Thank you for choosing 2KW air parking heater.
This instruction book describes the structures, working
principles, installation and operation of the air-heating parking
Heater. For correct use of the heater, please read this instruction
book carefully before installation and use. The instruction book
shall be saved in a convenient place for later reference.
Attention:
● This instruction book is subject to revision without notice,
but the instruction book is in conformity to the purchased
product.
● Our effort is to explain all questions the users may have
through this instruction book. If you have any doubts or find
anything incorrect in this instruction book, please contact
our company directly.
● At first unpacking, please check the heater and its
accessories against the packing list. Please contact the dealer
immediately if any problem is found.
● If any trouble arises during application, please contact the
Department of Marketing of our company or other customer
service stations authorized by this company. We shall do our
best to provide service to you.
Preface
1
Advertisement
Table of Contents
Related Manuals for Belief FJH-2
Summary of Contents for Belief FJH-2
- Page 1 Preface Thank you for choosing 2KW air parking heater. This instruction book describes the structures, working principles, installation and operation of the air-heating parking heater. For correct use of the heater, please read this instruction book carefully before installation and use. The instruction book shall be saved in a convenient place for later reference.
- Page 2 CONTENTS 1 Introduction „„„„„„„„„„„„„„„„„„3 2 Main Technical Specifications „„„„„„„„„„„3 3 Structures and Working Principles „„„„„„„„„4 4 Installation „„„„„„„„„„„„„„„„„„9 5 Methods of Operation „„„„„„„„„„„„„„20 6 Treatment of Usual Troubles „„„„„„„„„„„28 7 Precautions „„„„„„„„„„„„„„„„„„29 Note： Comply with the operational manual for installation and use to ensure that the heaters can work for a long time.
- Page 3 1 Introduction The main equipment of Model FJH-2/ □ parking heater (hereinafter referred to as the heater) is a small fuel furnace controlled by a single-chip micro- processor. Its furnace body (the heat exchanger) is located in the hood-shape case, which serves as independent air passage.
- Page 4 3 Structures and Working Principles The structures of the main heater are shown in Fig. 2 3.1 Heater Fig.3 is the diagram for structure of the heater. Heat exchanger 1 is the combustion furnace body, made of die-casting aluminum, with radiating fins around and at the rear end.
- Page 5 3.2 Hood-Shape Case Fig. 4 1-Junction box cover 2-Top hood-shape cover 3-Hot air outlet; 4-Bottom hood-shape cover 5-Air inlet of heater 6-Air inlet/exhaust hood The structure of the hood-shape case is shown in Fig. 4. It consists of the top cover 2 (The junction box cover 1 can be fixed on its window), bottom cover 4, air inlet hood 6, air inlet of heater 5 and hot air outlet 3.
- Page 6 3.3.2 Locking Due to Troubles When the heater can not be ignited normally, or can not sustain normal combustion after ignition, or broken circuit or short-circuit occurs to the glow plug, fan motor, fuel pump, or various sensors and components, or in case of overheating of heat exchanger, five times of termination of combustion, twice of unsuccessful ignition or abnormal power voltage, the heater will turn off and enter into locked status for protection.
- Page 7 the heat exchanger. If the temperature here becomes higher than 182℃, the fuel pump circuit will be cut off by the controller and supply of fuel is stopped and then the heater is turned off for purpose of overheating protection. Fig.
- Page 8 voltage is lower than the specified lower limit for 18 seconds continuously or higher than the specified higher limit for 5 seconds continuously, trouble display will occur to the heater and the heater will be turned off automatically with trouble display. 3.7 Fuel Supply The fuel for the heater can be from the fuel tank or from another independent fuel tank.
- Page 9 4 Installation Only special-purpose parts can be used for installation of the heater. Fig. 7 is the diagram for installation. The positions and ways of fixing of various parts may vary from one automobile model to another, but the general principles must be followed in conformity with the requirements of this chapter.
- Page 10 Fig. 8 A-Inlet of heating air B-Outlet of heated air C-Inlet of combustion air D- Fuel inlet E-Exhaust outlet F- Non-interference area G-Information label H-Installation surface I-Gasket Please make sure that there is not any foreign matter in the gap between the bottom surface of the main heater and the installation surface of the vehicle (Fig.
- Page 11 Attention: For re-installation of the heater ,a new gasket must be used to replace the old one. 4.2.5Direction for installation of the heater is shown in Fig. 11. Attention must be paid to that the inclination angle shall not exceed the limit, or normal operation will be affected.
- Page 12 exhaust from the engine can be sucked in. 4.3.6 For heater working in internal circulation, measures shall be taken to avoid re-entering of the supplied hot air into the air inlet port (as shown in Fig. 12). If no air inlet pipe is attached in this a) Correct b) Wrong...
- Page 13 Fuel pipe surface Fig.14 1.Fuel tank 2.Fuel extractor 3.Fuel pipe connector 4.Filter 5.Fuel pipe 6.Fuel pump 7.Damper 4.4.1 The fuel pump shall be fixed in automobile with a fuel pump clamp with protective rubber cover. The outlet of the fuel pump shall tilt upwards. The tilt angle can be selected from the range of 15°...
- Page 14 1-Fuel pump 2-Max.fuel level 3-Min.fuel level 4-Fuel inlet level ①Allowable installation angle ②Optimum installation angle Fig.15 4.4.4 Installation of Fuel Filter A fuel filter shall be installed before the fuel inlet port. Please make sure that the fuel flow is correctly followed. Its position shall be in conformity with Fig.
