- Page 1 GE Security Installation/Operation Instructions Warranty Information DED2500-E DED2500-M DED2500-EM DED2500-S DED2500-ES www.ifs.com 888-999-9IFS...
- Page 2 DED2500 series Left Side Right Side Network Connection (Electrical) Network Connection (Optical) Network Activity (Optical) Blinks with data transfer OFF: No Link ON: Link Link Network Activity (Electrical) Blinks with data transfer Link Speed (Electrical) OFF: 10 Mbps ON: 100 Mbps Power LED illuminates Power Connector...
- Page 3 DED2500 series DED2500-EM - 10 SERIAL TO ETHERNET MEDIA CONVERTER NO - 9 CONTACT 10 /100 TX COM - 8 CLOSURE NC - 7 2W RS485 (-) - 6 2W RS485 (+) - 5 RS485 OUT (-) - 4 RS485 OUT (+) RS232 OUT - 3 RS485 IN (-) - 2 International RS485 IN (+) RS232 IN...
- Page 4 Initializing the DED2500 Upon power up and network connection into the DED2500, the address factory default is 192.168.1.100. The unit's serial port configuration must be completed prior to physically wiring to the data port. Opening the web browser to the default address, the log on screen will be displayed.
-
Page 6: Fcc Compliance
FCC Compliance This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesirable operation. Changes or modifications not expressly approved by International Fiber Systems, Inc. -
Page 7: Required Tools
Product Disassembly Instructions for WEEE Per European Directive 2002/95/EC Waste Electrical and Electronic Equipment Required Tools: One number 2 Phillips (crosstip) screwdriver. One number 2 flat screwdriver. For the enclosed box version: 1. Locate and remove box cover securement screws. Usually, but not limited to, at least 4 screws.
