Tesira D 200:4T Quick Start Manual

D series

Advertisement

Quick Links

D SERIES
Rev. 2.0.0
Item no. QSG-DSERIES-TESIRA
High-Power installation platform
Tesira Variants:
D 200:4T/Ta
D 120:4T/Ta
D 80:4T/Ta
Incorporating technologies from
Quick Start Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the D 200:4T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tesira D 200:4T

  • Page 1 D SERIES Rev. 2.0.0 Item no. QSG-DSERIES-TESIRA High-Power installation platform Tesira Variants: D 200:4T/Ta D 120:4T/Ta D 80:4T/Ta Incorporating technologies from Quick Start Guide...
  • Page 2: Important Safety Instructions

    Il n’y a pas des parties serviceable à l’intérieur, tous minors are using the equipment. reparations doit etre faire par personnel qualifié seulment. 22. The US National Differences clause 16.3 requires that network cables must be flame rated VW-1. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 3: Caution

    If the dust fi lters are not clean and the unit voltage, do not connect or disconnect speaker cables when malfunctions, any resulting problems will not be covered by the mains power is on. the warranty. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 4 D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 5 D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 6 本業務用音響機器は、成人・未成人に関わらず未経験者が使用する Français: À prévenir le choc électrique n’enlevez pas les couvercles. Il n’y a 21 . 場合は特に、必ず経験者の監視の元で使用してください。 pas des parties serviceable à l’intérieur, tous reparations doit etre faire par personnel qualifié seulment. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 7 Aucune pièce réparable par l’utilisateur. Confier l’entretien àpersonnel qualifié. メンテナンス 3.4.5 安全で信頼性の高い動作を維持するために、定期的にフロントパネル両側、グ 使用者責任 リル裏のダスト・フィルターを取り外して清掃することで最大限の換気が行え るようにしてください。 接続電源の接地 3.4.1 装置(アンプリファイアー)は必ず接地されたコンセントに接続してください。 ダスト・フィルターのメンテナンスを怠ると安全面でのリスクが生じます。例え ば、内部温度の上昇により埃が発火する可能性があります。また、装置は安定 アンプリファイアーのスピーカー出力の危険性 3.4.2 した前面吸気/背面排気の換気が行えることを前提としているため、故障のリ アンプリファイアーは危険な電圧を出力する能力を持ちます。感電を避けるた スクが生じます。ダスト・フィルターがきれいでない状態に起因する本体の異 め、アンプの稼働中に露出されたスピーカーのワイアリングには触れないでくだ 常が生じても、結果的な問題は保証外となります。 さい。スピーカー・ターミナルに接続する外部配線の設置は必ず有資格者が行 うか、既製品を使用する場合には必ず適切な容量の線を使用してください。 アンプの出力チャンネルは高電圧を生成します。電源がオンの場合は絶対にス ピーカー・ケーブルの抜き差しを行わないでください。 D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 8 22. Aux USA, la clause 16.3 des US National Differences exige une classe d’inflammabilité VW-1 pour les câbles réseau. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 9 électriques. Ce produit utilise des ondes radioélectriques et, s’il n’est pas installé et utilisé conformément à ces instructions d’utilisation, peut causer des interférences avec d’autres appareils, tels que les radiorécepteurs. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 10: Wichtige Sicherheitshinweise

    Il n’y a pas des parties serviceable à l’intérieur, tous reparations doit Minderjährige das Gerät bedienen. etre faire par personnel qualifié seulment. 22. Entsprechend US National Differences Abschnitt 16.3 müssen Netzwerkkabel flammwidrig nach VW-1 sein. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 11 Ein Muster dieses Produkts wurde auf Einhaltung der Grenzwerte der Europäischen Richtlinie für Elektromagnetische Verträglichkeit (EMV) geprüft und entspricht diesen Vorgaben. Dieses Gerät ist geprüft worden und entspricht den Grenzwerten der Federal Communications Commission (FCC) für digitale Geräte der Klasse D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 12: Instrucciones Importantes De Seguridad

    22. La cláusula 16.3 de la US National Differences obliga al uso de couvercles. Il n’y a pas des parties serviceable à l’intérieur, tous cables de red de una categoría mínima de VW-1 reparations doit etre faire par personnel qualifié seulment. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 13 Cualquier avería resultante de una limpieza incorrecta de los altavoz con la unidad encendida filtros no quedará cubierta por la garantía D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 14: Table Of Contents

    3.4.4. Speaker damage 3.4.5. Maintenance 5. Introduction 5.1. Welcome 5.2. D Series: Two versions available 6. Feature summary 6.1. Features Unique to Tesira® DSP and Networking Environment 7. Installation 7.1. Unpacking 7.1.1. Included in the box 7.2. Mounting 7.2.1. Rear Mounting 7.2.2.
  • Page 15 13.2. Network setup 13.3. System setup 13.4. Basic Configuration 14. Faults and warnings 15. Technical Specifications 16. Warranty and support 16.1. General 16.2. Technical assistance and service 16.2.1. International service 16.2.2. Factory service D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 16: Introduction

    This document is for use with D Series Tesira version only, and applies to models in all power levels. Additional documentation on D Series can be found in the full Operation Manual available on www.labgruppen.com.
  • Page 17: Feature Summary

    6.1. Features Unique to Tesira® DSP and Networking Environment • Developed and supported by Biamp Systems • D Series Tesira models fully integrated as high-power output devices • Channel processing control of Mute, Level and Signal Invert • Four input channels via Ethernet-based Audio Video Bridging (AVB) network •...
  • Page 18: Installation

