Matrix 2 is an Android mini PC powered by the latest eight computing cores processor(AllWinner A80
octa-core processor). With Matrix 2 connected to your TV, you can play Android games, exploring
internet, watch youtube, Netflix and many other movies. Matrix 2 supports up to 4K ultra HD movies
playing. Kodi(XBMC)/OpenElec can also be installed to Matrix 2, so you can enjoy the great features of
Kodi(XBMC) as home media center. Browse
Specifications
System-on-a-Chip (SoC)
CPU
GPU
RAM
USB Ports
Audio & Video
Storage
Network
Video Format
Audio Format
Operating System
Power Input
Dimension
What's in the box
1x Matrix 2
1x Power Adapter
1x Remote Control
1x User Guide
Quick Start Guide
www.tbsdtv.com
Allwinner A80
Octa-core big.LITTLE Cortex-A15/7
64-core PowerVR G6230
2GB DDR3
1x USB 3.0
2x USB 2.0
CVBS port
HDMI port
Optical (S/PDIF)
8GB eMMC
1x micro SD card slot
10/100/1000 wired Ethernet
WIFI IEEE 802.11a/b/g/n dual-band
Bluetooth 4.0
Decoder: mkv, wmv, mpg, mpeg, dat, avi, mov, iso, mp4, rm
Encoder: H.265 HEVC MP@L5.0 up to 4Kx2K@30fps
MP1, MP2, MP3, WMA, WAV, OGG, OGA, APE, FLAC, AAC, M4A, 3GPP
Android 4.4
DC 5V, 3A
Product: 4*4*1 Inch
Model No. TBS2980
for more information.
Quick Start Guide For Matrix 2 ARM mini PC – V1.0
www.tbsdtv.com
1 / 3
Advertisement
Table of Contents
Summary of Contents for TBS technologies Matrix 2 TBS2980
- Page 1 Quick Start Guide Model No. TBS2980 Matrix 2 is an Android mini PC powered by the latest eight computing cores processor(AllWinner A80 octa-core processor). With Matrix 2 connected to your TV, you can play Android games, exploring internet, watch youtube, Netflix and many other movies. Matrix 2 supports up to 4K ultra HD movies playing.
- Page 2 Interface overview 1. IR sensor: for receiving signal from remote control. Remote control should aim at IR sensor to send control signal. 2. LAN: for wired network connection. 3. HDMI: HDMI output for Video and Audio. 4. S/PDIF: Digital audio output. 5.
- Page 3 Set up Network: 1) For wired connection, click “settings”—“Ethernet”, you can select “DHCP mode” to get IP address automatically or set up IP address manually. 2) For wireless connection, click “settings”—“Wifi”, select your wireless network and connect. * visit www.tbsdtv.com for more information about other supported operating systems. Remote control guide Button Function...
