  • Page 2 DIGITAL LOUD SPEAKER MANAGEMENT RT-DRIVE DLM-206 PARAMETER CLIP CLIP CLIP OUTPUT CLIP OUTPUT CLIP OUTPUT CLIP OUTPUT CLIP OUTPUT CLIP OUTPUT LEVEL LEVEL LEVEL LEVEL LEVEL LEVEL LIMIT LIMIT LIMIT LIMIT LIMIT LIMIT RT-DRIVE PASS LOAD MUTE MUTE MUTE MUTE...

  • Page 4: Table Of Contents

    INTRODUCTION .......................4 FEATURES .........................4 USEFUL DATE ......................4 CONTROL ELEMENTS ....................5 CONFIGURATION & FUNCTIONS ................7 CONNECTIONS ......................20 REMOTE CONTROL ....................21 BLOCK DIAGRAM ......................24 TECHNICAL SPECIFICATIONS ..................25 TROUBLE SHOOTING ....................26 GUARANTEE ......................27...

  • Page 5: Introduction

    Thank you for purchasing TOPP PRO product, the RT-DRIVE DLM-206. RT-DRIVE DLM-206 is 2 In Digital Signal Processor for speaker management. For the input section, thereare Input Gain, 8 bands Parametric Equalizer (PEQ)and delay functions for the stereo input signal processing. In the 6 / 4 output channels section, there are equipped with Input selection, 5-band Parametric Equalizer, Crossover, Delay, Gain, Limiter, and Mute.In order to make the users understand the ways of operation conveniently, it uses the LEDs...

  • Page 6: Control Elements

    7. PASS / EXIT The button ''PASS'' is used to bypass the DSP PEQ, HP / LP, and Volume functions, also send the input signal to the RT-DRIVE DLM-206 outputs directly. The button ''EXIT'' is used to return to previous operation.
  • Page 7 TIDE TIDE TIDE FUSE: 90-120V T500mAL 210-264V T315mAL Apparaten skall anslutas till A102 jordat uttag nar den ansluts till ett natverk DIGITAL IN RS485 OUT RS485 IN INPUT B INPUT A RT-DRIVE DLM-206 DIGITAL LOUDSPEAKER MANAGEMENT SIGNAL AUDIO MIXER POWER...

