Summary of Contents for Schwaiger AVS5010 011
- Page 1 2.4GHz WIRELESS AV LINK OWNER’S MANUAL （PLEASE READ BEFORE USE） AVS5010 011 PLEASE CONSULT THE BACK COVER OF THIS OWNER’S MANUAL FOR MODEL AND FEATURE 0336...
- Page 2 Important-Safety Precautions ■ This device of which operation is subject to the following two condition (1) This device may not cause harmful interference, and (2)This device must accept any interference received, including interference that may cause undesired operation. • To prevent fire or shock hazard, do not expose this device to rain or moisture. Do not use near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet basement, or near a swimming pool.
- Page 3 • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. A.
- Page 4 B. Introduction to 2.4GHz Wireless AV Link This sender system is a wireless audio/video sender that uses advanced wireless communication technology to deliver consistently sharp audio and video up to 100 meters away. By transmitting at a very high frequency (2.4 GHz), it avoids the crowded 900 MHz band used by many cordless telephones and other wireless audio/video transmitters.
- Page 5 4. When two equipment or more is used at the same time, used different channels. But a transmitter can be used with several receivers at the same time. 5. When the equipment is operating, please do not use a microwave oven near 6.
-
Page 6: Product Layout
C. Product Layout The following illustrations show the names of each component, button and switch connectors on the transmitter and receiver. FRONT VIEW FOR RECEIVER LED of power and channel display IR remote control window... - Page 7 REAR VIEW FOR TRANSMITTER IR extender output port Audio L in (white) Audio R in (red) Video in (yellow) DC power input, connect to power adapter (9VDC Power on/off switch Channel Switch REAR VIEW FOR RECEIVER CH4 (NTSC only) RF output to TV (e.g.2058R) Audio L out (white) Audio R out (red)
- Page 8 D. Setting Up 2.4GHz wireless AV Link To enjoy wireless video and audio, just connect the transmitter to whatever audio/video source you want to enjoy from another location, and connect the receiver to the TV, monitor or powered speakers in that other location. A/V link system is suggested to connect to following A/V equipment use: Video sources：...
- Page 9 Make sure the ON/OFF switch is in the position before connection. ■ How To Transmit Audio/Video from Your VCR Connect VCR and transmitter using one of the provided A/V CABLE with RCA plug, plug SCART to VCR output jack, RCA to transmitter. Please follow the instruction figure below.
- Page 10 ■ How To Transmit RCA from Your Satellite Receiver You can transmit audio/video either directly from your satellite receiver, or by connecting them to your VCR. To transmit directly from your satellite receiver, follow the instructions below. 1. Connect satellite receiver and transmitter using one of the provided A/V CABLE with RCA plug, plug SCART to any SCART jack of satellite receiver, RCA to transmitter.
- Page 11 ■ How To Receive Wireless Audio/Video Signals on Your TV There are two ways to receiver wireless audio/video signals on your remote TV (TV in another location such as in bedroom, kitchen). · Connect the receiver directly to the remote TV. ·...
- Page 12 ■ Connecting Receiver to Remote TV through VCR This setup enables you to record transmitted audio and video on your remote VCR and also enjoy the picture and sound on a remote TV at the same time. 1. Connect VCR and receiver using one of the provided A/V CABLE with RCA plug, plug SCART to the SCART input of VCR, RCA to receiver.
- Page 13 E. Orienting Units for Optimum Performance This sender system should be placed on a flat, stable surface to prevent damage to it from falling. For optimum performance, both the audio/video and remote control antennas should be carefully oriented as described below. In addition, to use the remote extension feature, the transmitter itself must be specially oriented so it can relay the converted remote control signal back to the audio/video source (see following section titled "Using The Remote Control extension Feature").
- Page 14 Sometimes, it may be difficult or even impossible to orient the transmitter unit such that it can be "seen" (means face-to-face) by the A/V equipment you wish to control. Perhaps there is no good surface that allows for this or perhaps you wish to control. Or perhaps you wish to remotely control A/V equipment in different locations without re-orienting the transmitter.
-
Page 15: Troubleshooting, Care And Maintenance
G. Troubleshooting, Care and maintenance Please read this owner's manual carefully and follow the steps described in it. If you still have difficulties, consult the following table. It will guide you though the most common problems and their solutions. Problem Possible solutions No picture or sound •... -
Page 16: Specifications
Note: Clean the outside plastic packaging with a soft cloth lightly moistened with mild soap and water. Never use any abrasive scouring powder or solvent. H. Specifications Transmitter: Operating Frequency Band 2.400GHz~2.4835GHz Transmit power output 10dBm(CE), 0dBm(FCC) Modulation (video and audio) Video Input Level 1V p-p ＠... - Page 18 Schwaiger GmbH Würzburger Str. 17 D-90579 Langenzenn TEL: 09101 / 702 - 0 Hotline TEL: 09101 / 702 - 299 FAX: 09101 / 702 - 121 E-mail: info@schwaiger.de Web Site: http://www.schwaiger.de...
