  • Page 1 WINYCAM Vehicle Drive Recorder X200FHD Uesr Manual www.winycam-eng.com...
  • Page 2: Table Of Contents

    3-4. How to record 3-22. REC Time 3-5. LED Operation 3-23. Specification 3-6. Voice Guide 4. FAQ 3-7. LCD Configuration Warranty 3-8. PC Original Viewer Program Installation 3-9. PC Original Viewer - Screen Configuration 3-10. PC Original Viewer - Viewer Configuration WINYCAM X200FHD...
  • Page 3: Safety Precautions

    60℃ may cause malfunction or breakdown. (This caution shock or fire.) should be applied when product is unused.) Do not touch the LCD excessive force as it may cause Caution on Operation and Storage malfunction. Do not use the product in places in high temperature/humidity. WINYCAM X200FHD...
  • Page 4 LED is turned off, the last recording file may not be saved, so please be careful. When turn off the power of the body and remove the SD card before LED is turned off, the last recording file may not be saved, so please be careful. WINYCAM X200FHD...
  • Page 5: Before Use

    All rights vested in the design and software of X200FHD are the property of Winy Technology Co., Ltd. and protected by the Copyright Law. WINYCAM X200FHD...
  • Page 6: Product Feature

    Security LED light are mounted on front body (LED Lighting connecting to a PC. function On/Off can be set in PC viewer / LCD menu) Each capacity of a normal / event/ motion folder can be set in PC Viewer. WINYCAM X200FHD...
  • Page 7: Standard Package

    The video cable can be purchased separately and used after verifying the PLUG Pin specification of Navigation AV IN. Video input type is different and check the user manual of Micro SD Card Rear Camera Rear Camera monitor. Video Cable WINYCAM X200FHD...
  • Page 8: Product Parts

    2-3. Product Parts 사 DC Jack Rear Camera 용 Connection 하 - 기 Connection Card Slot Reset Front Camera Security LED Power Button REC Button by manual Power LED Microphone REC LED WINYCAM X200FHD...
  • Page 9: How To Use

    4. Connect packaged cigar lighter to a 5. Adjust the angle of body and fix it. 6. Arrange a power cable. cigar socket. (Adjust the angle of camera so that the horizon can be shown above the true center of screen.) WINYCAM X200FHD...
  • Page 10: Rear Camera Installation

    If you embed cable to car wall, please rear camera and a TV-Out jack on front Please check the recorded image that is check cable connection. Also after stored in SD card if X200FHD can record camera embedded double-check if X200FHD properly. can record properly. WINYCAM X200FHD...
  • Page 11: Gps/Tv-Out Cable Installation

    The receiving signal may become poor depending restricted, and/or extra service charge may be incurred. on the climate, satellite status and geography in the neighborhood. The receiving signal may become poor if the windshield is heavy sun-coated or fixed with metallic materials. WINYCAM X200FHD...
  • Page 12: How To Record

    (Driving / Parking). ※ After changed to Parking mode, LCD will be on for 30sec nevertheless you set screen saving time as 30se/60sec/always. ※ When turned to “Parking Mode” G-sensor sensitivity will be more sensitive than driving mode. WINYCAM X200FHD...
  • Page 13: Led Operation

    Red flashing interval at 0.5 sec Red flashing interval at 0.5 sec (Including other error) ※ GPS Icon : when GPS dose not connect, Icon color turn to gray color. And when GPS signal receive properly, Icon color turn to white color. WINYCAM X200FHD...
  • Page 14: Voice Guide

    “ The Recording will end. ” Alarm tone in a Rear Camera disconnect “ Ding-Dong, Ding-Dong ” (the error for 2CH REC) ※ Only when event REC mode is set in the configuration, the voice guiding "event recording will start" will announce WINYCAM X200FHD...
  • Page 15: Lcd Configuration

    Normally off after 30sec / on 60sec System Set TV-OUT Set TV our format (NTSC/PAL) Touch Calibration Calibrate Touch Screen Speaker Volume Set Speaker Volume Factory Init Initialize Configuration Camera Set Camera Set Adjust Brightness, Contrast, Chroma on Camera WINYCAM X200FHD...
  • Page 16: Pc Original Viewer Program Installation

    An executable file is in the SD card as below figure. If you run “setup.exe”, Winy BB Viewer will be installed. And then, installation will be continued according to the installation sequence of setup dialog box.     WINYCAM X200FHD...
  • Page 17 NEXT 사 용 하 기 ※ Installation may tale long depend on PC Usage environment. Installing Please click “Cancel” if you   need to stop installation. WINYCAM X200FHD...
  • Page 18 Select file location and click “Next” NEXT 사 용 하 기 Complete installation ※ If viewer program is lost accidentally, please visit our website winycam-eng and download to the SD card       WINYCAM X200FHD...
  • Page 19: Pc Original Viewer - Screen Configuration

    3-9. PC Original Viewer - Screen Configuration 2 3 4 5 6 사 용 하 기 13 14 15 16 19 20 WINYCAM X200FHD...
  • Page 20 Total File Time/Playback Time Playback File Location Brightness/Contrast/Chroma REC file list / Map Display GPS signal condition Playback Video Image Driving speed Playback Control Latitude/Longitude Full Screen G-sensor information Flip Horizontal Split image Flip Vertical File Skip Back WINYCAM X200FHD...
  • Page 21: Pc Original Viewer - Viewer Configuration

