SPECIFICATION
Input Port
1xHDMI(Female connector)
Output Port
8xHDMI(Female connector)
Bandwidth
10.2Gbps
Output Resolution
480i~1080P@50/60,1080P@24/50/60,
VGA~UXGA
Operating Temperature
-15℃~55℃/5°F~131°F
Deep Color
36bit
Chassis
Metal
Dimension
276mm(L)x156mm(W)x25mm(H)
Weight
1020g
Power Supply
DC 5V
SAFETY PRECAUTIONS
Please read the following safety precautions carefully before you unpack
and install this equipment.
1.Do not expose the unit to rain, moisture or any other dripping liquids. And
keep it away from any wet locations such as fishing tanks, vases.
2.Do not install the unit close to fire or any other heat sources.
3.Keep the unit in dry and ventilated area. Do not install in bookcase,
cabinet or any other confined space.
4.Stop using the unit during thundering or lightening storms.
5.Avoid the power cable to be stepped on or pinched. Position the unit
carefully to avoid damage or accident.
6.Clean the unit only with dry cloth.
7.Only use accessories specified by the manufacturer.
8.Unplug the equipment when unused for a long period of time.
9.Do not try to open any non-serviceable parts. Contact your authorized
servicing center and personnel.
Keep Away
Keep Dry
from Heat
1x8 HDMI Splitter
Danger Electric
Shock Risk
Full 3D Pass-through
SP18NN00N
User Manual
Advertisement
Summary of Contents for HDMI SP18NN00N
- Page 1 DC 5V carefully to avoid damage or accident. 6.Clean the unit only with dry cloth. 1x8 HDMI Splitter 7.Only use accessories specified by the manufacturer. 8.Unplug the equipment when unused for a long period of time. 9.Do not try to open any non-serviceable parts. Contact your authorized servicing center and personnel.
-
Page 2: Panel Description
INTRODUCTION PANEL DESCRIPTION INSTALLATION This 1 x 8 HDMI splitter is one of our latest versions that allow one HDMI Front Panel •Connect HDMI input port to the signal source equipment such as source to be connected to eight HDMI displays simultaneously. You can enjoy DVD player.