    7.1.1. Included in the box In addition to the D Series device, the shipping carton includes the following items: • D Series Tesira Quick Start Guide (this document) • AC mains lead (power cable) with Neutrik powerCON connector and AC socket plug according to ®...
  • Page 19: Mounting Front Grille

    To clean the foam filter, detach it from the exterior front and gently use a vacuum cleaner or gently shake it. Remount with the opposite procedure. Never operate the amplifier without the dust filter installed. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 20: Cooling And Fan Operation

    For regions with nominal voltage below 140 V, one could consider connecting the amplifier in a three-phase delta or two phase split-phase configuration. NOTE: Following connections applicable only for resulting voltage inside the amplifiers nominal voltage range. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 21: Grounding

    Use correctly-shielded balanced audio input connections to minimize hum and interference. D Series must be grounded (earthed) with the safety ground pin to the mains distribution system. NEVER disconnect the earth (ground) pin on the mains cable (AC power cord). D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 22: Product Overview

    LED will indicate the unit is selected. NOTE: The touch buttons use capacitive touch technology and might be sensitive to large temperature and humidity variations. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 23 Input signal below present Signal above signal threshold or Frame/Amp Signal clip or limit/fault active Signal present threshold fault active Not muted Muted Mute Device not selected Device selected Select D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 24: Rear Panel

    4 Terminal block connector for Logis I/O (4 pins of GPIO and a ground) 5 Analog inputs on Tesira Analog version. The analog inputs are available on terminal block connectors with clearly marked hot (+), cold (-) and ground terminals. The analog inputs can either be used as local inputs to a Tesira AVB system or as analog failover in case the AVB audio network is interrupted.
  • Page 25: Signal Flow And Processing

    System IO is designed and managed, and all signal processing is defined, at the server level. D Series Tesira amplifiers are added as high power outputs to the system with audio transported to them via the AVB network, through analog connection, or both.
  • Page 26: Quick Start Tutorial

    Update D Series amplifier firmware The first time a D Series amplifier is connected to an active Tesira system following a server firmware update, the server will automatically update the firmware of the amplifier when needed.
  • Page 27: Network Setup

    13.2. Network setup Network connections/topology The following diagram shows a typical setup with Tesira software running on a PC. A Tesira server has separate network ports for control and AVB but D Series has these combined into one port. BIAMP SYSTEMS assembled in the USA www.biamp.com...
  • Page 28: System Setup

    The setup guide describes how to get a simple system up and running, connect audio through to the amplifier, and make basic configurations of the amplifier. This guide assumes you have a Tesira Server IO with an analog input card, a D Series amplifier and an AVB switch. To pass audio through the system you will also need a signal source and a speaker.
  • Page 29 2. Enter a system description or leave to default and click OK 3. Click Yes to start system audio 4. Click Start All in the Manage partition audio popup. Click close Your system is now up and running and passing audio. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 30: Basic Configuration

    13. Quick Start Tutorial 13.4. Basic Configuration In the Tesira software, double click the amplifier block. The D Series configuration window opens. Here you can check the amplifier for any potential faults and warnings and monitor signal status. You can also control STANDBY/ ON state and other amplifier channel functions such as mute, level and invert.
  • Page 31: Faults And Warnings

    Power supply detects mains voltage Mains voltage above Check mains distribution/ MAINS > 400 VPK above 400 volt peak. Protective shut Fault 400 volt peak connection down, auto restart attempt D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 32 Very high frequency fault VHF FAULT Amplifier channel protection Check input signal Fault Reduce output power Voltage clip VOLTAGE CLIP Amplifier reached voltage limit Clip to avoid limiting D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 33: Technical Specifications

    0.006 % Dynamic range (20 Hz - 20 kHz, 0 dB) > 108 dB Cross talk (20 Hz - 20 kHz @ 0 dB gain + 4 dBu in) > 85 dB D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 34 Detachable mains cord Neutrik PowerCon rated at 250 V / 32 A Front panel user interface System status indication 3 x 3 colored LED. ALARM, ACTIVITY, STATUS for Tesira ® system status and Device STATUS indication Channel status indication 3 x 3 colored LED per channel. Status indication separated for channel LOAD, AMP, SIGNAL status...
  • Page 35: Warranty And Support

    16.2.1. International service If your Lab.gruppen product requires repair, contact your Lab.gruppen dealer or distributor, visit http://labgruppen.com/support/find_service_centre/ or contact Lab.gruppen by phone or email to obtain details for the nearest authorized service center. D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 36: Factory Service

    3. Mark the Return Authorization number on the outside of the packing. Ship the product prepaid to: Lab.gruppen AB Faktorvägen 1 SE-434 37 Kungsbacka Sweden Phone: +46 300 56 28 00 Fax: +46 300 56 28 99 service@labgruppen.com www.labgruppen.com D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 37 Notes Notes D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 38 Notes Notes D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 39 Notes Notes D SERIES Tesira Quick Start Guide rev 2.0.0...
  • Page 40 Lab.gruppen adopts a policy of continuous improvement and product specification is subject to change. RPM, R.SMPS, PFC, CDM, BEL, UVL, CAFÉ, ESP, ISVPL, Iso-Float, Raised Cosine, MESA EQ, LimiterMax and LoadLibrary are trademarks of Lab.gruppen AB. Tesira is a trademark of Biamp Systems. All other trademarks remain the property of their respective owners.