    3-10. PC Original Viewer – Viewer Configuration 사 용 하 기 WINYCAM X200FHD...
  • Page 22 App Always Top Select App is always the top of another window. Video Reverse Video can reverse from side to side and up and down Product Model Select the model. Video adjustment Control playback speed Volume Control recording volume level WINYCAM X200FHD...
  • Page 23: Pc Original Viewer - Configuration

    3-11. PC Original Viewer – Configuration 1 사 용 하 기 WINYCAM X200FHD...
  • Page 24 Video Out Format Select TV-Out format OSD Setting Select OSD out on LCD Front LED Setting Select front security LED function Breaking Voltage Select a breaking voltage for a constant power discharge protection function REC Channel Select a recording channel WINYCAM X200FHD...
  • Page 25 3-11. PC Original Viewer – Configuration 2 사 용 하 기 WINYCAM X200FHD...
  • Page 26 SD Card Folder 하 Select the capacity of each recording mode in SD card Capacity Adjustment 기 Standard time Auto-apply an actual location when using GPS Summer Time Select apply a summer time Time Setting Apply set time to X200FHD WINYCAM X200FHD...
  • Page 27: Configuration Default Setting

    Standard Time Seoul, Korea Voice Guide Volume Level Summer Time REC Volume Level Auto Time Setting Parking Mode Change 30 sec LCD Screen saver Setting NTSC Video Out Format OSD Setting Front LED Setting Breaking Voltage 11.8(23.7)V REC Channel WINYCAM X200FHD...
  • Page 28: Playback (Black Box)

    Window REC video playback window 하 기 LIVE Button Back to list Front /Rear Button Toggle front/Rear video diplay Former file Button Playback Former file Playback Button Playback REC file Next file Button Playback Next file Back Button Back to list tab WINYCAM X200FHD...
  • Page 29: Playback (Standard Video Player)

    Normal : Constant record Event Note : Shock sensor record Motion : Motion sensor record (Parking mode) GPS Information is displayed in the original viewer. You can check only front REC when playing by standard video player. WINYCAM X200FHD...
  • Page 30: Playback (Pc Original Viewer)

    P : Parking REC file list 하 Click icon for the original viewer 기 4. Find a REC file location Click “FILE LOCATION” in original viewer on upper right. Choose file location, video file list will be shown WINYCAM X200FHD...
  • Page 31: Playback (Tv/Car Navigation)

    Please check the TV/Car navigation supplier for an external monitor cable. Mode change method is different for each modes, please refer user manual of TV/Car navigation. If remove or insert TV Out cable during recording, recording will end and start reboot. WINYCAM X200FHD...
  • Page 32: To Save Video File On Your Pc

    2. Go to the folder where recorded video files are stored. 3. Create the new folder in same location. 사 용 4. Drag the particular file to the new file to copy. (If you drag a folder, the whole folder will be copied.) 하 기 WINYCAM X200FHD...
  • Page 33: To Separate Recorded Video Files

    3-18. To separate recorded video files 1. Press “Front & Rear Extract” button on the original PC viewer program. 2. Select a video file to separate and click “OK” button. 3. Stored separated file in “C:\Program Files\BlackBoxViewer\BlackBoxViewer\Video” 사 용 하 기 WINYCAM X200FHD...
  • Page 34: Firmware Upgrade

    5) Insert the SD card to X200FHD. After power ON then firmware will be updated automatically. 6) During firmware updating, a voice guide will be announced and updating massage will be displayed ion LCD. 7) When the firmware update is completed, X200FHD will be initialized and a voice guide will be announced WINYCAM X200FHD...
  • Page 35: Touch Calibration

    RESET : Go back to a test calibration it will be initialized and loading screen will be shown. Keep pressing screen. Note CANCEL : uncompleted a calibration and REC button, a calibration button can be skipped. turn to Normal REC mode. WINYCAM X200FHD...
  • Page 36: Sd Card Format & Set Breaking Voltage

    If you format as NTFS or another format, Micro SD card will not be recognized and product can not work correctly. We recommend allocated value 64KB when you format a Micro SD Card. 2) Format on X200FHD Format a Micro SD Card on a device. (Menu > Others > SD Card Format) WINYCAM X200FHD...
  • Page 37: Rec Time

    By mode : Total record files are stored by your setting rate on “SD card Folder Capacity Adjustment” When memory is full on a particular recording mode, the oldest file will be automatically deleted on Note particular recording mode. Stored file may also be deleted. WINYCAM X200FHD...
  • Page 38: Specification

    2CH : Front 25FPS /Rear 15FPS Temperature 1CH : Super High / High / Normal Operating (bitrate 12/10/8Mbps – FHD Standard) Image Quality -20℃ ~ +60℃ 2CH: Super High / High / Normal Temperature (bitrate 6/5/4Mbps – HD Standard) WINYCAM X200FHD...
  • Page 39: Faq

    3. If the constant power protect function is set ‘OFF’, monitoring during parking will be performed only for a certain period of time. If the vehicle battery voltage is lowered for self-protection, power to the device may be disconnected even in the Parking Mode disabling the recording. WINYCAM X200FHD...
  • Page 40: Warranty

    3) If failures caused by natural disasters (fire, lightning, flood damage, etc. 4) Failures caused by the malfunction of power in use and connected equipment. Please keep this “Warrantee” because we will not be able to re-issue this warrantee note. WINYCAM X200FHD...
