Golden Blount TEXAS SIZZLER “JR” Owner's Manual

Infra-red gas grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

TEXAS SIZZLER "JR"
FOR YOUR
SAFETY
If you smell gas:
1. Shut off gas to the
appliance.
2. Extinguish any open
flame.
3. Open lid.
4. If odor continues,
immediately call
your gas supplier
or your fire
department.
INFRA-RED GAS GRILL
OWNER'S MANUAL
FOR OUTDOOR USE ONLY
CONTENTS:
▪ Location Requirements . . . . . . . . . . . 1
▪ Assembly . . . . . . . . . . . . . . . . . . . . . . 1
▪ Gas Connection . . . . . . . . . . . . . . . . . 3
▪ Operation . . . . . . . . . . . . . . . . . . . . . . 4
▪ Maintenance and Cleaning . . . . . . . . 6
▪ Replacement Parts. . . . . . . . . . . . . . . 7
▪ Troubleshooting . . . . . . . . . . . . . . . . . 7
▪ Warranty . . . . . . . . . . . . . . . . . . . . . . . 8
Golden Blount Inc.
4301 Westgrove Dr., Addison, Texas 75001
(972) 250-3113
FOR YOUR
SAFETY
1. Do not store or use
gasoline or other
flammable vapors
or liquids in the
vicinity of this or
any other
appliance.
2. An LP Cylinder not
connected for use
shall not be stored
in the vicinity of
this or any other
appliance.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TEXAS SIZZLER “JR” and is the answer not in the manual?

Questions and answers

Summary of Contents for Golden Blount TEXAS SIZZLER “JR”

  • Page 1 ▪ Warranty ..... . . 8 or your fire shall not be stored department. in the vicinity of this or any other Golden Blount Inc. appliance. 4301 Westgrove Dr., Addison, Texas 75001 (972) 250-3113...

  • Page 2: Location Requirements

    LOCATION REQUIREMENTS: WARNING: This appliance should not be located closer than 10 inches to any adjacent combustible surface or under any unprotected combustible construction. WARNING: This appliance is designed for outdoor use only. This appliance must be on a level, stable surface in an open area.
  • Page 3 Optional Pedestal Base With Shelves: 1. Carefully remove grill from carton. 2. Remove pedestal base from carton and locate hardware to attach grill to pedestal. 3. Position pedestal on flat surface and locate (4) holes on each corner of “x” brace on top of pedestal. (Figure 3.) 4.

  • Page 4: Gas Connection

    GAS CONNECTION: The Texas Sizzler “JR” is offered in one of two gas types: LP or Natural Gas. LP models include pressure regulator and quick connect adapter for disposable LP cylinders. (Pressure regulator, hose assembly and quick connect adapter for 20 lb.

  • Page 5: Operation

    Connecting the Cylinder (20 lb) 1. Turn cylinder valve hand wheel clockwise until it stops. 2. Make sure burner control knob is in the “OFF” position. 3. Position grill in open area that is level. 4. Position cylinder in safe location and where hose will be positioned to prevent tripping.

  • Page 6: Manual Lighting Procedure

    6. If flame is not present, turn burner control knob to “OFF” position, leave cover open and wait 5 minutes. Repeat steps 3 through 6 until ignition occurs. 7. Rotate burner control knob to desired cooking level. 8. To turn off grill, push in and turn burner control knob to the “OFF” position. Lighting Burner Without Igniter: If the igniter is not working properly, the burner can be lit manually using a long match or extended nozzle butane lighter.

  • Page 7: Cooking Hints

    Cooking Hints: 1. When handling meat, use a spatula or tongs, instead of a fork. When meat is pierced the natural juices will leak out. 2. Upon initial use, start off with hamburgers or hot dogs to become familiar with infra-red cooking. 3.

  • Page 8: Replacement Parts List

    REPLACEMENT PARTS LIST: Item Description jr-cerelm Ceramic element kit w/gasket jr-burn Burner housing jr-scrn Burner screen jr-bcv Burner control valve jr-ldhdl Lid handle jr-bck Burner control knob jr-elec Electrode jr-ign Igniter jr-cgrid Cooking grid jr-dpan Drip pan jr-orinat Natural orifice jr-orilp LP orifice jr-regnat...

  • Page 9: Warranty

    DEFECTIVE PARTS ARE TO BE RETURNED TO THE FACTORY PREPAID FOR REPAIR OR EXCHANGE WITH PROOF OF PURCHASE. ALL HANDLING AND SHIPPING CHARGES ARE TO BE PAID BY THE PURCHASER. TEXAS SIZZLER GAS GRILLS MFG. BY GOLDEN BLOUNT INC. 4301 WESTGROVE DRIVE ADDISON, TEXAS 75001 (972) 250-3113...
