Summary of Contents for Buzzaudio DBC-20
- Page 1 DBC-20 Diode Bridge Compressor Users Manual DBC-20 USERS MANUAL VERSION-1, NOVEMBER 2014. CONTENTS COPYRIGHT BUZZ AUDIO LTD 2014. PO BOX 6677, TE ARO. WELLINGTON, 6141 NEW ZEALAND. PH. +64-4-472-3084 www.buzzaudio.com email management@buzzaudio.co.nz...
- Page 2 Welcome… Thank you for choosing the Buzz Audio DBC-20 Diode Bridge Compressor. In this manual you will find important information regarding the use of the DBC and we suggest you do read it before using the unit to become familiar with all the controls and their function.
- Page 3 2] The Mains Input The DBC-20 mains input can be set to run from 110V or 230V. On the rear panel you will find a circular voltage selector switch to set this up. Generally the DBC mains voltage is set for the country to which it has been initially sent, but before powering up the unit, please check the voltage selector.
- Page 4 4] Controls and Indicators The DBC-20 has two channels with identical controls. The DBC utilizes silicon diodes in a transformer coupled balanced arrangement as the gain reduction element and has a unique self-adjusting ratio control. COMPRESSION This control adjusts the amount of signal sent to the side chain circuit and therefore the amount of gain reduction (or compression) applied to the input signal.
- Page 5 POWER ON This switches the mains power to the DBC-20 on and off. An aqua colored led tells you when you have successfully achieved this operation. The DBC bypass relays are engaged for a few seconds at power up to prevent thumps.
- Page 6 6] Service Information We are confident that you will receive many years of trouble free operation from your unit. If however you experience any technical problem with your DBC-20, contact your dealer or Buzz Audio for recommendations on what to do.
- Page 7 Buzz Audio Ltd is not liable for any damage to microphones, amplifiers, consoles, speakers or any other equipment and/or electric shock to humans that is caused by negligence or improper installation and/or use of the DBC-20 Diode Bridge Compressor. • Standard Product Warranty...
- Page 8 ⑧...