  • Page 8: Configuration & Functions

    & Functions GETTING STARTED The powerful versatile signal processor RT-DRIVE DLM-206 is mainly designed for use with audio systems. Its routing configurations of the input and output can be only set by recalling one of the PRESETS included in the internal memory. So the user must be very clear about the main function of theunit in...
  • Page 9 A / D converters cause a typical particularly distinct noise (high level square wave). Proceed as follows: Keep the RT-DRIVE DLM-206 outputs in MUTE status (LEDs light on). Feed a signal in on the...
  • Page 10 onfiguration & Functions Disable the MUTE function on the outputs you intend using and listen the sound, carry out instrum- ental checks (if you have the necessary equipment) and any corrections required. Then, if necessary, adjust the values of the following functions: Output EQ Output equalizers Output Limiter...
  • Page 11 onfiguration & Functions L o a d P r e s e t U 6 3 D e f a u l t * * * A 1 3 5 B 2 4 6 U 6 3 e f a u l t * * * 2) Store &...
  • Page 12 A / D converter due to an excessively high input signal causes a typical particularly distinct noise. To achieve a good signal / noise ratio, i.e. an up-front distortion free signal, feed a signal in on the RT-DRIVE DLM-206 's input and watch the INPUT LEVEL A-B LED meter.
  • Page 13 onfiguration & Functions Each equalizer has 5 pages (one for each filter), showing the name of the input it affects & the number of the filter.The following editable parameters are available for each filter: (A) Type of filter Peaking Low Shelving High Shelving Allows to choose among Peaking, Low or High Shelving with a slope of 6 or 12 dB per octave.
  • Page 14 onfiguration & Functions 3) Input Delay Press key and PREV & NEXT keys to adjust the delay lines of Input A, Input B. Input delay ranges from 0 to 1364mS with 0.021 step. I N A D e l a y 0 0 0 0 .
  • Page 15 onfiguration & Functions P e a k 1 k 0 0 2 . 0 0 - 0 0 . 5 Example: Output 1 - Filter 1 Since technical specifications and editing fields of the Output EQ are identical to those of the Input EQ please refer to INPUT Eq...
  • Page 16 onfiguration & Functions The values can be set in the following ranges: OUTPUT DELAY OUTPUT DELAY OUTPUT DELAY Loudspeaker Delayed Virtual Delayed Virtual OP1 DELAY= OUTPUT 1 Components Alignment #1 Alignment #2 HIGH 18ms(6 5m) 14ms(5m) OUTPUT 3 OP3 DELAY= 5) Output Gain Output level control.
  • Page 17 onfiguration & Functions UTIL menu This menu comprises a series of submenus that allow to set a series of system options and access certain utilities, such as the control of protection against accidental or unauth- orized changes: Units Delay Units Misc.
  • Page 18 POWER ENTER (B) Wake Up Allows to choose the mode in which MUTE functions are restored when the RT-DRIVE DLM-206 switched on. The options include: Normal Mute when switched on, the system restores the last when switched on, the system automatically...
  • Page 19 onfiguration & Functions (C) Input Select Used to choose inputs. The options include: Auto Inputs Digital Inputs Analog Inputs I n p u t S e l e c t I n p u t S e l e c t I n p u t S e l e c t i g i t a l...
  • Page 20 onfiguration & Functions Note: Confirmation is only accepted if the cursor is positioned on one of the passwords four characters. This allows to avoid accidental enabling, without having seen the password. Protection is enabled protection and the system takes up default status.How to disable the If the protection is enabled, when the system is in default status (i.e.

  • Page 21: Connections

    CONNECTIONS The adapter that meets all the international safety regulations is supplied with your RT-DRIVE DLM-206 Before power on the RT-DRIVE DLM-206 , please make sure all connections have been made correctly and the volume controls of the amplifier or mixer are turned down completely.

  • Page 22: Remote Control

    REMOTE CONTROL Communications: PC & one or more connection RT-DRIVE DLM-206 to / from USB Port to / from USB RT-DRIVE DLM-206 Serial Port PUSH PUSH OUTPUTS AC INPUT PUSH PUSH PUSH 90-264V 50/60Hz Rated Power SERIAL PORT Consumption 10W...
  • Page 23 FUSE: 90-120V T500mAL TIDE TIDE TIDE 210-264V T315mAL Apparaten skall anslutas till A102 jordat uttag nar den ansluts till ett natverk DIGITAL IN RS485 OUT RS485 IN INPUT B INPUT A RT-DRIVE DLM-206 DIGITAL LOUDSPEAKER MANAGEMENT SIGNAL AUDIO MIXER POWER...
  • Page 24 TIDE TIDE TIDE FUSE: 90-120V T500mAL 210-264V T315mAL Apparaten skall anslutas till A102 jordat uttag nar den ansluts till ett natverk DIGITAL IN RS485 OUT RS485 IN INPUT B INPUT A RT-DRIVE DLM-206 DIGITAL LOUDSPEAKER MANAGEMENT AUDIO MIXER SIGNAL POWER...

  • Page 25: Block Diagram

    BLOCK DIAGRAM...

  • Page 26: Technical Specifications

    7 8 LED for Input and Output Level Display 9 buttons for different DSP functions selection Control 4/6 buttons for Outputs channels Muting Power Supply AC90-264V, 50/60Hz Dimension (W D H) 483 210 40 mm (19" 8.3" 1.6") Weight RT-DRIVE DLM-206: 2.5 Kg (5.51 lb)

  • Page 27: Trouble Shooting

    TROUBLE SHOOTING Symptom Likely Cause What to do Speaker not connected to Verify that speaker is connected and that the circuit is on active AC power No sound Power not switched on Switch on power and verify that power Led is on No sound, speaker is Speaker power cable is faulty *Re-seat the power cable at both ends;...
