commercial and pleasure craft applications. The base engine is manufactured at the General Engine Products ( a division of AM General) 92,000 square foot production facility, located in Franklin, Ohio. The Optimizer 6500 base engine is Euro III and QS 9000 certified.

  • Page 4: Identification

    IDENTIFICATION The Marinediesel engine has a stainless steel serial number tag located on the rear starboard side of the engine block. This serial number tag will reflect the engines six digit serial number starting with MD-######. Serial Number ###### BREAK IN PROCEDURE All Marinediesel engines have a break-in period during the first 20 hours of operation.

  • Page 5: Winter Storage

    It’s not unusual with smoke from the exhaust system just after start-up but this will stop once the engine reaches operating temperature. Glow system will automatically afterglow. Recommended cruising rpm for all Marinediesel engines is 2700-3200rpm although the maximum rated effect is at a higher rpm. It is necessary to choose a propeller that will allow the engine to reach maximum engine rpm at WOT to not inflict unnecessary load on the engine, which could effect longevity and void warranty.

  • Page 6: Procedures After Winter Storage

    thermostat to open and mix the added antifreeze. Never use more than 50% antifreeze. Turn off the engine and drain the raw-water system. At the same time remove the impeller from the impeller pump. Check all hoses, clamps and fittings for wear and leakage, replace if necessary.

  • Page 7: Periodic Maintenance

    This warranty shall apply only to pleasure craft and light-duty craft applications. This warranty shall become effective upon the date of sale to the first purchaser or user of the Product and receipt by MarineDiesel of a completed Sea Trial Registration Form.

  • Page 8: Dealer & Service Directory

    VIII. Claim shall be made under this warranty by delivering the Product for inspection to a Marinediesel dealer authorized to service the Product. If purchaser cannot deliver Product to such authorized dealer, he may give notice in writing to the Company . We shall then arrange for the inspection and repair, provided such service is covered under this warranty.

  • Page 9: Supercharger And Intercooler System

    Raiser bolts Water passage gasket Supercharger and Intercooler System Air induction on Marinediesel SC-engines includes the following parts: x Air intake duct, intake silencer and air filter assembly x Supercharger assembly x Intake assembly with integrated CuNi intercooler x Crankcase ventilation system...
  • Page 10 Air intake adaptor mounts with 6pcs M8 X 25 hexagon socket head bolts. Clamps CDR valve Bolted bracket...
  • Page 11 Supercharger assembly The supercharger assembly connects to the intake manifold using a gasket and 7 pcs M8 X 25 hexagon socket head bolts, torque to 22 Nm, seal with Loctite 270, picture below. gasket Intake assembly with integrated CuNi intercooler...
  • Page 12 Rubber damper on Intercooler tank The intercooler mounts into the rear section of the intake manifold and is then covered by a bronze lid which incorporated an o-ring for sealing. At the end of the intercooler is the intercooler tank that is covered by a rubber damper to ensure that the intercooler does not get in contact with the casting of the intake manifold.

  • Page 13: Impeller Pump

    Impeller Pump Standard UV1 Commercial (high flow) Raw water and fuel inlet connections Fuel return connection Fuel inlet connection Raw water connection Please see installation section starting page 169 for further information...

  • Page 14: Oil Filter Relocator

    Oil filter relocator The oil filter relocator is ordered as an option when ordering the engine. As it is supplied separately it is essential that the oil lines and oil filter are prefilled with oil before starting the engine. The lines should be connected as shown below. To check the function of the remote filter feel the oil lines when engine is running, if they are warm the oil is circulating as it should, if not, stop the engine and recheck the connections.

