Psion Teklogix MLP 3040 Quick Start Manual

Important:
1. You must charge the battery for at least 2½ hours prior to the first use.
2. Maximum battery capacity is first reached after completing three complete charge and discharge cycles.
3. Always use Genuine Psion Teklogix Media to ensure optimal performance.
• To load media:
• Move the Paper Door Release in the direction indicated in Figure A and open the Paper Door.
• Roll Feed - Move the media support as shown in Figure B and place the roll between the supports. Make sure the media rotates
freely. Lay the leading edge of the media through the print head as shown in Figure C, and close the door.
• To install the battery: Slide the battery into the battery compartment until the release lever on the battery snaps into place.
You may remove the battery by pressing the release lever toward the bottom of the printer and pulling the battery out of the
battery compartment.
• To charge the battery, connect a power adapter (sold separately) to the appropriate power source and plug the output
cable into the printer's Power Connector as shown in Figure A. The Battery Indicator will turn on indicating that the battery
is being charged.
• To perform a self test, press and hold the
Note: For more information, refer to the MLP3040 Series Operator's Manual.
Serial I/O Connector
Tear Bar
Power Connector
Magnetic Card Reader
Figure A
Power
Paper Feed
/Advance
Paper Feed Button while turning on the printer with the
Paper Supply Gauge
Paper Door
Release

Quick Start Guide

Power Button.
Paper Door
Release Lever
Battery
Media Support
Figure B
Paper Leading Edge
Figure C