- Page 15 connections between fuel pipe and fuel pump, fuel pipe and heater, fuel pipe and sucking pipe of fuel tank and fuel pipe and reducing T. The fuel pipe shall ties with fuel pipe clamps. Bubbles shall be eliminated from the connecting places (Fig.
- Page 16 shall connect the fuel pump of the heater via oil pipe fitting and fuel pipe. The angle for installation must in conformity with Fig. 19, or normal work of the heater will be affected. After installation, the vehicle engine shall be started and then turned off after one minute’s work to eliminate air trapped in the fuel sucking pipe.
- Page 18 4.5.5 Straighten the fuel pump leads (two 0.6mm black wires) with their protective pipes, which is made a coil inside the combustion supporting air inlet port, and put them through the opening on the wall of the air inlet pipe. Insert the terminals at the end of the wires with pressed springs into the socket of the fuel pump connector and therefore connect to the fuel pump.
- Page 19 used. The air inlet pipe is a corrugated pipe made of a aluminum pipe that it’s surface is covered by plastic and paper；The exhaust pipe is corrugated stainless steel pipe. Please identify them and do not make mistake at installation. To connect them with the heater, please use the supplied clamps to fix them tightly on the combustion supporting air inlet and exhaust pipe vent respectively.
- Page 20 installation, make sure to install it in far distance from plastic parts or other objects with poor thermal resistance of the vehicle body. The exhaust pipe shall be properly fixed. The exhaust vent shall be downwards, perpendicular to road surface with an angle of 90° ± 10° . To ensure such an angle, the fixing clamp for the exhaust pipe shall be within 150mm from the pipe end.
- Page 21 button,mode incating light turns red,the heater will convert to the constant temperature mode. 5.2.3 The user can install a ventilation switch oneself ,if you want the heater work for air circulation only under normal temperature without any heating, you can close the ventilation switch. The wind capacity can be continuously regulated with the control knob.
- Page 22 At this time,press the manual button,heater will work and the indication light of manual button will be lights up.The default heating time is 45 minutes of starting by manual button. 5.3.2.2 The indication light of manual button lights up when the heater is in the heating status.At this time press the manual button or the heating 45 minutes is finished,the heater will stop heating and the indication light of manual button will be went out.
- Page 23 screen .Press any key,the screen will be lighted up (key lock symbol will be displayed). 5.3.5.2 The autocode function of remote controller and wireless remote control receiver 5.3.5.2.1 Press the encoding button of the wireless remote control receiver, the indication light will turn red and the remote controller will enter into the encoding state.
- Page 24 and heating symbol will be went out.The heating process will be stop after the end of heating symbol occurs and the buzzer rings two times. 5.3.5.4.2 In the heating end of unlocking status,press stop key,the remote controller will return to the standby and locking status immediately. 5.3.5.4.3 In the heating end of locking status, the remote controller will return to the standby and locking status after 60 seconds.
- Page 25 If not,you have to input the right password after voice“Please input the password and press #”.You will hear“Password is wrong,please input again”if wrong password used.Your phone will be hung up automatically after second wrong password. In the heating mode you can hear voice prompt:“The heater is heating”,xx minutes have been heated”,“XX minutes have been left”, “Press 0 to stop heating”,“Press 8 for language change”.
- Page 26 setting up successfully you will hear “Language changed successfully” in language which has been converted. 5.4.7 SMS Control Method （Use phone number 139333444411 as an example） 5.4.7.1 SMS Binding. One GSM controller can be binded with only 2 cellphones, send message to GSM controller：*2530666**13933344411# You will receive the message from controller: “13933344411 is “Command...
- Page 27 Binding cellphone send message to GSM controller: *0215*30# or *2530666*0215*30# Non-binding cellphone send message controller: *2530666*0215*30# 5.6.7.4.2 System default heating time are 45 minutes. Eg:Heat 45 minutes in 2 hours and 15 minutes later: Binding cellphone send message to GSM controller：*0215# or *2530666*0215# Non-binding cellphone send message to GSM controller ：...
- Page 28 Non-binding cellphone send message to GSM controller ： *2530666*01# 5.4.7.5.3 GSM controller reply SMS. GSM will reply the SMS “The heater has started, estimated heating time are xx minutes”.If the heater has been heating you will receive SMS “The heater is heating now, xx minutes have been heated, xx minut es are left”.
- Page 29 6.2 Circuit troubles may be caused by different reasons, such as corrosion of connectors, poor contact of connectors, wrong connection of wires, corrosion of wires or fuse, corrosion of battery poles, etc. Users need to check and prevent such troubles and offer good maintenance. 6.3 The reasons for the troubles to the heater can be indicated by the green LED on the control switch (see Section 3.3.3 for details).
- Page 30 combustion noise or fuel smell is sensed, the heater must be turned off. Please take out the fuse, making the heater unable to operate. The heater can only be put into use after it is tested by qualified professionals. 7.3 Before each heating season, check shall be performed by qualified professionals for maintenance works, details as follows: (a)Check air inlet and air outlet to find any pollution or foreign matters.
- Page 31 transport and storage of the heater to avoid any damage to its electronic elements and components. 7.12 Only authorized customer service stations are allowed to provide repair and installation for the heater. It is prohibited to make repair by yourself or use non-manufacturer’s parts or components so as to avoid danger.