  • Page 36: Serpentine Belt System

    Drive Belt Replacement Removal procedure: 1. Install a 3/8 inch drive wrench on the drive belt tensioner arm and rotate the arm counterclockwise. 2. Remove the drive belt from the drive belt tensioner pulley. 3. Slowly release the tension on the drive belt tensioner arm.
  • Page 152 DIAGNOSTIC STRATEGY The diagnosis of faults related to the MarineDiesel engine involves the following steps: 1 Verify that a condition related to a fault exists 2 Select the condition of the fault 3 Select a system or check that relates to the condition...
  • Page 153 NOTE: Items underlined are the most likely cause of the condition. LOW POWER or LOSS OF POWER PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Incorrect fuel quality (heating ƒ Check specific gravity of fuel (Use fuel energy/purity) quality hydrometer); Inspect and clean fuel tank if needed ƒ...
  • Page 154 NOTE: Items underlined are the most likely cause of the condition. HARD TO START PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Incorrect fuel quality (heating ƒ Check specific gravity of fuel (Use fuel energy/purity) quality hydrometer). Inspect and clean fuel tank, if needed. ƒ...
  • Page 155 NOTE: Items underlined are the most likely cause of the condition. WILL NOT START - COLD PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Incorrect fuel quality (heating ƒ Check specific gravity of fuel (Use fuel energy/purity) quality hydrometer). Inspect and clean fuel tank, if needed. ƒ...
  • Page 156 NOTE: Items underlined are the most likely cause of the condition. WILL NOT START – HOT (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Incorrect fuel return from injection pump ƒ Check fuel return line on top of injection pump for restrictions or debris. ƒ...
  • Page 157 NOTE: Items underlined are the most likely cause of the condition. ROUGH/ERRATIC IDLE PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Operation during extreme ambient ƒ Review normal operating procedures. temperatures (hot/cold) ƒ Binding injection pump throttle cable ƒ Check throttle controls. ƒ Incorrect fuel supply to injection pump (air ƒ...
  • Page 158 NOTE: Items underlined are the most likely cause of the condition. ENGINE MISFIRES PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Incorrect low/fast idle speeds ƒ Consult your dealer service manager. ƒ Incorrect injection pump static timing ƒ Consult your dealer service manager. ƒ Incorrect fuel supply to injection pump (air ƒ...
  • Page 159 NOTE: Items underlined are the most likely cause of the condition. POOR ACCELERATION PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Operation while overloaded or at excessive ƒ Insure boat is properly loaded and operated within RPM limits. ƒ Operation during extreme ambient ƒ Review normal operating procedures. temperature (hot/cold) ƒ...
  • Page 160 NOTE: Items underlined are the most likely cause of the condition. EXCESSIVE WHITE SMOKE PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Incorrect fuel quality (heating ƒ Check specific gravity of fuel (fuel quality energy/purity) hydrometer). Inspect and clean fuel tank, if needed. ƒ Operation with long periods of engine ƒ...
  • Page 161 NOTE: Items underlined are the most likely cause of the condition. BLACK SMOKE UNDER LOAD – HOT (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Operation during extreme ambient ƒ Review normal operating procedures. temperature (hot/cold) ƒ Outside air intake or air filter restricted ƒ...
  • Page 162 BLACK SMOKE AT IDLE (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Worn or damaged supercharger ƒ Consult your dealer service manager. ƒ Air leakage or restriction in air inlet duct or ƒ Check air inlet duct bolt and clamp intake manifold tightness; check intake manifold bolt/stud tightness;...
  • Page 163 EXCESSIVE SMOKE DURING ACCELERATION (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Air leakage or restriction in supercharger ƒ Consult your dealer service manager. inlet duct ƒ Worn or damaged supercharger ƒ Consult your dealer service manager. ƒ Air leakage or restriction in air inlet duct or ƒ...
  • Page 164 GRAY SMOKE (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Air leakage or restriction in air inlet duct or ƒ Check air inlet duct bolt and clamp intake manifold tightness; check intake manifold bolt/stud tightness; disassemble and inspect air inlet duct; with air inlet duct removed, check intake manifold runners.
  • Page 165 EXCESSIVE LUBE OIL COMSUMPTION (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Operation during extreme ambient ƒ Review normal operating procedures. temperature (hot/cold) ƒ Faulty CDRV operation ƒ Consult your dealer service manager. ƒ Leaking crankcase ventilation system ƒ Inspect system for oil leakage; repair or (pipes/hoses) replace damaged parts, if needed.
  • Page 166 EXCESSIVE FUEL CONSUMPTION (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Restricted exhaust system ƒ Inspect exhaust sytem for collapsed pipes or muffler ƒ Incorrect injection pump static timing ƒ Consult your dealer service manager. ƒ Incorrect fuel supply to injection pump ƒ Consult your dealer service manager. ƒ...
  • Page 167 FUEL OR LUBE OIL LEAKS (Continued) PROBLEM CORRECTION/FURTHER DIAGNOSIS ƒ Lubrication component package ƒ Inspect sealing surfaces and areas for signs of oil leakage: -Rocker arm covers -Front cover -Oil fill pipe -Oil pump drive/engine speed sensor -Cylinder case passage plugs -Oil filter mounting -Oil cooler pipes/hoses -Oil pan...
